Sida 1/32

36″ Sealed Gas Cooktop

Installation

Instructions

CAUTION: Before you begin—read these

instructions completely and carefully.

• IMPORTANT—Save these instructions for

local inspector’s use.

• IMPORTANT—OBSERVE ALL GOVERNING

CODES AND ORDINANCES.

• Note to Installer—Be sure to leave these

instructions with the Consumer.

• Note to Consumer—Keep these instructions

for future reference.

• Note—This appliance must be properly

grounded.

PARTS INCLUDED

1/8" Drill Bit &

Electric or

Hand Drill

Phillips

Head

Screwdriver

Pencil Ruler or

Straightedge

Joint Sealant

Saber Saw

TOOLS YOU WILL NEED

Pipe Fittings

MATERIALS YOU MAY NEED

JGP636, JGP960

Shut Off

Valves

Pipe Wrench

• IMPORTANT: Leak testing of the appliance

shall be conducted according to the

manufacturer’s instructions.

229C4053P464-1

31-10505-1 (05-03 JR)

In the Commonwealth of Massachusetts:

• This product must be installed by a licensed

plumber or gas fitter.

• When using ball-type gas shut-off valves,

they shall be the T-handle type.

• A flexible gas connector, when used,

must not exceed 3 feet.

2 screws

2 Hold

Down

Brackets

Foam

Tape

Questions? Call GE Answer Center at 800.626.2000 or visit our

Website at: www.geappliances.com

WARNING!!

If the information in this manual

is not followed exactly, a fire, explosion

or gas leak may result, causing property

damage, personal injury or death.

• Installation of this cooktop must conform with

local codes or in the absence of local codes

with the National Fuel Gas Code, ANSI Z223.

1-Latest edition.

• Be sure your cooktop is installed properly by a

qualified installer or service technician.

• To eliminate reaching over surface burners,

cabinet storage above burner should be avoided.

• Do not install the unit near an outside door or

where a draft may affect its use.

Do not store or use gasoline or other

flammable vapors and liquids in the vicinity

of this or any other appliance!

STOP!

STOP!STOP!

Installation Instructions

IMPORTANT SAFETY INSTRUCTIONS

For Your Safety

• Do not try to light any appliance. Do not touch

any electrical switch; do not use any phone in

your building.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call the

fire department.

Installation and service must be performed

by a qualified installer, service agency or the

gas supplier.

This cooktop has been design certified by CSA

International. You’ll find safety precautions in

your Owner’s Manual. Read them carefully.

This Appliance must be electrically

grounded. Check with your local codes

which apply in your area. If no local codes

apply, the National Electrical Code, ANSI/

NFPA No. 70-Latest Edition must be

followed. Write to:

National Fire Protection Association

Batterymarch Park

Quincy, MA 02269

Be sure the installation of this cooktop

in a mobile home conforms with the

Manufactured Home Construction and

Safety Standard, Title 24 CFR, Part 3280.

If this standard does not apply, you must

follow the standard for Manufactured Home

Installations, ANSI A225.1 and Manufactured

Home Installations, Sites and Communities

and ANSI/NFPA 501A or with local codes.

You can get a copy of the Federal Standard

by Writing:

Office of Mobile Home Standards

HUD Building

451 7th Street, S.W.

Washington, D.C. 24010

Electrical

Requirements

WHAT TO DO IF YOU SMELL

GAS:

Remove Installation Instructions

from literature pack and read them

carefully before you begin.

Be sure to place all literature,

Owner’s Manual, Installations, etc.

in a safe place for future reference.

Make sure you have all the tools and

materials you need before starting the

installation of the cooktop.

Your home must provide the adequate

electrical service needed to safely and

properly use your cooktop. (Refer to

section on electrical requirements.)

Remove packaging materials and

literature package from the cooktop

before beginning installation.

When preparing cooktop opening,

make sure the inside of the cabinet

and the cooktop do not interfere with

each other. (See section on preparing

the opening.)

When installing your cooktop in your

home, make sure all local codes and

ordinances are followed exactly as

stated.

Pre-Installation Checklist

EASY INSTALLATION OF YOUR NEW

30" COOKTOP

Be fo re you begi n- Read the s e i ns truct ion s c omple te ly and caref ull y.

IMP ORT AN T - Save th es e ins tru ctio ns for lo cal in s pect or's us e .

IMP ORT AN T - OB SERVE ALL GOVERNI NG CODES AN D ORDI ANCE S.

No te to In st alle r- B e s ure to l eave th e se in stru ctio ns with the con s ume r.

OWNE R- Ke ep th es e ins truc tio ns for fu ture refe re nce .

No te - T h is appl iance mus t be prope rly groun ded (if applic able ).

Be fo re you begi n- Read the s e

in stru cti ons co mple tel y an d

caref u ll y.

IMP ORT AN T - Save th es e

in stru cti ons fo r local ins pe ctor' s u se .

IMP ORT AN T - OB SERVE ALL

GOVERNI NG CODE S AND ORDIAN CES.

No te to In st alle r- B e s ure to l eave

the s e i ns truc tion s with th e co ns u mer.

OWNE R- Kee p th es e ins truc tio ns

for fu ture re fere nc e.

No te - T hi s appl iance mus t be

prope rly grou nde d (if appli cable ).

FOR YOUR SAFET Y
