Classic Deluxe 110 Dual Fuel
Australia
USER GUIDE &
INSTALLATION INSTRUCTIONS
i
1. Before You Start... 1
Installation and Maintenance 1
Peculiar Smells 1
If You Smell Gas 1
Ventilation 1
Personal Safety 1
Cooker Care 2
Cleaning 2
2. Cooker Overview 3
Hotplate Burners 3
Wok Burner 4
The Wok Cradle 4
The Ceramic Hotplate 5
The Griddle 6
The Glide-out Grill 7
The Ovens 8
The Clock 11
Accessories 13
Oven Lights 14
Storage 14
3. Cooking Tips 15
Tips on Cooking with the Timer 15
General Oven Tips 15
4. Cooking Table 16
5. Cleaning Your Cooker 17
Essential Information 17
Hotplate Burners 17
Ceramic Hotplate 18
Grill 19
Control Panel and Doors 20
Ovens 20
Cleaning Table 21
6. Troubleshooting 22
7. Installation 24
Service and Spares 24
Dear Installer 25
Provision of Ventilation 25
Location of Cooker 25
Conversion 25
Location of Cooker 26
Conversion 26
Positioning the Cooker 27
Moving the Cooker 27
Fitting the Stability Bracket and Chain 28
Repositioning the Cooker Following
Connection 29
Conversion to Another Gas 29
Fitting the Handles and Handrail 29
Levelling 29
Gas Connection 30
Pressure Testing 30
Electrical Connection 31
Final Checks 32
Final Fitting 32
Customer Care 32
8. Conversion to LP Gas 33
Injectors 33
Tap Adjustment 33
Set the Governor 34
Pressure Testing 34
Ax Label 34
9. Servicing 35
10. Circuit Diagram 42
11. Technical Data 43
Contents
Classic Deluxe 110 DF (Australia) U110289-01B
1
Thank you for buying a Falcon cooker. It should give you
many years of trouble-free cooking if installed and operated
correctly. It is important that you read this section before
you start, particularly if you have not used a dual fuel cooker
before.
This appliance is designed for domestic cooking
only. Using it for any other purpose could invalidate
any warranty or liability claim. In particular, the
oven should NOT be used for heating the kitchen –
besides invalidating claims this wastes fuel and may
overheat the control knobs.
Certain types of vinyl or laminate kitchen furniture
are particularly prone to heat damage and
discolouration. We cannot accept responsibility
for damage caused by normal use of the cooker
to any material that de-laminates or discolours
at temperatures less than 70 °C above room
temperature (as measured by EN30 / EN60335).
Installation and Maintenance
The installation must be in accordance with the relevant
instructions in this booklet, with the relevant national and
local regulations, and with the local gas and electricity supply
companies’ requirements.
Make sure that the gas supply is turned on and that the
cooker is wired in and switched on (the cooker needs
electricity).
Set the clock to make sure that the oven is functional – see
the relevant section in this manual.
The cooker should be serviced only by a qualied service
engineer, and only approved spare parts should be used.
Always allow the cooker to cool and then switch it o at the
mains before cleaning or carrying out any maintenance work,
unless specied otherwise in this guide.
Peculiar Smells
When you rst use your cooker it may give o an odour. This
should stop after use.
Before using for the rst time, make sure that all packing
materials have been removed and then, to dispel
manufacturing odours, turn the ovens to 200 °C and run for at
least an hour.
Make sure the room is well ventilated to the outside air
(see ‘Ventilation’ below). People with respiratory or allergy
problems should vacate the area for this brief period.
If You Smell Gas
• DO NOT turn electric switches on or off
• DO NOT smoke
• DO NOT use naked flames
• DO turn off the gas at the meter or cylinder
• DO open doors and windows to get rid of the gas
• DO keep people away from the area affected
• Call your gas supplier
Ventilation
The use of a gas cooking appliance results in the production
of heat and moisture in the room in which it is installed.
Therefore, make sure that the kitchen is well ventilated: keep
natural ventilation holes open or install a powered cooker
hood that vents outside. If you have several burners on, or
use the cooker for a long time, open a window or turn on an
extractor fan.
Personal Safety
DO NOT modify this appliance.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
WARNING: The appliance and its accessible parts
become hot during use and will retain heat even
after you have stopped cooking. Care should be
taken to avoid touching heating elements. Children
less than 8 years of age shall be kept away unless
continuously supervised.
DO NOT use a steam cleaner on your cooker.
CAUTION: A long term cooking process has to be
supervised from time to time. A short term cooking
process has to be supervised continuously.
Danger of re: DO NOT store items on the cooking
surfaces.
To avoid overheating, DO NOT install the cooker
behind a decorative door.
Accessible parts will become hot during use and will
retain heat even after you have stopped cooking.
Keep babies and children away from the cooker and
never wear loose-tting or hanging clothes when
using the appliance.
Always be certain that the controls are in the OFF
position when the oven is not in use, and before
attempting to clean the cooker.
1. Before You Start...
