GE GTZ18ICESS Bruksanvisning

GE kylskåp GTZ18ICESS

Läs nedan 📖 manual på svenska för GE GTZ18ICESS (80 sidor) i kategorin kylskåp. Denna guide var användbar för 6 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/80
GEAppliances.com
Refrigerators
Top-Freezer
197D3354P013 49-60511-2 05- 12 GE
Safety Instructions . . . . . . . . . . . .2–3
Operating Instructions
Additional Features . . . . . . . . . . . . . . . . . . . . .6
Automatic Icemaker . . . . . . . . . . . . . . . . . . . .7
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Crispers and Pans . . . . . . . . . . . . . . . . . . . . . .6
Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Shelves and Bins . . . . . . . . . . . . . . . . . . . . . . . .5
Water Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Care and Cleaning
Care and Cleaning . . . . . . . . . . . . . . . . . . . .8, 9
Replacing the Light Bulbs . . . . . . . . . . . . . . .9
Installation Instructions
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . . . . . . . . . .10
Reversing the Door Swing . . . . . . . . . .14–18
Water Line Installation . . . . . . . . . . . . .11–14
Troubleshooting Tips . . . . . . .19–21
Normal Operating Sounds . . . . . . . . . . . . .19
Consumer Support
Consumer Support . . . . . . . . . . . .Back Cover
Performance Data Sheet . . . . . . . . . . . . . . .27
State of California Water
Treatment Device Certificate . . . . . . . . . . .28
Warranty for
Canadian Customers . . . . . . . . . . . . . . . . . .25
Warranty for U.S. Customers . . . . . . . . . . .26
Réfrigérateurs
Congélateur supérieur
Refrigeradores
Congelador superior
Model 18
Manuel d’utilisation
et d’installation
Owner’s Manual and
Installation Instructions Manual del propietario
e instalación
La section française commence à la page 29 La sección en español empieza en la página 53
Nota al instalador – Asegúrese de dejar
estas instrucciones con el consumidor.
Nota al consumidor –Conserve
estas instrucciones para referencia futura.
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on the gray label
on the left side, near the top of the
refrigerator compartment.
Refrigerators
Top-Freezer
Note to Installer –Be sure to leave
these instructions with the Consumer.
Note to Consumer –Keep these
instructions for future reference.
Note à l’installateur –Assurez-vous
de laisser ces instructions au consommateur.
Note au consommateur –Conservez
ces instructions pour référence future.
Instructions de sécurité...29–30
Instructions de
fonctionnement
Bacs à légumes . . . . . . . . . . . . . . . . . . . . .33
Caractéristiques additionnelles . . . . . .33
Clayettes et bacs . . . . . . . . . . . . . . . . . . .32
Distributeur . . . . . . . . . . . . . . . . . . . . . . . . .34
Filtre à eau . . . . . . . . . . . . . . . . . . . . . . . . .31
Machine à glaçons automatique . . . .34
Réglages . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Soins et nettoyage
Remplacement des
ampoules électriques . . . . . . . . . . . . . . .36
Soins et nettoyage . . . . . . . . . . . . . .35, 36
Instructions d’installation
Installation de la
conduite d’eau . . . . . . . . . . . . . . . . . .38–41
Inversion du sens
d’ouverture des portes . . . . . . . . . .41–45
Préparation à l’installation
du réfrigérateur . . . . . . . . . . . . . . . . . . . . .37
En cas de panne . . . . . . . . . .46–49
Bruits normaux
de fonctionnement . . . . . . . . . . . . . . . . .46
Soutien au consommateur
Feuillet de données relatives à la
performance de la cartouche . . . . . . . . .51
Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Soutien au consommateur . . . . . . . . . .52
Información de seguridad...53–54
Instrucciones de operación
Características adicionales . . . . . . . . . . . . . .57
Controles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Dispensador . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Estantes y compartimientos . . . . . . . . .56 –57
Filtro de agua . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Gavetas de almacenamiento . . . . . . . . . . .57
Máquina de hielos automática . . . . . . . . . .58
Cuidado y limpieza
Cómo reemplazar las bombillas . . . . . . . . .60
Cuidado y limpieza . . . . . . . . . . . . . . . . . .58–60
Instrucciones para la
instalación
Cómo invertir el vaivén de
la puerta . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65–69
Instalación de la tubería
del agua . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62–65
Preparación para instalar
el refrigerador . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Consejos para la solución
de problemas . . . . . . . . . . . . . . . . .70–74
Sonidos normales de operación . . . . . . . . .70
Soporte al consumidor
Hoja de datos de funcionamiento . . . . . . .78
Garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Soporte al consumidor . . . . . . . . . . . . . . . . . .79
Escriba aquí el modelo y el número
de serie:
Modelo # ________________________________
Serie # __________________________________
Encuentre estos números en la etiqueta gris en
el lado izquierdo, cerca de la parte superior del
compartimiento del refrigerador.
Écrivez ici le numéro de modèle et le numéro de
série :
Modèle # ______________________________
Série # ________________________________
Vous trouverez ces numéros sur l’étiquette grise
située à gauche, près du haut du compartiment
réfrigérateur.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
This refrigerator must be properly installed and
located in accordance with the Installation
Instructions before it is used.
Do not allow children to climb, stand or hang on the
shelves in the refrigerator. They could damage the
refrigerator and seriously injure themselves.
Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
In refrigerators with automatic icemakers, avoid
contact with the moving parts of the ejector
mechanism, or with the heating element located on
the bottom of the icemaker. Do not place fingers or
hands on the automatic icemaking mechanism
while the refrigerator is plugged in.
Keep fingers out of the “pinch point” areas;
clearances between the doors and between the
doors and cabinet are necessarily small. Be careful
closing doors when children are in the area.
Unplug the refrigerator before cleaning and making
repairs.
NOTE: We strongly recommend that any servicing
be performed by a qualified individual.
Setting either or both controls (some models only
have one control) to the 0 (off) position does not
remove power to the light circuit.
Do not refreeze frozen foods which have
thawed completely.
2
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding type
plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
Take off the doors.
Leave the shelves in place so that children may not
easily climb inside.
Refrigerants
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal. If you are getting rid of an old refrigeration
product, check with the company handling the
disposal about what to do.
3
GEAppliances.com
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with
a 3-prong (grounding) plug which mates with a
standard 3-prong (grounding) wall outlet to minimize
the possibility of electric shock hazard from this
appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded.
Where a standard 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly grounded 3-prong
wall outlet.
The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the wall, be
careful not to roll over or damage the power cord.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
