Sida 1/16

MODEL

WM5

5kg

Front Loader

Washing Machine

Manual

Installation and Operation

2 - EN

1 Warnings

General Safety

• Neverplaceyourmachineonacarpet

coveredfloor.Otherwise,lackofairflow

frombelowofyourmachinemaycause

electricalpartstooverheat.Thismaycause

problemswithyourwashingmachine.

• Ifthepowercableormainsplugis

damagedyoumustcallAuthorizedService

forrepair.

• Fitthedrainhoseintothedischarge

housingsecurelytopreventanywater

leakageandtoallowmachinetotakein

anddischargewaterasrequired.Itisvery

importantthatthewaterintakeanddrain

hosesarenotfolded,squeezed,orbroken

whentheapplianceispushedintoplace

afteritisinstalledorcleaned.

• Yourwashingmachineisdesignedto

continueoperatingwhenthepower

restoresafterapowerinterruption.The

machinewillresumeitsprogramwhenthe

powerrestores.Pressthe“Start/Pause/

Cancel”buttonfor3secondstocancelthe

program(See,CancelingaProgram)

• Theremaybesomewaterinyourmachine

whenyoureceiveit.Thisisfromthequality

controlprocessandisnormal.Itisnot

harmfultoyourmachine.

• Someproblemsyoumayencountermay

becausedbytheinfrastructure.Press

“Start/Pause/Cancel”buttonfor3seconds

tocanceltheprogramsetinyourmachine

beforecallingtheauthorizedservice.

First Use

• Carryoutyourfirstwashingprocess

withoutloadingyourmachineandwith

detergentunder“Cottons90°C”program.

• Ensurethatthecoldandhotwater

connectionsaremadecorrectlywhen

installingyourmachine.

• Ifthecurrentfuseorcircuitbreakerisless

than16Amperes,pleasehaveaqualified

electricianinstalla16Amperefuseor

circuitbreaker.

• Whileusingwithorwithoutatransformer,

donotneglecttohavethegrounding

installationlaidbyaqualifiedelectrician.

Ourcompanyshallnotbeliableforany

damagesthatmayarisewhenthemachine

isusedonalinewithoutgrounding.

• Keepthepackagingmaterialsoutofreach

ofchildrenordisposethembyclassifying

accordingtowastedirectives.

Intended use

• Thisproducthasbeendesignedforhome

use.

• Theappliancemayonlybeusedfor

washingandrinsingoftextilesthatare

markedaccordingly.

Safety instructions

• Thisappliancemustbeconnectedto

anearthedoutletprotectedbyafuseof

suitablecapacity.

• Thesupplyanddraininghosesmust

alwaysbesecurelyfastenedandremainin

anundamagedstate.

• Fitthedraininghosetoawashbasinor

bathtubsecurelybeforestartingupyour

machine.Theremaybeariskofbeing

scaldedduetohighwashingtemperatures!

• Neveropentheloadingdoororremovethe

filterwhilethereisstillwaterinthedrum.

• Unplugthemachinewhenitisnotinuse.

• Neverwashdowntheappliancewitha

waterhose!Thereistheriskofelectric

shock!

• Nevertouchtheplugwithwethands.Do

notoperatethemachineifthepowercord

orplugisdamaged.

• Formalfunctionsthatcannotbesolvedby

informationintheoperatingmanual:

• Turnoffthemachine,unplugit,turnoff

thewatertapandcontactanauthorized

serviceagent.Youmayrefertoyourlocal

agentorsolidwastecollectioncenterin

yourmunicipalitytolearnhowtodisposeof

yourmachine.

If there are children in your

house...

• Keepchildrenawayfromthemachine

whenitisoperating.Donotletthem

tamperwiththemachine.

• Closetheloadingdoorwhenyouleavethe

areawherethemachineislocated.

3 - EN

2 Installation

Removing packaging

reinforcement

Tilt the machine to remove the packaging

reinforcement. Remove the packaging

reinforcement by pulling the ribbon.

Opening the transportation locks

ATransportationsafetyboltsmustbe

removedbeforeoperatingthewashing

machine!Otherwise,themachinewillbe

damaged!

1. Loosenalltheboltswithaspanneruntil

theyrotatefreely(“C”)

2. Removetransportationsafetyboltsby

turningthemgently.

3. Fitthecovers(suppliedinthebagwiththe

OperationManual)intotheholesonthe

rearpanel.(“P”)

Keepthetransportationsafetyboltsin

asafeplacetoreusewhenthewashing

machineneedstobemovedagaininthe

future.

Nevermovetheappliancewithoutthe

transportationsafetyboltsproperlyfixedin

place!

Adjusting the feet

ADonotuseanytoolstoloosenthelock

nuts.Otherwise,theycanbedamaged.

1. Manually(byhand)loosenthelocknutson

thefeet.

2. Adjustthemuntilthemachinestandslevel

andfirmly.

3. Important:Tightenalllocknutsupagain.

Connecting to the water supply.

Important:

• Thewatersupplypressurerequiredtorun

themachinemustbe1-10bar(0,1–1

MPa).

• Connectthespecialhosessuppliedwith

themachinetothewaterintakevalveson

themachine.

• Ifyouaregoingtouseyourdoublewater-

inletmachineasasingle(cold)water-inlet

unit,youmustinstallthestopper*,supplied

withyourmachinetothehotwatervalve.

• Ifyouwanttousebothwaterinletsofthe

product,youcanconnectthehotwater

hoseafterremovingthestopperand

gasketgroupfromthehotwatervalve.

* Applies for the products supplied with a blind

stopper group.

• Modelswithasinglewaterinletshouldnot

beconnectedtothehotwatertap.

When returning the appliance to its place after

maintenance or cleaning, care should be taken

not to fold, squeeze or block the hoses.

Connecting to the drain

The water discharge hose can be attached to

the edge of a washbasin or bathtub. The drain

hose should be firmly fitted into the drain as to

not get out of its housing.

Important:

• Theendofthedrainhosemustbedirectly

connectedtothewastewaterdrainorto

thewashbasin.

• Thehoseshouldbeattachedtoaheightof

atleast40cm,and90cmatmost.

• Incasethehoseiselevatedafterlayingit

onthefloorlevelorclosetotheground

(lessthan40cmabovetheground),water

dischargebecomesmoredifficultandthe

laundrymaycomeoutwet.

• Thehoseshouldbepushedintothe

drainageformorethan15cm.Ifitistoo

longyoumayhaveitshortened.

• Themaximumlengthofthecombined

hosesmustnotbelongerthan3.2m.
