Sida 1/2
• Transportation terminals, clubs, auditoriums,
theatres, gyms, houses of worship
• Background music/announcements: restaurants,
pubs, ecc...
• School and corporate audio visual sound
reinforcement
• Live sound PA system or live sound monitor
• DJ system
• Completely manufactured in Italy
• 1" exit throat HF compression driver
• 10" LF woofer / 2" voice coil
• Sturdy gas-injected polypropylene molded enclosure
• Processed 2-way active loudspeaker
• 2 x M10 suspension points, 1.38" top-hat speaker
stand socket, wall bracket mount flange plate
• DSP with 4 EQ presets
• Stage monitor angling facility with 12°, 40°, 55° taper
The FBT JMaxX 110A two way active reinforcement speaker system shall incorporate 1 x 10" LF woofer with 2" voice coil and 1" exit
throat HF compression driver with 1" voice coil coupled to a 90°H x 60°V constant directivity horn. Thanks to the asymmetrical shape
also allows use as a stage floor monitor at 12°, 40°, 55°. The FBT JMaxX 110A shall meet the following performance criteria:
frequency response of 58Hz to 20kHz, maximum SPL of 129.5 dB, 700W RMS + 200W RMS Class D power amplifiers. The FBT
JMaxX 110A provides a DSP with 4 factory equalization presets. With its eye-catching gas-injected forms designed to virtually
eliminate undesired enclosure resonance and reinforce strong low frequency performance, The FBT JMaxX providing a myriad of
possibilities for bands, DJ and solo artists. A front face steel grille protects the woofer fro external damage. The control panel provides
XLR/Jack input, XLR link, level, preset switch, HP filter button, line/mic button, two status led (PRT-LIMITER / ON). The two M10 fly
points built into the cabinet, along with the optional mounting bracket, allow the The FBT JMaxX 110A speaker to be surface mounted
on walls or ceilings and standard 1.38" speaker stand socket, allow the The FBT JMaxX 110A to be mounted on speaker stand.
PEAK SPL: free space, based on max power amp rating and system peak sensitivity, 10mS time average
CONT SPL: free space, based on power amp rating and LF transducer average sensitivity data, 125mS time average
MAX PEAK: based on max peak output voltage and nominal speaker impedance
MAX: 2mS burst, RMS power on nominal speaker impedance
Dispersion
Crossover Frequency
Maximum SPL (cont / peak)
Nominal Power Requirement
Power Consumption
Input Impedance
Frequency Response
Buil-in Amplifiers LF / HF
System Type
max.: 700/200W RMS
max. peak: 1400/400W
58Hz 20kHz
2-way
22kOhm
123.5 / 129.5dB
220-230Vac
600W
1.8kHz
90°H x 60°V
Power Cord
Enclosure Material
Shipping Weight
Net Weight
Shipping Dimensions (WxHxD)
Net Dimensions (WxHxD)
Input Connectors
High Frequency Driver
Low Frequency Woofer
XLR / Jack
polypropylene
29.8 lb
15.7 x 24.8 x 14.2 inch
24.2 lb
12.6 x 21.6 x 10.8 inch
16.4 ft
10" / 2" coil
1" / 1" coil
220 - 230 V
50/60 Hz
T4A - 250 V
Power Consumption 600W
Replace fuse with same type and rating.
PRT / LMT
ON
IN LINK
LINE
MIC
HP FILT
0
+6dB line
+36dB mic
4
123
1 - ORIGINAL
2 - FLOOR / VOCAL
3 - BOOST / LOUNGE
4 - CLUB / DJ
PRESET
J
MaxX
110A
ON
1 - SHIELD
2 - HOT
3 - COLD
MADE IN ITALY
TO PREVENT RISK OF FIRE OR ELECTRIC SHOCK
DO NOT REMOVE COVER ( OR BACK )
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
THIS APPARATUS MUST BE EARTHED
NEVER EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
BEFORE CONNECTING THE APPARATUS TO THE MAINS
MAKE SURE THE SUPPLY VOLTAGE MATCHES THE ONE INDICATED
STATUS
PROCESSED 2-WAY ACTIVE LOUDSPEAKER
