Introduction

The Fluke 700PDX Series Pressure Modules measure

positive and negative pressure. The 700PVX modules

measure vacuum. The 700PDX modules work with the Fluke

700 Series Documenting Process Calibrators. The 700PVX

modules work only with the 740 Series Calibrators. Read this

sheet before you use the pressure module. This sheet

contains specifications and information about how to avoid

damaging the pressure module. See the calibrator’s Users

Manual for operating instructions.

Note

If you are using a Fluke-701 or Fluke-702, software

V1.3 or higher is required. See specification

footnote 1.

The pressure module measures pressure or vacuum using

an internal microprocessor. It receives operating power from

and sends digital information to the calibrator.

Gage pressure modules have one pressure fitting and

measure pressure with respect to atmospheric pressure.

Differential pressure modules have two pressure fittings and

measure the difference between the applied pressure on the

high fitting versus the low fitting. A differential pressure

module functions like a gage module when the low fitting is

open.

700 Series Dual-Range and

Vacuum Pressure Modules

Instruction Sheet

Box Contents

Pressure module, strap, 1/4 NPT to 1/4 ISO metric adapters

(one for gage, two for differential), and instruction sheet.

Protecting Yourself from Pressure Releases

To avoid a violent release of pressure in a pressurized

system, shut off the isolation valve and slowly bleed off the

pressure before you attach or remove the pressure module

from the pressure line.

Avoiding Overpressure Damage

Applying pressure in excess of the BURST PRESSURE

specified on the pressure module can destroy the pressure

module. Burst pressure is 3X full scale.

Table 1. Specifications 1

Model Range2Gage or

Differential

Isolated

Nonisola

Fluke-700PD2 -1 to 1.0000 psi

-6.89 to 6.8900 kPa

-6.89E-2 to 6.89 E-2 bar

Differential Isolated

Fluke-700PD3 -5 to 5.0000 psi

-34 to 34.000 kPa

-0.34 to 0.3400 bar

Differential Isolated

Fluke-700PD4 -15 to 15.000 psi

-100 to 100.00 kPa

-1 to 1.0000 bar

Differential Isolated

Fluke-700PD5 -15 to 30.000 psi

-100 to 200.00 kPa

-1 to 2.0000 bar

Gage Isolated

Fluke-700PD6 -15 to 100.00 psi

-100 to 700.00 kPa

-1 to 7.0000 bar

Gage Isolated

Fluke-700PD7 -15 to 200.00 psi

-100 to 1400.0 kPa

-1 to 14.000 bar

Gage Isolated

Fluke-700PV3 0 to -5.0000 psi

0 to -34.000 kPa

0 to -0.3400 bar

Differential Isolated

Fluke-700PV4 0 to -15.000 psi

0 to -100.00 kPa

0 to -1.0000 bar

Differential Isolated

1. Use of the pressure zero function is required to achieve these specifications

or Fluke 702 V1.0, V1.1, or V1.2 Calibrator. (PV3 and PV4 not compatible w

2. Available pressure units (psi, kPa, bar, inHg, mmHg, inH

20, ftH20, kg/cm2, mm

3. Accuracy specifications apply for 1 year for full span from 0 °C to 50 °C. Typ

4. Maximum non-destructive pressure: 3X maximum rated pressure, including

5. Maximum common mode pressure: 3X maximum rated pressure.

6. Specifications reflect a confidence interval of 95%.

Avoiding Corrosion Damage

To avoid damaging the pressure module from corrosion, use it

only with specified media as shown below:

• Isolated: any medium that is compatible with type 316

stainless steel on the high side. Use dry, noncorrosive

gasses only on the low side.

• Nonisolated: dry, noncorrosive gasses only.

Recommended Measurement Technique

For best results, it is recommended that the module be

pressurized to full scale and then vented to zero pressure

(atmosphere) prior to zeroing and making measurements.

Note

Low range pressure modules may be sensitive to

gravity. For best results, pressure modules 30

psi and below should be held at the same

physical orientation from the time they are

zeroed until the measurement is complete.

Pressure Calibration Kit

The Fluke-700PCK Pressure Calibration Kit makes it possible

to calibrate pressure modules at ambient temperature with a

precision pressure calibrator or dead weight tester at least 4X

better than the module specification. A 386 or better PC and

Windows® 3.1 are required. The kit is an optional accessory

available from your distributor or Fluke.

Performance Test

If you need to check that the pressure module meets its

accuracy specification, use a dead weight tester or suitable

pressure calibrator. The accuracy of the dead weight tester or

pressure calibrator should be at least 4X better than the

module’s pressure specification. Proceed as follows to verify

that a pressure module is operating within specification:

1. Read the pressure value with no externally applied

pressure to make sure the 0% of scale is correct. When

reading the pressure with a 700 Series calibrator, press

the ZERO key to remove any zero offset.

Note

If you are using a Fluke-701 or Fluke-702, the

pressure ZERO function is available only with V1.3 or

higher software. Contact your Fluke Service Center

for upgrade of earlier calibrators.

2. Connect the pressure module to a dead weight tester.

3. Choose pressure test values that give approximately 20%

of full span steps.

4. Set the dead weight tester to each of these pressures and

verify that each reading is within the specification in

Table 1. Percent of full span is calculated as follows:

100% x (reading - dead weight tester setting) / (top of

span - bottom of span).

5. If temperature sensitivity is of concern, repeat steps 1

through 4 at various controlled temperatures.

Certifications

P Conforms to European Standard EN61010-1, EN61326.
