GEIST™ SWITCH IRA
AIRFLOW MANAGEMENT DEVICE
Quick Installation Guide
SL-70387_REV0/VM-1176/590-2211-501A 1
Models:
SA1-01002, SA1-01002S and
SA1-01002L
Type:
Rear Air Intake-Front (Port)
Exhaust Switches
CAUTION: Ensure the required
airflow for safe operation of
equipment is not compromised
when installing the Geist SwitchAir.
WARNING: Take precaution to
avoid interference with the switch
input power cords when installing
on a live unit.
1. Preparing for installation
Before installing the SwitchAir,
remove the lower screw that
attaches each of the two switch
mounting bracket rails (left and
right) to the front rack uprights
(if necessary). Save these
screws to be used in the next
step. The switch mounting
bracket rails’ upper screws
remain fastened.
SwitchAir is not in the fully
extended position when
shipped from the factory. Pull
evenly on the chassis mounting
tabs for the desired depth.
2. Installing the unit into the
rack
Insert SwitchAir into the open
rack space at the same U height
as the switch. As the SwitchAir
is pushed into the space, the
SwitchAir rail tabs will engage
the switch mounting bracket
rails for support during
installation. Keep pushing the
SwitchAir into the space until
the SwitchAir front chassis
mounting tabs are flush with the
racks front rails.
Reinstall the screws that were
removed previously. Installation
is complete.
Geist SwitchAir Airflow Management Device
Geist SwitchAir Rack Installation
Switch
Switch mounting
bracket rails
Lower screws
Rack uprights
Expand to
fit
Rail tab
Rail tab
To contact Vertiv Technical Support: visit www.VertivCo.com
© 2019 Vertiv Co. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names,
trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co. assumes no
responsibility, and disclaims all liability, for damages resulting from use of this information or for any errors or omissions. Specifications are subject to change without notice.
2 SL-70387_REV0/VM1176/590-2211-501A
