OPTIMAX 25 OV
wall-mounting,
pre-mixed
condensing gas boiler
INSTRUCTIONS FOR USE INSTALLATION AND MAINTENANCE
cod. 3544708/3 - 08/2004
Optimax 25 OV
2
IMPORTANT
Your “benchmark” Installation, Commissioning and Service Record Log Book will be enclosed in
your customer information pack.
“This record must be completed and left with the end user”.
Ferroli is a member of the Benchmark initiative and fully supports the aims of the programme.
Benchmark has been introduced to improve the standards of installation and commissioning of central
heating systems in the UK and to encourage the regular servicing of all central heating systems to
ensure safety and effi ciency.
Please see installation and servicing guidelines.
• Read the warnings given in this manual thoroughly.
They provide important information for safe instal-
lation, use and maintenance
• Keep the manual carefully for future consultation.
• The instruction manual is an integral and essential
part of the product and must be kept safely by the
user.
• If the appliance is sold or transferred to another
owner or if the owner moves, leaving the appliance
behind, always ensure that the manual is kept with
the appliance for consultation by the new owner
and /or installer.
• Incorrect installation or poor maintenance absolves
the manufacturer from all liability for damage to
people or property.
• Installation and maintenance must be carried out
in conformity with current legislation, according
to the manufacturer’s instructions and by qualifi ed
personnel.
• Before cleaning or maintenance, disconnect the
appliance from the mains via the switch on the
appliance or a suitable isolating device.
• In the event of malfunction or faulty operation, switch
off the appliance. Do not attempt to repair or carry
out any other operation on the appliance directly.
Contact qualifi ed personnel only.
• Repairs or the replacement of components must be
carried out exclusively by qualifi ed personnel using
original spare parts only. Failure to respect the above
my compromise the safety of the appliance.
• To guarantee effi cient operation, the appliance must
be serviced once a year by an authorised service
centre.
• The appliance may not be used for purposes other
than those for which it was explicitly designed. Any
other use is considered improper and therefore dan-
gerous.
• Incorrect installation and use or failure to follow the
instructions provided by the manufacturer absolve
the manufacturer from all liability for damage.
• After unpacking, check that the contents are complete
and undamaged.
• Keep packing out of reach of children as it is poten-
tially hazardous.
• To clean external parts, use a damp cloth moistened
with soapy water if necessary. Avoid using abrasive
cleaning products and solvents.
This symbol indicates and is placed next to all safety warnings. Carefully “Caution”
follow these instructions in order to avoid danger and damage to persons, and or
property.
This symbols calls attention to a note or an important notice for the installer/service
engineer.
Declaration of conformity
Manufacturer: FERROLI S.p.A.
Address: Via Ritonda 78/a 37047 San Bonifacio VR Italy
declares that this unit complies with the following EU directives:
• Gas Appliance Directive 90/396
• Efficiency Directive 92/42
• Low Voltage Directive 73/23 (amended by 93/68)
• Electromagnetic Compatibility Directive 89/336 (amended by 93/68)
President and Legal Representative
Cav. del Lavoro
Dante Ferroli
Optimax 25 OV
3
1. OPERATING INSTRUCTIONS..................................................................4
1.1 Introduction.............................................................................................................4
1.2 Control panel ..........................................................................................................5
1.3 Turning ON and OFF ..............................................................................................6
1.4 Adjustments............................................................................................................6
1.5 Maintenance............................................................................................................7
1.6 Faults.......................................................................................................................7
2. INSTALLATION .......................................................................................8
2.1 General Instructions................................................................................................8
2.2 Boiler location .........................................................................................................9
2.3 Water connections ................................................................................................10
2.4 Connection to the gas system..............................................................................13
2.5 Electrical Connections ..........................................................................................13
2.6 Flue system ...........................................................................................................16
2.7 Condensate outlet connection .............................................................................22
3. SERVICE AND MAINTENANCE............................................................24
3.1 Adjustments..........................................................................................................24
3.2 System start-up .....................................................................................................25
3.3 Maintenance..........................................................................................................26
3.4 Troubleshooting ....................................................................................................28
4 TECHNICAL CHARACTERISTICS AND DATA.........................................30
4.1 Dimensions and connections ................................................................................30
4.2 General view and main components ....................................................................31
4.3 Hydraulic diagram.................................................................................................32
4.4 Technical data table ..............................................................................................33
4.5 Wiring diagram .....................................................................................................34
