Installation Manual
MARINE RADAR
MODEL1835/1935/1945
SAFETY INSTRUCTIONS .............................................................................................................i
SYSTEM CONFIGURATION ........................................................................................................ii
EQUIPMENT LISTS.....................................................................................................................iii
1. HOW TO INSTALL THE SYSTEM ...................................................................................... 1-1
1.1 Display Unit ................................................................................................................. 1-1
1.2 Antenna Unit for MODEL1835..................................................................................... 1-3
1.3 Antenna Unit for MODEL1935/1945............................................................................ 1-9
2. CABLE CONNECTION......................................................................................................... 2-1
2.1 Standard Connection................................................................................................... 2-1
2.2 Data Signal Port .......................................................................................................... 2-2
3. HOW TO SET THE EQUIPMENT ......................................................................................... 3-1
3.1 How to Set the Language............................................................................................ 3-1
3.2 How to Set the Purpose ............................................................................................. 3-2
3.3 How to Enter the Initial Settings .................................................................................. 3-3
4. OPTIONAL EQUIPMENT ..................................................................................................... 4-1
4.1 ARP Kit ARP-11........................................................................................................... 4-1
4.2 Connection of Buzzer and/or Remote Display............................................................. 4-4
PACKING LISTS.......................................................................................................................A-1
OUTLINE DRAWINGS..............................................................................................................D-1
INTERCONNECTION DIAGRAMS........................................................................................... S-1
www.furuno.co.jp
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
www.busse-yachtshop.de | info@busse-yachtshop.de
i
SAFETY INSTRUCTIONS
WARNING
Radio Frequency
Radiation Hazard
Do not open the equipment
unless totally familiar with
electrical circuits and
service manual.
Only qualified personnel
should work inside the
equipment.
Wear a safety belt and hard
hat when working on the
antenna unit.
Serious injury or death can
result if someone falls from
the radar mast.
WARNING
Construct a suitable service platform
from which to install the antenna unit.
Serious injury or death can result if some-
one falls from the radar mast.
Turn off the power at the mains switch-
board before beginning the installation.
Fire, electrical shock or serious injury can
result if the power is left on or is applied
while the equipment is being installed.
ELECTRICAL
SHOCK
HAZARD
Observe the following compass safe
distances to prevent deviation of a
magnetic compass.
Standard Steering
Display unit
0.45 m 0.30 m
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
Ground the equipment to
prevent electrical shock and
mutual interference.
M1835 Antenna unit
0.90 m 0.70 m
MODEL
Distance to
100 W/m
2
point
Distance to
10 W/m
2
point
MODEL1835
M1935 Antenna unit
M1945 Antenna unit
Unit
1.00 m
1.00 m
0.75 m
0.75 m
MODEL1935
MODEL1945
Worse case
0.1 m
Worse case
0.2 m
Worse case
0.2 m
Worse case
2.2 m
Worse case
2.4 m
Worse case
2.2 m
Note: If the antenna unit is installed at a
close distance in front of the wheel house,
your administration may require halt of
transmission within a certain sector of
antenna revolution. This is possible - Ask
your FURUNO representative or dealer to
provide this feature.
The radar antenna emits
electromagnetic radio
frequency (RF) energy which
can be harmful, particularly
to your eyes. Never look
directly into the antenna
aperture from a close
distance while the radar is
in operation or expose
yourself to the transmitting
antenna at a close distance.
Distances at which RF radiation
levels of 100 and 10 W/m2 exist
are given in the table below.
www.busse-yachtshop.de | info@busse-yachtshop.de
ii
SYSTEM CONFIGURATIONS
12 - 24 VDC
Display unit
RDP-152
100/110/220/230 VAC
for M1835
External buzzer
Echo sounder
GPS navigator
AIS, etc.
Rectifier
PR-62
Remote display
: Basic configuration
Heading sensor
MODEL 1835
Antenna unit
RSB-0071-057
Echo sounder
GPS navigator
AIS, etc.
ECONOMY
RANGE
TLL
GAIN
TRAILS
OFF
CENTER
TARGET
ALARM
STBY
T X
A/C S EA
A/C RAIN
CUSTOM
MENU
CANCEL
EBL VRM
HL OFF
ENTER
R
B
L
L
I
MODEL 1945
Antenna unit
XN-12A
RSB-0070/0073-059
MODEL 1935
Antenna unit
XN-10A
RSB-0070/0073-064
100/110/115/220/230 VAC
for M1935/1945
Rectifier
RU-3423
www.busse-yachtshop.de | info@busse-yachtshop.de
