The FLIR A6260 camera sets the standard for SWIR cameras
for science and R&D applications by pairing high-speed
performance with fully customizable features. The high-
resolution detector offers improved sensitivity and linearity
across the full dynamic range, making it ideal for radiometry
and temperature calibrated applications. This camera also
records full-frame data at 180 fps and synchronization with
other instruments for stop-action recording on high-speed
events.
www.ir.com/science
S W I R P E R F O R M A N C E C A M E R A
FLIR A6260™
ADJUSTABLE FRAME
RATES & TRIGGERING
Ensure the camera is congured perfectly for your
testing needs
HIGH QUALITY SWIR IMAGES
Capture high-resolution, high-sensitivity images in
both bright and low-light scenes
The A6260 offers full customization of all settings,
including integration time and frame rate, so you can
tailor the controls to each unique application.
Synchronize and trigger the camera with external
events and devices, for maximum exibility. The
A6260 also provides a built-in at eld shutter that
can be either manually or automatically controlled
for spatially-uniform image quality.
The A6260 is equipped with an indium gallium
arsenide (InGaAs) detector optimized to the 0.9 – 1.7
μm or 0.6 – 1.7 μm waveband, which produces crisp,
640 x 512 pixel images. The sensor includes three
user selectable gain states offering a 75x gain
factor, making it an exceptionally exible tool for
imaging both bright objects (laser beam proling)
and low light scenes (nightglow imaging).
TEMPERATURE CALIBRATION
& MEASUREMENT
Measure thermal transients and temperature data
across a wide range*
When optimized for the 0.9 – 1.7 μm waveband, the
A6260 can be factory- or user-calibrated to measure
temperatures above 400°C. Couple this with the
ability to see through materials such as glass, and
the A6260 becomes a perfect tool for high
temperature thermal measurement in an oven,
furnace, or environmental chamber.
*A6261 model only
On/Off switch
Status LEDs
Power in
Cat 6 Ethernet port
Sync Video port
AUX port
Equipment described herein is subject to US export
regulations and may require a license prior to export.
Diversion contrary to US law is prohibited. Imagery for
illustration purposes only. Specications are subject to
change without notice. ©2019 FLIR Systems, Inc. All
rights reserved. 01/28/19
18-2816-INS-A6260
CORPORATE
HEADQUARTERS
FLIR Systems, Inc.
27700 SW Parkway Ave.
Wilsonville, OR 97070
USA
PH: +1 866.477.3687
BOSTON
FLIR Systems, Inc.
9 Townsend West
Nashua, NH 03683
USA
PH: +1 866.477.3687
LATIN AMERICA
FLIR Systems Brasil
Av. Antonio Bardella, 320
Sorocaba, SP 18085-852
Brasil
PH: +55 15 3238 8070
CANADA
FLIR Systems, Ltd.
920 Sheldon Court
Burlington, ON L7L 5K6
Canada
PH: +1 800.613.0507
www.ir.com
NASDAQ: FLIR
Specications are subject to change without notice. For the most up-to-date specs, go to www.ir.com
Image and Optical Data A6261 A6262
Temperature Range 400°C to 1200°C
(752°F to 2192°F)
NA
Optional Temperature Range Up to 1,500°C (2,732°F),
Up to 2,200°C (3992°F)
NA
Available Lenses 16 mm, 25 mm, 35 mm, 50
mm, 100 mm
25 mm
Sensor Material FLIR indium gallium
arsenide (InGaAs)
FLIR backside-thinned
indium gallium arsenide
(VisGaAs)
System Overview
IR Resolution 640 x 512
Detector Pitch 15 µm
Spectral Range 0.9 - 1.7 µm or 0.6 - 1.7 µm
Noise (NEI) Low Gain: 8.35E9 photons/sec/cm 2
Medium Gain: 2.89E9 photons/sec/cm2
Quantum Efciency >60% from 1 to 1.6 μm
Well Capacity Low Gain: 1.44 M electrons
Medium Gain: 95.7 K electrons
High Gain: 19.1 K electrons
Operability 99.5% (99.8% typical)
Electronics/Imaging
Sensor Temperature 30°C (TEC Stabilized)
Readout Snapshot
Readout Modes Asynchronous integrate while read
Asynchronous integrate then read
Synchronization Modes Sync In, Sync Out, Trigger In
Integration Time 50 µsec to full frame
Frame Rate (Full Window) Programmable 0.0015 Hz to 180 Hz (GigE limited)
Subwindow Modes User-dened size, centered in image
Max. Frame Rate 17,781 Hz (32 x 4 window)
Dynamic Range 14-bit
Digital Data Protocol GigE Vision ® 2.0
Analog Video NTSC, PAL
Command & Control GenICam
S P E C I F I C A T I O N S
Optics
Camera f/Number Lens dependent
Focus Manual
Filtering 25.4 mm diameter by 1 mm thick lter mount, behind
the lens
Analog Video
Analog Palettes Selectable 8-bit
AGC Manual, Linear, Plateau Equalization, DDE
Zoom Video zoom is auto-selected: 1x for full and 1/2 window,
2x for 1/4 window
General
Operating Temperature Range 0°C to 45°C (32°F to 113°F)
Shock/Vibration 40g,11msec½sinepulse/4.3gRMSrandom vibra-
tion, all 3 axes
Power 24 VDC (<22 W steady state)
Weight w/o Lens 5 lbs
Size (L x W x H) w/o Lens, Handle 21.6 x 10.2 x 10.9 cm (8.5 x 4.0 x 4.3 in)
Mounting 2 x 1/4”–20, 1 x 3/8”–16, 4 x 10/24
