NV SERIES
AMPLIFIER MODELS
NV−AM16001, NV−AM25001, NV−AM10002, NV−AM20004
222
NV SERIES
Embrace the ultimate in power. The NV Series is the pinnacle of modern car audio. State of the
art engineering ensures the most refined sound available is delivered at unparalleled levels. The
NV Series represents the finest work FUSION has achieved; designed and manufactured to the
highest level with no compromises.
To optimise your FUSION experience, we recommend you have your FUSION product installed
by an Authorised FUSION Dealer. Please read the warranty policy, keep your purchase receipt
and original packaging.
If after reading this manual you still have questions regarding this product, please contact
Technical Customer Services via email technical@fusionelectronics.co.nz
FUSION CULTURE
There’s no point doing something if no one notices. We’ve always believed
the way to make things happen is by getting noticed. From our product, to our
demo cars, to our events, FUSION is about making some noise.
And now you’re about to. Step out of the shadows. Announce you’ve
arrived in a world where the old limits are left behind. Where technology is
creatively combined with the latest in product innovation. Where new levels
of entertainment are delivered with outstanding performance and quality. Our
development team evolve distinctively different products; subwoofers, amplifiers,
speakers and peripherals that redefine what can be done in car audio.
Leave the old behind and push the limits of what can be achieved in car audio.
Make some noise.
For more information about FUSION Car Audio visit our website at www.fusionelectronics.com
or email technical@fusionelectronics.co.nz
3
TABLE OF CONTENTS
• AMPLIFIER FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 4
• AMPLIFIER SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 5
• AMPLIFIER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 6
• AMPLIFIER DIMENSIONS: NV-AM16001 . . . . . . . . . . . . . . . . . . . . . . . . . .pg 7
• AMPLIFIER DIMENSIONS: NV-AM25001 . . . . . . . . . . . . . . . . . . . . . . . . . .pg 8
• AMPLIFIER DIMENSIONS: NV-AM10002 . . . . . . . . . . . . . . . . . . . . . . . . . .pg 9
• AMPLIFIER DIMENSIONS: NV-AM20004 . . . . . . . . . . . . . . . . . . . . . . . . . .pg 10
• INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 11
• WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 12
• CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 13
• CONTROL DESCRIPTIONS: MONOBLOCK AMPLIFIER NV-AM16001 . . . . .pg 16
• CONTROL DESCRIPTIONS: MONOBLOCK AMPLIFIER NV-AM25001 . . . . .pg 18
• CONTROL DESCRIPTIONS: 2 CHANNEL AMPLIFIER . . . . . . . . . . . . . . . .pg 20
• CONTROL DESCRIPTIONS: 4 CHANNEL AMPLIFIER . . . . . . . . . . . . . . . .pg 22
• WIRING DIAGRAM: MONOBLOCK AMPLIFIER . . . . . . . . . . . . . . . . . . . . . .pg 24
• WIRING DIAGRAM: 2 CHANNEL AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . .pg 27
• WIRING DIAGRAM: 4 CHANNEL AMPLIFIER . . . . . . . . . . . . . . . . . . . . . . .pg 30
• TECH TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 34
• TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 37
RECORD YOUR PRODUCT DETAILS HERE:
MODEL NUMBER _______________________________ DATE OF PURCHASE______________________
AFFIX RECEIPT HERE
WARNING! Audio Systems can produce sound levels over 135dB. Continuous exposure to sound
pressure levels over 100dB may cause permanent hearing loss!
Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
RECORD YOUR PRODUCT DETAILS HERE:
MODEL NUMBER _______________________________ DATE OF PURCHASE______________________
AFFIX RECEIPT HERE
WARNING! Audio Systems can produce sound levels over 135dB. Continuous exposure to sound
pressure levels over 100dB may cause permanent hearing loss!
Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
