Performance
C R E A T E Y O U R S O U N D
Focal® is a trademark of Focal-JMlab®-Tel. (33) 04 77 43 57 00 - www.focal.com - Images may not conform exactly to specific product. Photos L’Atelier Sylvain Madelon - SCFG131113/1
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
ACCESS
25A4
• DFS® Cone
• Sealed or ported enclosure
10" (25cm) subwoofer
Nominal power 200W RMS
Maximum power 400W
Sensitivity (2,83V/1m) 85.45dB
Cone DFS® (Dual Fiberglass Structure)
Surround Butyl
Nom. impedance 4 Ohms
DC resistance 4.2 Ohms
VC diameter 50mm 2"
VC height 25mm 1"
Former Kapton
Layers 4
Wire Copper
Inductance 2.85mH
Xmax ± 8.5mm 05/16"
Magnet d x h 120mm x 30mm 423/32
" x 13/16"
Magnet weight 1250g 2.75 lbs
Flux density 0.8T
Gap height 8mm 05/16"
Net weight 3.5kg 7.7 lbs
PARAMETERS
Fs 23.5Hz
Vas 49.85 liters
Qts 0.506
Qes 0.562
Qms 5.059
Re 4.19 Ohms
Sd 330.06cm2
Cas 3.55E-07 m5/N
Mas 129.23kg/m4
Ras 3771.9 Ohms.ac
Cms 3.26E-04 m/N
Mms 140.79g
Rms 4.109Kg/s
Ces 908.39mF
Les 50.49mH
Res 37.72 Ohms
BI 12.45N/A
SPL 82.45 dB/W/m
SPECIFICATIONS
20 litres / 0.70 cu.ft
SUGGESTED APPLICATION
Load Volume Port Ø Port lenght F-3 (Hz)
Ported 20l-0.70cu.ft 9 cm-31/2" 35 cm-133/4" 38Hz
Ported 30l-1.05cu.ft 9 cm-31/2" 35 cm-133/4" 32Hz
Ported 35l-1.23cu.ft 9 cm-31/2" 35 cm-133/4" 31Hz
Sealed enclosure
25 litres / 0.88 cu.ft15 litres / 0.52 cu.ft
Load Volume F-3 (Hz)
Sealed 15l-0.52cu.ft 38Hz
Sealed 20l-0.70cu.ft 35Hz
Sealed 25l-0.88cu.ft 35Hz
