UseandCare Guide

Refrigerator—Freezer

K-Line Large Side by Side

and Built-In Style

General Electric Company, Appliance Park, Louisville, KY 40225 USA

Part No. 162D9616P004

Pub No. 49-60068-1

JR 5-00

Safety Instructions ........................ 2

Operating Instructions, Tips

Automatic Icemaker ..................................... 7

Electronic Monitor......................................... 5, 6

Ice and Water Dispenser ............................. 8

Refreshment Center...................................... 4

Refrigerator Doors......................................... 3

Shelves ..................................................... 9–10

Storage Drawers............................................ 9

Temperature Controls .................................. 3

Care and Cleaning

Behind Refrigerator .................................... 13

Cleaning—Inside and Outside .................. 12

Cleaning the Decorator Door Panels ..... 12

Drawer and Cover Removal ..................... 13

Light Bulb Replacement............................ 13

Under Refrigerator...................................... 12

Problem Solver...................... 22–25

Normal Operating Sounds .................... 22

Preparation

Clearances .................................................... 14

Dimensions................................................... 14

Dimensions and Specifications

for Built-In Style Models..........................15

Leveling Rollers/Door Alignment........... 15

Location......................................................... 14

Moving and Vacation................................. 14

Trim Kits................................................. 16–18

Water Supply to Icemaker........................ 14

Installation ................................. 19–21

Earthing ......................................................... 19

Electrical Requirements ............................ 19

How to Install Features.............................. 20

Additional Features .................................... 21

Mains Lead Replacement............................ 2

Model and Serial Numbers ......................... 2

HELP US HELP YOU…

Read this guide carefully.

It is intended to help you operate and maintain your new

refrigerator properly.

Keep it handy for answers to your questions.

If you received a damaged refrigerator…

Immediately contact the dealer (or builder) that sold you the refrigerator.

Save time and money. Before you request service…

Check the Problem Solver in the back of this guide. It lists minor

operating problems that you can correct yourself.

Products are continuously being improved…

Therefore product features and specications may change or

vary slightly.

Write down the model and serial numbers.

You’ll see them on a label inside the fresh food compartment

on the top.

Please write these numbers here:

Model Number

Serial Number

Use these numbers in any correspondence or service calls concerning

your refrigerator.

WARNING—When using this appliance,

always exercise basic safety precautions, including

the following:

• Use this appliance only for its intended purpose as

described in this Use and Care Guide.

• This refrigerator must be properly installed

and located in accordance with the

Installation Instructions before it is used.

WARNING—Connect to potable water

supply only.

• Never unplug your refrigerator by pulling on the

power cord. Always grip plug rmly and pull straight

out from the outlet.

• Repair or replace immediately all electric service

cords that have become frayed or otherwise

damaged. Do not use a cord that shows cracks or

abrasion damage along its length or at either the plug or

appliance end.

• When moving your appliance away from the wall, be

careful not to roll over or damage the power cord.

• Do not allow children to climb, stand or hang on the

shelves in the refrigerator. They could damage the

refrigerator and seriously injure themselves.

• If your old refrigerator is still around the

house but not in use, be sure to remove the

doors. This will reduce the possibility of danger

to children.

• After your refrigerator is in operation, do not touch

the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

• Do not place ngers or hands on the automatic ice-

making mechanism while the refrigerator is plugged

in. This will prevent contact with the moving parts of the

ejector mechanism, or with the heating element that

releases the cubes.

• Do not allow anyone to climb, sit, stand or hang on the

Refreshment Center Compartment door. They could

damage the refrigerator and maybe even tip it over,

causing severe personal injury.

• Unplug your refrigerator before cleaning and making

repairs. NOTE: We strongly recommend that any

servicing be performed by a qualied individual.

• Before replacing a burned-out light bulb, unplug the

refrigerator or turn off power at the circuit breaker or

fuse box in order to avoid contact with a live wire

lament. (A burned-out light bulb may break when

being replaced.) Turning control to NOTE: “ ”

position does not remove power to the light circuit.

• Do not store or use gasoline or other ammable

vapors and liquids in the vicinity of this or any other

appliance.

Mains lead replacement

If the mains lead on your refrigerator needs replacing at

any time, it must be replaced by a special lead which is

obtainable from your local dealer. A charge will be made

for the replacement of the mains lead if you have damaged

the lead.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using this appliance.

OPERATING YOUR REFRIGERATOR

Set the Temperature Controls (appearance may vary)

Two controls let you regulate the temperature in the fresh food and

freezer compartments.

At rst, set both the fresh food control and the freezer control to “5.”

Allow 24 hours for the temperature to stabilize, whether you are

setting the controls for the rst time or adjusting them later. Then, if

you want colder or warmer temperatures in either compartment, adjust

the controls one step at a time.

NOTE: Moving the freezer control to the

“ ”

position turns o

cooling in both compartments—fresh food and freezer—but does not

shut o power to the refrigerator.

Ambient Room Temperature Limits How to Test Temperatures

This refrigerator is designed to operate in ambient temperatures

specified by its Temperature Class which is marked on the rating plate.

Temperature Symbol Ambient Temperature

Class Maximum Minimum

Extended-

Temperate SN 32°C 10°C

Temperate N 32°C 16°C

Subtropical ST 38°C 18°C

Tropical T 43°C 18°C

NOTE: Internal temperature may be aected by such factors as the

location of the refrigerator, ambient temperature and frequency of

door openings. Adjust temperature controls as required to compensate

for these factors.

Use the milk test for the fresh food compartment. Place a container

of milk on the top shelf in the fresh food compartment. Check it a day

later. If the milk is too warm or too cold, adjust the temperature controls.

Use the ice cream test for the freezer compartment. Place a

container of ice cream in the center of the freezer compartment. Check

it after a day. If it’s too hard or too soft, adjust the temperature controls.

Always allow 24 hours for the refrigerator to reach the

temperature you set.

Important Safety Instructions Operating Your Refrigerator

Refrigerator Doors

The refrigerator doors may feel dierent than the ones you are used to.

The special door opening/closing feature makes sure the doors close

all the way and are securely sealed.

When opening and closing the door you will notice a “stop” position.

If the door is opened past this “stop” point, the door will remain open

to allow you to load and unload food more easily. When the door is

only partially open it will automatically close.

The resistance you feel at the “stop” position will be reduced as the

door is loaded with food.

When the door is only

partially open it will

automatically close.

Beyond this “stop” the

door will stay open.

Refrigerator

control

Freezer

control
