INSTRUCTION MANUAL
1
EN
Introduction
The all-new FMS 1:18 Cruiser perfectly captures essence of the original design of Land Cruiser design while boldly
evolved to a new style of "Be Pioneer, Go Adventure" style.
FMS 1:18 Cruiser, as an officially licensed detailed scale replica, also represents a strengthened off-road vehicle with
splendid realistic details, from widened wheel-brows on both sides, right waders, to heavy-duty front wading bumper;
from hard-shell body with classic yellow and white paint scheme, full-scale interior cockpit, center console and seats,
to the scale luggage rack and three front wipers, footrests, etc.
Cruiser, as FMS always did, demonstrated impressed LED lighting function by adopting the most detailed features with
all transparent lights equipped and scale linkage-function light controls delicately embodied, including headlights, turn
signals and reverse lights. Barely no other cars can compete with Cruiser in reserving light controls for search lights on
the bumper, the fog lights on both sides and the turn signals on the rearview mirror.
A feature-packed trail-proven chassis drives the Cruiser. Aluminum rails provide a rigid platform while a multilink
geometry with panhard bar chassis design allows for maximum axle articulation.Power is delivered from the super
high-torque gearbox to ultra grippy beadlock tires via nylon driveshafts.We are proud to announce that Cruiser’s
wheels can match all tires of the same scale, making it easy for players to DIY.
Power-packed electronics consists of independent servo, 2-in-1 receiver/ESC, 050 motor and 7.4V 380mAh battery;
Allowing for high power-to-weight ratio and all weather operations.
FMS 1:18 Cruiser, see the difference and bring it home.
Transmitter intruction
F.Reset
REV/ST
Angle
A/B Mode
CH5/Climbing
CH4/Train CH6
ON/OFF
ST TRIM
+
--
TH TRIM
+/LED
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[10]
[11]
[8]
[9]
2
EN
[1]
[9]
[2]
[10]
[3]
[11]
[4]
[5]
[6]
[7]
[8]
A/B Mode switch key
Re-set button（F.Reset）Mode A
Steering Trim+（ST TRIM+）Mode A
Steering Trim-（ST TRIM-） Mode A
Power Switch
Reverse key mode a
/ steering angle limit mode B
Throttle trim + (TH TRIM +) mode A / light control switch 1 mode B
Throttle trim
-
(TH TRIM
-
) mode A / light control switch 2 mode B
Channel 6 (reserved)
Steering wheel
Throttle trigger
F.Reset
REV
ST TRIM
TH TRIM
LED
In the use of the
disorder settings, not
back to the normal
state, you can use
Factory.Reset function
A/B mode function toggle switch
After replacing the
steering gear, the
steering gear is
reversed
After replacing the
motor, there is a
reverse
Adjust 30 / 50 /
100% steering
radian
When the steering
center is not centered
When the throttle is
not centered
Light setting
Make sure that the mode function toggle switch is in mode A, hold the
steering wheel left or right, and click the F. Reset button at the same time.
After two clicks, it means that the factory settings have been completed.
Make sure that the mode function toggle switch is in mode A, twist the
left or right steering wheel, and click Rev button at the same time. After
ringing, it means that the reverse setting of steering gear has been
completed.
Make sure that the mode function toggle switch is in mode B, and click
the ST Angle key. After a click, it means that the 30% steering radian
has been set. Click the ST Angle button again, and you will hear two
beeps, indicating that the setting of 50% steering radian has been
completed. Click the ST Angle button again, and you will hear three
beeps, indicating that the 100% steering radian has been set. Then click
to cycle to a click to indicate that the 30% steering radian has been set.
Make sure that the mode function toggle switch is in mode A, pull or
push the throttle, and click Rev button at the same time. After ringing, it
means that the motor reverse setting has been completed.
Make sure that the mode function toggle switch is in mode A, press ST
TRIM+ or - button to fine tune the steering center. Every click of the
button will ring. When the maximum and minimum values are reached, a
long sound will appear. When the median value is reached, it will ring
twice.
Make sure that the mode function toggle switch is in mode A, press TH
TRIM + / - button to fine tune the throttle center. Every click of the
button will ring. When reaching the maximum and minimum value, the
button will ring, when reaching the median value, the button ring twice.
Make sure that the mode function toggle switch is in mode B, click the
LED button, and the headlamp will be on after a click. Then click the
LED button, and the headlight will be highlighted after two clicks.
Continue to click the LED button, and the air defense light will be on
after three rings.
