OWNER'S MANUAL
ER100103
SmartSet Clock Radio,
With Auto Date-Time Setting System,
1.4" Blue Jumbo Display,
Dual Alarms, PLL FM Radio,
USB Charging and
Red Projection Clock
(SmartSet Patent No. 6,567,344)
®
Location of Controls and Indicators
5
2
2
Setting Time Zone / Clock / Alarm Week Mode
NOTE: If you manually adjust the time, your new setting is entered into the
SmartSet memory. If the power is interrupted, the display will return to
your new setting, not the original setting, when the power is restored.
®
Date and Year Display and Adjustment
YEAR ADJUSTMENT:
While at YEAR DISPLAY, press the" " or " " button to adjust the Year ▼ ▲
Depress and hold the "TIME ZONE" button.
Press the " " or " " button until your own time zone appears on the ▼ ▲
display, then release the buttons.
1
2
There are 7 time zones programmed into your clock radio as SmartSet
follows:
ZONE 1 — Atlantic Time ZONE 2 — Eastern Time (Default Setting)
ZONE 3 — Central Time ZONE 4 — Mountain Time
ZONE 5 — Pacific Time ZONE 6 — Yukon Time
ZONE 7 — Hawaiian Time
®
6
Adjusting The Wake Up Times and
Alarm Week Mode
A
Everyday
The alarm will
turn on all 7 days.
Weekdays only
B
The alarm will only
turn on Monday
through Friday.
C
The alarm will only
turn on Saturday
and Sunday.
Alarm Week Mode
Press and hold the "AL1" ("AL2") button until the
display flashes, then release the buttons.
Press the "AL MODE" button to select the
Alarm Week Mode , or that suits your need.
Short press the “AL1” (“AL2”) button again,
Alarm Volume (U03-U15) will display.
Repeat the Alarm Volume setting procedure
stated above.
Selecting The Alarm We ek Mode( / / )
A B
C
NOTE: Be sure that you have set the wake up time by observing the AM
indicator. If the AM indicator is 'On ' the wake up time is "AM". Otherwise
the wake up time is "PM".
Daylight Saving and Leap Year Adjustments
Al l Da yl i gh t Sav i n g a n d L e ap Yea r a d j us t me n ts ar e m a de
au t om a ti c a ll y by the SmartSet internal computer as follows:
• Start of Daylight Saving Time:
At "2:00 AM" on the 2nd Sunday in March, the clock will automatically
advance to "3:00 AM".
• End of Daylight Saving Time:
At '3:00 AM' on the 1st Sunday in November, the clock will automatically
reset to "2:00 AM".
• Leap Year:
At "12:00 Midnight" on February 28th, the calendar display will change
to "2.29".
®
Manual Time Adjustments
Press and hold the “TIME” button, and then short or long press the
" " or " " button to advance Hour or Minutes.▼ ▲
The first time you connect your new clock radio to the AC outlet SmartSet
the internal computer will automatically set the time correctly for the Eastern
Time Zone, which is the initial default setting.The display will scan for a few
seconds and then show the correct and in the Eastern zone. If you Day Time
live in the Eastern Time zone, there’s nothing else to do. Your clock is set
correctly and running.If you do not live in the Eastern Time zone you must
change the default zone display to your own zone. You only do this one time
and the will remember the new default zone setting and will SmartSet
always return to that setting after a power interruption.
®
®
Press and hold the “AL1” (“AL2”) button until the
display flashes, then release the button.
Short or long press the " " or " " button to ▼ ▲
advance Hour or Minutes.
Short press the “AL1” (“AL2”) button again,
Alarm Volume (U03-U15) will display.
Short or long press the " " or " " button to ▼ ▲
decrease or increase the maximum volume of the
buzzer or radio alarm at which the alarm will
reach gradually at wake up time.
Then, short press the “AL1” (“AL2”) button again
to finish this alarm setting process, or leave the
unit idle, that will resume to time/standby mode
automatically.
Adjusting The Wake Up Times for AL1 or AL2
Package Contents
ER100103 Clock Radi o x 1
Read Thi s Sheet
1
SN OOZE
DIM MER
SLE EP
ZON E
TIM E
MEM .STO RE
VOL +VOL
AL MOD E
DATE
YEA R
TIM E
AL1 AL2 - TUNE / S ET +
21
SNO OZ E
DIM MER
14
16
15
18
13
22 23
24
25
19
20
26
27
SL EEP
ZO NE
TI ME
AL MO DE - TUN E / SET +
DATE
YEA R
TIM E
ME M.STO RE
AL1 AL2
VO L+VO L
1
2
3
4
58
9
10
11
12
6
7
17
28
16. S peak er (B ac k Cabinet).
17. MEMTIME Setting / FM Station Recall
18. S TORE MONTH/DATE Setting / Radio
Station .abc
19. 1 VOLUME-ALARM Setting / Button .
2 2 VOLUME+0. ALARM Setting / Button.
21. P roj ecto r.
22. (Button.UNIT ON / OFF Standb y)
23. / Button .SNOOZE DIMMER
24. SLEEP B utton(Slee p To Music Time r).
Button. ▲ 25. TUNE +/ S ET
▼ 26. TUNE -/ Button.SET
adapter(Bo tto m Cabine t).27. AC
28. A dapter's cable (also acts
as the FM antenna)
Holder(29. B ackup Bat tery Bac k Cab inet)
1. (AL 1'Radi o' Alarm Indic ato r.)
2. (AL 1'Buzzer' Alarm In dicator.)
3. AM Indicator.('On'=AM;'Off'=PM)
4. AUX Indicator.
5. DAY OF WEEK MON, Indic ators.(
TUE ,WED,THU,FRI,SAT,SUN)
6. Projection clock Button.ON/OFF
7. ROTATE IM AGE Button.
8. LOW Batter y Indicator.
9. FM Radio Indicator.
10. (AL 2 ‘B uz z er’) Alarm Indi cator.
11. (AL 2 ‘Radio’) Alarm Indicator.
12. Ti me/Date Dis play.
13. / Button .TIME ZONE AL M ODE
14. USB Charge Out
15. J ac k. AUX IN
1
1
4
SNOOZ E
DIMMER
ZO NE
TI ME
ME M.STO RE
VO L+VO L
AL MO DE
DATE
YEA R
TIM E
AL1 A L2 - TUN E / SET +
SL EEP
1
1
1
11
Note: Time Zone and Date/Time setting can only be adjusted
in standby mode, where the function of Radio and AUX are
disabled (indicators of "MHz" and "AUX" are Off).
DATE DISPLAY(MM.DD):
Press and hold the DATE button " "
DATE ADJUSTMENT:
Press and hold the DATE button and then short or long press the “ ” ,
" " or " " button to advance Month or Date▼ ▲ .
For example May 21st will appear as 5 21 , " . ".
Release the buttons to finish the adjustment .
YEAR DISPLAY(YYYY)
Press and hold the "DATE" and "TIME" button
Release the buttons to finish the adjustment.
29
2
2
2
22
A B
C
Tuning to The FM Radio
1
2
Storing Station to the Memory
Listening to The Radio
7
Recalling Station from the Memory
After the radio is ‘On’ ,press , ‘P XX’ shows on the display .The station
according to this memory location will then be automatically tuned in.
To change memory location(P01~P20),press to step Up or press to step
Up/Down to locate and tune in the station stored in memory.
1
Enjoying Audio Sources with AUX IN Jack
8
Remark:
Even the jack is plugged in, the alarm sound only be Buzzer or Radio AUX IN
according to your Alarm Mode setting while the alarm function is activated.
Press to turn the unit ‘On’.
Connect the audio source from its earphone jack to with a 3.5mm Male to
Male stereo AUX cable (not provided)
AUX indicator will be On connected，when the AUX cable
Start to play the audio source.
The AUX volume can be adjusted through your audio players only.
1
3
1 hour
Radio gradually
• →Alarm 1 Single beep" sound
• →Alarm 2 Double beep" sound
1 hour
Buzzer gradually
Wake To Radio and Radio Alarm Volume Setting
Setting The Alarm
Wake To Buzzer
Press to turn the radio ( MHZ ‘On’) without AUX cable connected.On
Press or recall station from the to select the station that you Memory
wish to hear when the alarm comes ‘On’.
Press to set the maximum radio volume at which the alarm will
reach gradually at wake up time .
Turn Off the radio if it is On.
Then follow through the steps stated in the “Adjusting The Wake Up Times
and Alarm Week Mode” section to set the Radio Alarm and Volume for AL1
or Al2.
Press slightly, and repeat doing so if necessary, until or
indicator is lit on the display.
If you do not want the alarm to turn the radio on the following day , press
and release continuously until the ALARM indicator on the display is
‘Off’.
1
3
2
9
9 minutes
Radio And Buzzer Operation
You may also set one alarm for wake to and the other for wake to RADIO
BUZZER AL 1 AL 2. Just press the and buttons to the desired status as
shown on the ALARM indicators.
Reconfirm the wake up time and alarm mode settings for the alarm
you are using by pressing and holding when the"AL1" ("AL2")
unit is . ‘Off’
If alarm time adjustment is needed, follow through the steps stated in the
“Adjusting The Wake Up Times and Alarm Week Mode” section to set the
Buzzer Alarm and Volume for AL1 or AL2.
Press slightly, and repeat doing so if necessary, until or indicator
is lit on the display.
At the selected wake up time the buzzer will sound gradually and continue 
for 1 hour, press to stop the buzzer sooner.
If you do not want the alarm to buzzer on the following day, press and
release continuously until the ALARM indicator on the display is ‘Off’.
2
2
1
2
Snooze Alarm
1
Press the "SNOOZE/DIMMER" button while in Standby mode and select
any of the four levels. It also can be adjusted when the Radio or AUX is On.
4-Level Dimmer Control
12
10
toward any light-colored ceiling Tilt the rotatable Projector
or wall.
Press the Projector “ON/OFF” button to project the clock time
image .onto the ceiling or wall
Rotate the knob of the Projector either in clockwise or counterclockwise
direction to bring the image to focus.
If the image is inverted, press the “ROTATE IMAGE” button to meet
your needs.
Note: The projector will come On when the alarm comes On. It will turn
Off once the alarm is turned Off.
Lithium Battery Precautions
• Dispose of the old battery properly. Do not leave it lying around where a young
child or pet could play with, or swallow it. If the battery is swallowed, contact a
physician immediately.
• Battery may explode if mistreated. Do not attempt to recharge it or
disassemble it. Do not dispose of the old battery in a fire.
Care Of Cabinets
If the cabin et becomes dust y, wipe i t with a soft cloth. If the cabinet
becom es smudged or dirty, clean it with a soft, slightly dampened cloth .
Nev e r all o w wa t e r o r an y liq u i d t o g et in si d e th e cab i n e t. N e ver u se
a ny abrasive cleaners or cleaning pads as these will damage the finish of
your radio.
15 CARE AND MAINTENANCE
Emerson Radio Corp. warrants this product to be free from manufacturing
defects in original material, including original parts, and workmanship under
normal home use and conditions (“manufacturing defect”) for a period of ninety
(90) days from date of original purchase in, and if used in the United States.
Should service be necessary under this warranty, Emerson will provide the
following at our Return Repair Facility provided the manufacturing defect is
verified along with the date of purchase:
* Repair service for ninety (90) days from date of original purchase at no
charge for labor and parts.
To Receive Authorization to Return a Defective Item, please contact
Emerson Customer Service at 1-800-898-9020. Have your Model number,
Serial Number and dated Proof of Purchase with you when you call.
In the event the product must be returned to Emerson:
* Pack the unit in a well-padded heavy corrugated box. Please insure the item
is well padded to avoid damage while in transit back to our facility. If the item
incurs damage, it will NOT be replaced and the consumer will be responsible
for return freight costs to receive their same unit back.
* Enclose your check or money order payable to Emerson Radio in the
amount of $10 to cover return shipping and handling costs.
* Enclose a note with your name, address, phone number, Return
Authorization number and brief reason for returning the unit.
* Enclose a copy of your proof of purchase (warranty service will not be
provided without dated proof of purchase).
* Ship the unit prepaid via UPS or parcel post (SHIP INSURED and obtain a
abtracking number).
NOTE: This warranty does not cover:
(a) Damage to equipment not properly connected to the product.
(b) Cost incurred in the shipping of the product to and from Emerson's Return
abcFacility.
(c) Damage or improper operation of unit caused by customer abuse, misuse,
negligence or failure to follow operating instructions (including cleaning
abcinstructions) provided with the product.
(d) Ordinary adjustments to the product which can be performed by customer
as outlined in the owner's manual.
(e) Signal reception problems caused by external antenna or cable systems.
(f ) Products not purchased in the United States.
(g) Damage to product if used outside the United States.
THIS WARRANTY IS NON-TRANSFERABLE AND APPLIES ONLY TO THE
ORIGINAL PURCHASER AND DOES NOT EXTEND TO SUBSEQUENT OWNERS
OF THE PRODUCT. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING THE
WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A PERIOD
OF THE EXPRESSED WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE
DATE OF ORIGINAL PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER
EXPRESSED OR IMPLIED, SHALL APPLY TO THE PRODUCT THEREAFTER.
EMERSON MAKES NO WARRANTY AS TO THE FITNESS OF THE PRODUCT
FOR ANY PARTICULAR PURPOSE OR USE.THE EXTENT OF EMERSON RADIO
CORP'S LIABILITY UNDER THIS LIMITED WARRANTY IS THE REPAIR OR
REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL EMERSON RADIO
CORP'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY THE PURCHASER
OF THE PRODUCT. UNDER NO CIRCUMSTANCES SHALL EMERSON RADIO
CORP. BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
OR CONSEQUENTIAL DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE
USE OF THIS PRODUCT. THIS WARRANTY IS VALID ONLY IN THE UNITED
STATES OF AMERICA.THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS.
HOWEVER, YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO
STATE. SOME STATES DO NOT ALLOW LIMITATIONS ON IMPLIED WARRANTIES
OR EXCLUSION OF CONSEQUENTIAL DAMAGE, THEREFORE THESE
RESTRICTIONS MAY NOT APPLY TO YOU.
LIMITED WARRANTY
16
Model Number : ER100103
Serial Number :
The serial number can be found on the back cabinet. We suggest that you
record t he serial number of your unit in the space below for future
reference.
10-90-1402A
Emerson Part No. ER100103-20180108-00 Printed in China
3
1
2
3
12
2
4
4
23
10 90 min ,-
shut off automatically
Turn the unit On to Radio or AUX IN mode.
Short press the “SLEEP” button to choose your desired sleep timer
(10-90 minutes or OFF).
To display the sleep timer during countdown, press the “SLEEP” button.
To cancel the sleep timer, press to shut off the unit.
11 2~3 years battery life
CR2032(3V)
NEGATIVE(-)POSIT IVE(+)
Changing The Lithium Battery
14
USB For Charging
Output DC for 5V 1.2A
charging mobile phone or
portable digital audio player.
13
Note: Charging current drawn from the unit may vary due to different USB
charging cable condition or battery charging characteristics.
1
1SNOOZE
DI MME R SLEEP
ZO NE
TIME
AL M ODE - TUNE / SET +
DAT E
YE AR
TI ME
ME M.STOR E
AL 1 AL 2
VOL+VOL
S
NOOZ E
DIMME R
- TU NE / S ET +
DAT E
YEAR
TIM E
AL1 A L2
VOL+ ME M.
STO
RE
VOL
2
2
2
22
SL
EE P
ZONE
TIME
AL MO
D
E
- TUN E / SET +
DATE
YEAR
TIM E
AL1 AL2
VO L+ M
EM.
STO RE
VOL
SNOO ZE
DIMM ER
SN
OO ZE
DIM M
ER
1
1
1
1
1
AUX
3
PLAY
4
SLE EP
ZON E
TIM E
MEM .STOR E
VOL +VOL
AL MO D E
DATE
YEAR
AL1 AL2 - TUN E / S ET +
TIME
AM M
M
M
MMHz
Hz
Hz
HzHz
2
- TUNE / S ET +
DATE
YE
A
R
TIM E
AL
1AL
2
VO
L+ ME
M.
STORE
VOL
SNOOZE
DIM MER
3
3
3
3
3
1
1
1
1
1
SL EEP
ZO NE
TI ME
AL MO DE
ON/
OFF
ROTAT
E
- TUN E / SE T +
DATE
YEAR
TIME
AL 1 AL 2
VOL +
ME
M.
STO R E
V
OL
SNOOZE
DIMMER
SLEEP
ZONE
TIME
AL MO DE
1
- TUNE / S
ET +
DATE
YEA
R
TIME
AL1 AL2
VO L+ MEM.
STORE
VOL
SN OOZE
DI MM ER
SL EEP
ZO NE
TI ME
AL MO DE
SL EEP
ZO NE
TI ME
AL MO DE
SNOOZE
DIMM ER
- T
U
NE / S
ET +
DATE
YEAR
TIME
A
L1 AL2
VO L+ ME M.
STO RE
VO
L
SL EE P
ZON E
TI ME
A
L MO DE
NEGATIVE( )－
SNOOZE
DIM MER
- TU NE / S ET +
DATE
YE AR
TI ME
AL 1 AL 2
VO L+ M
EM.
STO
RE
VOL
S
LEE P
Z
ONE
TIM E
AL M ODE
2
radio
4
1
1
1
1
1
2
2
2
2
2
SAT SU N
AM
-
DATE
YEAR
TIME
AL1AL2
VOL+MEM.
STORE
VOL
SNOO ZE
DI MME
R
2
2
2
2
21
1
1
1
1
SLE EP
ZON E
TIM E
AL MOD E
AM
- T
UNE / SET +
DATE
YEA R
TIM E
A
L1AL2
VOL+M
EM .
ST ORE
VO
L
SNOO Z E
DI
MMER
2
2
2
22
1
1
1
1
1
SL EEP
ZO NE
TI ME
AL MO DE
SAT SU N
SAT SUN
5V 1.2 A
USB C
HAR.
AU X I
N
5V
1. 2A
USB C
N
5V
1.2A
USB C H AR.
AU
X IN
23
SN OO Z
E
DIMM ER
SLE EP
ZON E
TIM E
MEM .STO RE
VOL +VOL
AL MO DE
DATE
YEA R
TIM E
AL1 AL2 - TUNE / S ET +
1
1
1
1
1
SNOOZ E
DI
MMER
SLE EP
ZON E
TIM E
MEM .STO RE
VOL +VOL
AL MO DE
DATE
YEA R
TIM E
AL1 AL2 - TUNE / S ET +
1
1
1
1
1
4
4
4
4
4
3
3
3
3
3
4
4
4
44
2
2
2
2
2
2
2
2
2
2
3
3
3
33
1
1
1
1
1
2
2
2
2
2
3
3
3
3
3
4
4
4
4
4
1
1
1
1
1
2
2
2
2
2
1
1
1
1
1
Projecting the Clock Alarm Time  /
Sleeping to Music Timer
The built-in lithium battery is used to supply power to the SmartSet®
computer memory during storage period or power interruption. When the
battery power drops below a certain level, the LOW BATTERY "  "
indicator will `Flash'. You should replace the battery with a new 3V lithium
CR2032 or equivalent as follows:
1) Use a small screw driver to remove the screw securing the battery
holder to the cabinet.
2) Remove the original battery from the holder and insert the new battery
into the holder the same way, observing the positive (+) polarity.
3) Slide the holder with the new battery back into the slot in the cabinet.
4) Replace the screw that secures the battery holder in the cabinet.
4

Produktspecifikationer

Varumärke: Emerson
Kategori: Inte kategoriserad
Modell: ER100103

Behöver du hjälp?

Om du behöver hjälp med Emerson ER100103 ställ en fråga nedan och andra användare kommer att svara dig


Inte kategoriserad Emerson Manualer

Emerson

Emerson SmartSet CKSW5010 Bruksanvisning

24 September 2024
Emerson

Emerson SmartSet CKS8888 Bruksanvisning

24 September 2024
Emerson

Emerson Sensi RS01-SG Bruksanvisning

23 September 2024
Emerson

Emerson CK2023 Bruksanvisning

22 September 2024
Emerson

Emerson CKS1401 Bruksanvisning

22 September 2024
Emerson

Emerson MWG1191SB Bruksanvisning

22 September 2024
Emerson

Emerson WBS12 Bruksanvisning

20 September 2024
Emerson

Emerson CR175B Bruksanvisning

16 September 2024
Emerson

Emerson FK609 Bruksanvisning

16 September 2024
Emerson

Emerson PD5802 Bruksanvisning

16 September 2024

Inte kategoriserad Manualer

Nyaste Inte kategoriserad Manualer

Philips

Philips 43PUL7672 Bruksanvisning

27 Oktober 2024
Manhattan

Manhattan 461504 Bruksanvisning

27 Oktober 2024
Sungrow

Sungrow SG125HV Bruksanvisning

27 Oktober 2024
Schneider

Schneider CCT724319 Bruksanvisning

27 Oktober 2024
Technoline

Technoline WS 250 Bruksanvisning

27 Oktober 2024
Livarno

Livarno IAN 354423 Bruksanvisning

27 Oktober 2024
Kupper

Kupper 12152 Bruksanvisning

27 Oktober 2024
JennAir

JennAir CARBON24L Bruksanvisning

27 Oktober 2024
Medion

Medion Life E74001 (MD 81035) Bruksanvisning

27 Oktober 2024
POLARIS

POLARIS Sportsman Touring 850 SP (2015) Bruksanvisning

27 Oktober 2024
