www.furuno.co.jp
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
MARINE RADAR
FAR-2107/FAR-2807 SERIES
Operator’s Manual:
Fishing Vessel Specifications
The purpose of this manual is to provide the operating procedures for the functions available with
the fishing vessel specifications models (50 kW and 60 kW models) of the FAR-2107/FAR-2807
series radar. This manual is provided in addition to the Operator's Manual, which covers features
common to all radars in this radar series.
Specification type is set during installation. For details, contact a FURUNO agent or dealer.
Operation from the menu involves spinning the scrollwheel to select menu item or option then
pushing the scrollwheel or left button to confirm selection. For sake of brevity, we write "Select
XXX" (XXX=name of menu item) when you would spin the scrollwheel to make a selection and
"push the left button" when you confirm selection.
Contents
1. TARGET TRAIL FUNCTIONS................... 2
1.1 Long Trails....................................................2
1.2 Trail Color.....................................................3
1.3 Trail Color Shift.............................................4
1.4 Hiding Trails .................................................5
1.5 Trail Eraser...................................................6
1.6 Narrow Trails................................................7
1.7 Preventing True Sea Clutter Trails ...............7
2. CURSORS ................................................. 8
2.1 Crosshairs Cursor Size ................................8
2.2 Net Cursor....................................................9
2.3 Cursor Data Display ...................................11
2.4 Bearing Scale Format.................................12
3. OTHER FUNCTIONS............................... 13
3.1 Echo Display Area......................................13
3.2 Turning On-screen Boxes On/Of................14
3.3 Radar Picture Color....................................15
3.4 Bearing Reference .....................................16
3.5 VRM, Cursor Unit .......................................17
3.6 Pop-up Guidance .......................................17
4. FUNCTION KEYS (F1 - F4) .....................18
4.1 F1, F2 and F3 Keys.................................... 18
4.2 Operating the F4 Key................................. 27
5. ANCHOR WATCH ALARM......................31
6. VIDEO PLOTTER FUNCTIONS...............32
6.1 Depth Contour with Depth Indication ......... 32
6.2 Mark Settings ............................................. 33
6.3 Track Settings ............................................ 36
6.4 GPS Buoy .................................................. 41
7. ARP SYMBOLS .......................................42
8. DISPLAYING PICTURE FROM
EXTERNAL RADAR ................................43
9. MENU TREE.............................................44
2
1. TARGET TRAIL FUNCTIONS
1.1 Long Trails
The fishing vessel specifications radar provides trail lengths of 12 h, 24 h and 48 h, in
addition to the “standard” trail lengths of 15 s, 30 s, 1 min, 3 min, 6 min, 15 min, 30 min
and continuous. To select a trail length, do the following:
1. Place the cursor on the TRAIL MODE box at the bottom right-hand corner on the
screen.
2. Right-click the box to open the TRAIL
menu.
3. Select 8 TRAIL LENGTH then push the left
button.
4. Select NORMAL, 12H, 24H, or 48H as
appropriate then push the left button.
NORMAL: Trail lengths of 15 s, 30 s, 1 min,
3 min, 6 min, 15 min, 30 min and contin-
uous, selectable from the TRAIL MODE
box.
12H: Max. 12-hour trails
24H: Max. 24-hour trails
48H: Max. 48-hour trails
Note: Trail data is erased and the TRAIL
MODE box setting shows "OFF" whenever
a trail length is chosen from the menu.
5. Push the right button to close the menu.
6. If you chose the 12H, 24H or 48H trail
length, select how many minutes of trails to
show in the chosen time period, from the
TRAIL MODE box. Settings and corre-
sponding trail times are
12H: 30 minute increments
24H: 1 hour increments
48H: 2 hour increments
For example, you have selected 12H from the TRAIL menu and 30 minutes from
the TRAIL MODE box. Then, 30 minutes worth of trails are displayed over the 12-
hour time period.
Note: When 2 TRAIL GRAD is set for SINGLE, long trails (12H/24H/48H) are painted
in various colors (see section 1.2) and standard trails are painted in single color. For
long trails, select SINGLE, since MULTI paints trails in a single color.
TRUE TRAIL OFF
* Shown when 8 TRAIL LENGTH
is selected to other than "NORMAL".
[TRAIL
MENU]
1 TRAIL MODE
REL/TRUE
2 TRAIL GRAD
SINGLE/MULTI
3 NARROW TRAIL
OFF/1/2
4 TRAIL LEVEL
1/2/3/4
5 TRAIL RESTART
OFF/ON
6 TRAIL COPY
OFF/ON
7 OS TRAIL
OFF/ON
8 TRAIL LENGTH
NORMAL/12H/24H/48H
9 TRAIL HIDE*
START 00:00
END 00:00
0 [TRAIL COLOR]*
3
1.2 Trail Color
The color of target trails may be chosen from among fuchsia, maroon, red, purple,
yellow, lime, green, olive, teal, cyan, blue, and navy, when 2 TRAIL GRAD and 8
TRAIL LENGTH on the TRAIL menu are set for SINGLE and other than NORMAL,
respectively.
1. Right-click the TRAIL MODE box.
2. Select 0 [TRAIL COLOR] then push the left button.
Note: 3 TRAIL COLOR shows numbers from 1 to 12 and the color currently
selected for each number. Trail color changes at intervals according to trail length
setting as follows:
12 hour trails: Trail color changes once every hour.
24 hour trails: Trail color changes once every two hours.
48 hour trails: Trail color changes once every four hours.
The color of the track will change in the color order specified here when 3 COLOR
SHIFT (see the next page) is activated. These colors can be changed by con-
tinuing this procedure.
3. Select 3 TRAIL COLOR then push the left button. The cursor is choosing color
number 1.
4. Select color desired then push the left button.
5. Set colors for other numbers similarly. (Push the left button to select color number.)
6. Push the right button three times to close the menu.
[TRAIL
COLOR]
1 BACK
2 COLOR SHIFT
NO/YES
3 TRAIL COLOR
1: FUCHSIA
2: MAROON
3: RED
4: PURPLE
5: YELLOW
6: LIME
7: GREEN
8: OLIVE
9: TEAL
10: CYAN
11: BLUE
12: NAVY
