Sida 1/3

FEATURESTECHNICAL SPECS

Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY

superior functionality synth module 3HP wide and affordable?

Yes, we can.

Erica Pico NOISE is a versatile noise and percussion sounds source.

It consists of white a noise generator, a resonant VCF to generate

various colours of the noise – from extremely dark ones to high

pitched resonant sweeps and a VCA/decay envelope generator

combination to create range of percussion sounds to emulate

hi-hats, cymbals and even sine tone-based percussions, when the

resonance is full up.

White noise generator

Resonant VCF for coloured noise

VCA and decay envelope combo for percussion sounds

Input and output protection against overvoltage

Protection against reverse PSU connection

Output amplitude -5V — +5V

Max decay time 350ms

Power consumption +27mA, -25mA

Module width 3HP

Module depth 35mm

NOISE

PICO

NOISE

Adjust the VCF cutoff to control a

colour of the noise on the COLOR

output

Set the built in envelope generator

Decay time

This is the coloured noise output

This is the main output of the module –

the noise is internally routed through

the VCF, VCA + decay envelope.

Here you have percussion sounds

Adjust the VCF resonance. When the

resonance is close to full CW, the VCF

goes into self-oscillation and the

resulting sound is a mix of noise and

sinewave. When running it through VCA

you can achieve sounds similar to

cowbell and even toms, depending on

COLOR knob setting

Patch the trigger here to initiate

the internal decay envelope

generator and open a VCA

This is the white noise output

Water is lethal for most of the electric devices, unless they are made

waterproof. This Erica Synths module is NOT intended for use in a humid or

wet environment. No liquids or other conducting substances must get

into the module. Should this happen, the module should be disconnected

from mains power immediately, dried, examined and cleaned by

a qualified technician.

Do not expose the module to temperatures above +50° C or below -20° C. If

you have transported module in extreme low temperatures, leave it in

room temperature for an hour before plugging it in

Transport the instrument carefully, never let it drop or fall over.

Warranty does not apply to modules with visual damages.

The module has to be shipped in the original packaging only. Any module

shipped to us for return, exchange and/or warranty repair has to be in

its original packaging. All other deliveries will be rejected and

returned to you. Make sure you keep the original packaging and

technical documentation.

This device complies to the EU guidelines and is manufactured ROHS

conforming without use of led, mercury, cadmium and chrome.

Nevertheless, this device is special waste and disposal in household

waste is not recommended.

Safety Instructions

You will find Erica Synths terms of warranty at www.ericasynths.lv.

Items for return, exchange and/or warranty repair have to be sent to:

Erica Synths

Andrejostas Str. 43

Riga

Latvia

LV-1045

User manual by Girts Ozolins@Erica Synths

Design by Ineta Briede@Black8

Copying, distribution or any commercial use in any way is prohibited and needs the written

permission by Erica Synths. Specifications are subject to change without notice.

In case of any questions, feel free to contact us through www.ericasynths.lv or via e-mail

info@ericasynths.lv

Please follow the instructions for use of the Erica Synths module

below, ‘cause only this will guarantee proper operation of the module

and ensure warranty from Erica Synths.
