Sida 1/48
EZM-4430 48x48 DIN 1/16 Programmable Counter
EZM-4430 48 x 48 DIN 1/16
Universal Input Programmable Counter
Introduction Manual. ENG EZM-4430 02 V00 07/07
-
-
-
6 digits Process (PV) and 6 digits Set (SV) Value Display
- Operation with 1 Set Value
- Reset , Pause and ChA-ChB Counting Inputs
Operation with Automatic and Manual Reset
NPN/PNP Type Operation
- INC , DEC , INC / INC , INC / DEC , UP / DOWN , x1 / x2 / x4
Counting with Phase Shifting Property in Counter Function
- Multiplication Coefficient and Decimal Point Position
2
a
c
i
Instruction manual of EZM-4430 Programmable Counter consists of two main sections.
Explanation of these sections are below. Also, there are other sections which include order
information and technical specifications of the device. All titles and page numbers in instruction
manual are in “ ” section. User can reach to any title with section number.
In this section, physical dimensions of the device, panel mounting, electrical wiring,
module mounting in the device, physical and electrical installation of the device to the system are
explained.
In this section, user interface of the device, how to access to the parameters, description
of parameters are explained.
CONTENTS
Installation:
Operation and Parameters:
Also in these sections, there are warnings to prevent serious injury while doing the
physical and electrical mounting or using the device.
Explanation of the symbols which are used in these sections are given below.
This symbol is used to determine the dangerous situations as a result of an electric
shock. User must pay attention to these warnings definitely.
This symbol is used for safety warnings. User must pay attention to these
warnings.
This symbol is used to determine the important notes about functions and usage of
the device.
ABOUT INSTRUCTION MANUAL
3
1.PREFACE..................................................................................................................
2.INSTALLATION.........................................................................................................
3.ELECTRICAL WIRINGS...........................................................................................
4.DEFINITION OF FRONT PANEL AND ACCESSING TO THE SET
PARAMETERS............................................................................................................
FAILURE MESSAGES IN EZM-4430 PROGRAMMABLE COUNTER ...................
1.1 GENERAL SPECIFICATIONS
1.2 ORDERING INFORMATION
1.3 WARRANTY
1.4 MAINTENANCE
2.1 GENERAL DESCRIPTION
2.2 DIMENSIONS
2.3 PANEL CUT-OUT
2.4 ENVIRONMENTAL RATINGS
2.5 PANEL MOUNTING
2.6 INSTALLATION FIXING CLAMP
2.7 REMOVING FROM THE PANEL
TERMINAL LAYOUT AND CONNECTION INSTRUCTION
3.2 ELECTRICAL WIRING DIAGRAM
CONNECTION OF DEVICE SUPPLY VOLTAGE INPUT
COUNTING INPUT CONNECTION
3.5.1 PROXIMITY & SWITCH CONNECTION
3.5.2 INCREMENTAL ENCODER & SWITCH CONNECTION
3.5.3 SWITCH CONNECTION
3.6 RELAY OUTPUT WIRING DIAGRAM
3.7 GALVANIC ISOLATION TEST VALUES OF EZM-4430 PROGRAMMABLE
COUNTER
4.1 DEFINITION OF FRONT PANEL
4.2 POWER ON OBSERVATION OF EZM - 4430 PROGRAMMABLE
COUNTER AND SOFTWARE REVISION ON THE DISPLAY
RESETTING COUNT VALUE
ACCESSING TO THE PROGRAM PARAMETERS
3.1
3.3 VIEW OF DEVICE LABEL
3.4
3.5
4.3 ADJUSTMENT OF SET VALUE
4.4
4.5
5.PROGRAM PARAMETERS......................................................................................
6.
7.SPECIFICATIONS ....................................................................................................
CONTENTS
Page 5
Page 7
Page 12
Page 20
Page 29
Page 46
Page 48
