Sida 1/8

NOTE: Installation and service of this dryer

requires basic mechanical and electrical

skills. It is your responsibility to contact a

TXDOL¿HG LQVWDOOHU WR PDNH WKH HOHFWULFDO

connections.

Installation

Instructions

Electric Dryer

BEFORE YOU BEGIN

Read these instructions completely and carefully.

•

IMPORTANT- Save these instructions for local

inspector’s use.

• IMPORTANT- Observe all governing codes and

ordinances.

• Note to Installer - Be sure to leave these instructions with the

customer.

• Note to Customer - Keep these instructions with your Owner’s

Manual for future reference.

• Before the old dryer is removed from service or discarded,

remove the dryer door.

• Inspect the dryer exhaust outlet and straighten the outlet

walls if they are bent.

• Service information and the wiring diagram are located in the

control console.

• Do not allow children on or in the appliance. Close supervision

of children is necessary when the appliance is used near

children.

• Install the dryer where the temperature is above 50°F for

satisfactory operation of the dryer control system.

• Product failure due to improper installation is not

covered under the warranty.

TOOLS YOU WILL NEED

SLIP JOINT PLIERS

FLAT BLADE SCREWDRIVER

PHILLIPS SCREWDRIVER

LEVEL

TOOLS YOU WILL NEED

GLOVES

SAFETY

GLASSES

DRYER POWER

CORD KIT

(NOT PROVIDED

WITH DRYER)

4" DUCT

CLAMPS (2)

4" SPRING

CLAMPS (2)

EXHAUST

HOOD

3/4" STRAIN

RELIEF

UL RECOGNIZED

4" DIA. METAL

ELBOW

4" DIA. FLEXIBLE METAL (SEMI-RIGID)

UL LISTED TRANSITION DUCT

(IF NEEDED)

KIT WX08X10077 (INCLUDES 2 ELBOWS)

4" DIA. METAL DUCT

(RECOMMENDED)

4" DIA. FLEXIBLE METAL (FOIL TYPE)

UL LISTED TRANSITION DUCT (IF NEEDED.)

DUCT TAPE

UL RATED

120/240V,30A

WITH 3 OR 4 PRONGS.

IDENTIFY THE PLUG

TYPE AS PER THE

HOUSE RECEPTACLE

BEFORE PURCHASING

LINE CORD.

4” COVER PLATE (IF NEEDED

(KIT WE1M454)

234D2004P002 31-16308 03-13 GE

Step 1 Prepare the Area and Exhaust for Installation of

New Dryer (see section 1).

Step 2 Check and Ensure the Existing External Exhaust

is Clean (see section 1) and Meets Attached Installation

6SHFL¿FDWLRQVVHHVHFWLRQ

6WHS5HPRYHWKH)RDP6KLSSLQJ3DGVVHHVHFWLRQ

Step 4 Move the Dryer to the Desired Location.

Step 5 Connect the Power Supply (see section 2).

Step 6 Connect the External Exhaust (see section 4).

Step 7 Level Your Dryer (see section 5).

Step 8 Check the Operation of the Power Supply & Venting.

Step 9 Place the Owner’s Manual and the Installation

Instructions in a location where they will be noticed by the

owner.

For Alcove or Closet Installation, see section 6.

For Bathroom or Bedroom Installation, see section 7.

For Mobile or Manufactured Home see, section 8.

For garage installation (if allowed by local codes), see section 9.

For side or bottom exhaust, see section 10.

WARNING RISK OF FIRE

• To reduce the risk of severe injury or death, follow all

installation instructions.

• Clothes dryer installation must be performed by a

TXDOL¿HGLQVWDOOHU

• Install the clothes dryer according to these instructions

and in accordance with local codes.

• This dryer must be exhausted to the outdoors.

• Use only 4” rigid metal ducting for exhausting the

clothes dryer to the outdoors.

• DO NOTLQVWDOODFORWKHVGU\HUZLWKÀH[LEOHSODVWLFGXFWLQJ

PDWHULDOV,IÀH[LEOHPHWDOVHPLULJLGRUIRLOW\SHGXFWLV

installed, it must be UL listed and installed in accordance

with the instructions found in Connecting The Dryer To

House Vent on page 5 of this manual. Flexible venting

materials are known to collapse, be easily crushed, and

WUDSOLQW7KHVHFRQGLWLRQVZLOOREVWUXFWGU\HUDLUÀRZDQG

LQFUHDVHWKHULVNRI¿UH

• Do not install or store this appliance in any location

where it could be exposed to water and or weather.

• Save these instructions. (Installers: Be sure to leave

these instructions with the customer).

• Install the clothes dryer according to the manufacturer’s

instructions and local codes.

Questions? Call 800.GE.CARES (800.432.2737) or visit our Web site at: GEAppliances.com

In Canada, call 1.800.561.3344 or visit www.GEAppliances.ca

Installation Instructions

ELECTRICAL CONNECTION INFORMATION

Minimum Clearance Other Than Alcove or Closet Installation

Minimum clearance to combustible surfaces and for air opening are: 0 in. clearance both sides and 1 in. rear.

Consideration must be given to provide adequate clearance for installation and service.

WARNING - TO REDUCE THE

RISK OF FIRE, ELECTRICAL SHOCK AND

PERSONAL INJURY:

• DO NOT USE AN EXTENSION CORD OR AN

ADAPTER PLUG WITH THIS APPLIANCE.

Dryer must be electrically grounded in accordance with

local codes and ordinances, or in the absence of local

FRGHVLQDFFRUGDQFHZLWKWKH1$7,21$/(/(&75,&$/

CODE, ANSI/NFPA NO. 70.

CONNECTING DRYER USING 4-WIRE

CONNECTION (MUST BE USED FOR

MOBILE HOME INSTALLATION)

NOTES: Since January 1, 1996, the National Electric

code requires that the new constructions utilize a

4-wire connection to an electric dryer.

WARNING: Only a 4-conductor cord shall

be used when the appliance is installed in a location

where grounding through the neutral conductor is

prohibited. Grounding through the neutral is prohibited

for the new branch-circuit installations, mobile homes,

recreational vehicles, and areas where local codes

prohibit grounding through the neutral conduction.

1. 7XUQRȺWKHFLUFXLWEUHDNHUVDPSRUUHPRYHWKH

dryer’s circuit fuse at the electrical box.

2. Be sure the dryer cord is unplugged from the wall

receptacle.

 5HPRYHWKHSRZHUFRUGFRYHUORFDWHGDWWKHORZHUEDFN

4. 5HPRYHDQGGLVFDUGJURXQGVWUDS.HHSWKHJUHHQ

ground screw for step 7.

5. ,QVWDOOLQ8/UHFRJQL]HGVWUDLQUHOLHIWRSRZHUFRUG

entry hole. Bring power cord through strain relief.

6. Connect power cord as follows:

A. Connect the 2 hot lines to the outer screws of

the terminal block (marked L1 and L2).

B. Connect the neutral (white) line to the center of

the terminal block (marked N).

7. Attach ground wire of power cord with the green

ground screw (hole above strain relief bracket). Tighten

DOOWHUPLQDOEORFNVFUHZVVHFXUHO\

8. Properly secure power cord to strain relief.

9. 5HLQVWDOOWKHFRYHU

INTERNAL DUCT

OPENING CHECK THA T EXHAUST

HOOD DAMPER OPENS

AND CLOSES FREE LY.

WALL

TILT THE DRYER SIDEWAYS

AND REMOVE THE FOAM

SHIPPING PADS BY

PULLING AT THE SIDES

AND BREAKING THEM

AWAY FROM THE DRYER

LEGS. BE SURE TO

REMOVE ALL OF THE

FOAM PIECES AROUND

THE LEGS.

ELECTRICAL REQUIREMENTS

This dryer must be connected to an individual branch circuit,

SURWHFWHGE\WKHUHTXLUHGWLPHGHOD\IXVHVRUFLUFXLWEUHDNHUV

$ IRXU RU WKUHHZLUH VLQJOH SKDVH 9 RU 9

+]DPSFLUFXLWLVUHTXLUHG,IWKHHOHFWULFVXSSO\GRHVQRW

PHHWWKHDERYHVSHFL¿FDWLRQVWKHQFDOODOLFHQVHGHOHFWULFLDQ

GROUNDING INSTRUCTIONS

This dryer must be connected to a grounded metal, permanent

ZLULQJV\VWHPRUDQHTXLSPHQWJURXQGLQJFRQGXFWRUPXVW

be run with the circuit conductors and connected to the

HTXLSPHQWJURXQGLQJWHUPLQDORQWKHDSSOLDQFH

WARNING: NEVER LEAVE THE

COVER OFF OF THE TERMINAL BLOCK.

1PREPARING FOR INSTALLATION OF

NEW DRYER

TIP: Install your dryer before installing your washer.

This will allow better access when installing dryer

exhaust.

REMOVING LINT FROM WALL

EXHAUST OPENING

• Remove and discard existing plastic or metal

foil transition duct and replace with UL listed

transition duct.

Screws

(2)

5HPRYHJURXQGVWUDS

and discard. Keep

green ground screw

Hot

Wire

5HORFDWH

green

ground

screw

here

Green

Wire

µ8/

5HFRJQL]HG

6WUDLQ5HOLHI

$:*PLQLPXPFRSSHUFRQGXFWRUVRU9$SRZHUVXSSO\

cord kit marked for use with dryers and provided with closed loop or

spade terminals with upturned ends (not supplied).

Fuse

Hot

Wire

Neutral

(white)

Strain

5HOLHI

Bracket

Cover

Screw

Installation Instructions



CONNECTING DRYER USING 3-WIRE

CONNECTION

3-wire Connection

Not for use in Canada.

DO NOT use for Mobile Home Installations.

NOT for use on new construction.

NOT for use on recreational vehicles.

NOT for use in areas where local codes prohibit grounding

through the neutral conduction.

1. 7XUQ RȺ WKH FLUFXLW EUHDNHUV  DPS RU UHPRYH WKH

dryer’s circuit fuse at the electrical box.

2. Be sure the dryer cord is unplugged from the wall.

 5HPRYHWKHSRZHUFRUGFRYHUORFDWHGDWWKHORZHUEDFN

4. ,QVWDOOLQ8/UHFRJQL]HGVWUDLQUHOLHIWRSRZHUFRUG

entry hole. Bring power cord through strain relief.

5. Connect power cord as follows:

A. Connect the 2 hot lines to the outer screws of

the terminal block (marked L1 and L2).

B. Connect the neutral (white) line to the center of

the terminal block (marked N).

6. Be sure ground strap is connected to neutral (center)

terminal of block and to green ground screw on cabinet

UHDU7LJKWHQDOOWHUPLQDOEORFNVFUHZVVHFXUHO\

7. Properly secure power cord to strain relief.

8. 5HLQVWDOOWKHFRYHU

3 EXHAUST INFORMATION

WARNING - IN CANADA AND IN THE

UNITED STATES, THE REQUIRED EXHAUST

DUCT DIAMETER IS 4 IN (102mm). DO NOT

USE DUCT LONGER THAN SPECIFIED IN THE

EXHAUST LENGTH TABLE.

8VLQJH[KDXVWORQJHUWKDQVSHFL¿HGOHQJWKZLOO

• Increase the drying times and the energy cost.

5HGXFHWKHGU\HUOLIH

$FFXPXODWHOLQWFUHDWLQJDSRWHQWLDO¿UHKD]DUG

The correct exhaust installation is YOUR

RESPONSIBILITY. Problems due to incorrect installation

are not covered by the warranty.

5HPRYHDQGGLVFDUGH[LVWLQJSODVWLFRUPHWDOIRLOWUDQVLWLRQ

duct and replace with UL listed transition duct.

The MAXIMUM ALLOWABLE duct length and number of

bends of the exhaust system depends upon the type of

duct, number of turns, the type of exhaust hood (wall cap),

and all conditions noted below. The maximum duct length

for rigid metal duct is shown in the table below.

EXHAUST LENGTH

4" DIA.

2-1/2"

RECOMMENDED MAXIMUM LENGTH

Exhaust Hood Types

Recommended

No. of 90º

Elb ows

Rigid

Metal

Rigid

Metal

90 Feet

60 Feet

45 Feet

35 Feet

25 Feet

60 Feet

45 Feet

35 Feet

25 Feet

15 Feet

Use only for sho rt

run installations

EXHAUST SYSTEM CHECK LIST

HOOD OR WALL CAP

• Terminate in a manner to prevent back drafts or entry of

birds or other wildlife.

• Termination should present minimal resistance to the

H[KDXVWDLUÀRZDQGVKRXOGUHTXLUHOLWWOHRUQRPDLQWHQDQFH

to prevent clogging.

• Never install a screen in or over the exhaust duct. This could

cause lint build up.

• Wall caps must be installed at least 12 in. above ground

level or any other obstruction with the opening pointed

down.

SEPARATION OF TURNS

For best performance, separate all turns by at least 4 ft.

of straight duct, including distance between last turn and

exhaust hood.

TURNS OTHER THAN 90º

• One turn of 45º or less may be ignored.

• Two 45º turns should be treated as one 90º turn.

• Each turn over 45º should be treated as one 90º turn.

• For every extra 90° elbow, reduce the allowable vent system

length by 10 ft.

• Two 45° elbows will be treated like one 90° elbow.

• For the side exhaust installations, add one 90° elbow to the

chart.

• The total vent system length includes all the straight portions

and elbows of the system (transition duct included).

WARNING: NEVER LEAVE THE

COVER OFF OF THE TERMINAL BLOCK.

Screws

(2)

Green Ground Screw

& Ground Strap

Hot

Wire

µ8/

5HFRJQL]HG

6WUDLQ5HOLHI

$:*PLQLPXPFRSSHUFRQGXFWRUVRU9$SRZHUVXSSO\

cord kit marked for use with dryers and provided with closed loop or

spade terminals with upturned ends (not supplied).

Fuse

Hot

Wire

Neutral

(white)

Strain

5HOLHI

Bracket

Cover

Screw

If required, by local code, install external

ground (not provided) to grounded metal,

cold water pipe, or other established

ground determined by a qualified

electrician.

Produktspecifikationer

Varumärke:	GE
Kategori:	Torktumlare
Modell:	SensorDry GHDN520EDWS

Behöver du hjälp?

Om du behöver hjälp med GE SensorDry GHDN520EDWS ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Torktumlare GE Manualer

GE GFD55ESSN0WW Wasdror Bruksanvisning

21 Oktober 2024

GE GTDL210ED0WW Wasdror Bruksanvisning

20 Oktober 2024

GE DBXR453ET0WW Wasdror Bruksanvisning

20 Oktober 2024

GE Profile PFD95GSPTDS Bruksanvisning

16 Oktober 2024

GE SensorDry GHDN520EDWS Bruksanvisning

6 Oktober 2024

GE DMCD330GGWC Bruksanvisning

4 Oktober 2024

GE DLSR483EGWW Bruksanvisning

4 Oktober 2024

GE GLDP280GDWS Bruksanvisning

2 Oktober 2024

GE DSKS433ETAB Bruksanvisning

1 Oktober 2024

GE 7.0 cu. ft. capacity DuraDrum GTDP350EMWS Bruksanvisning

29 September 2024

Torktumlare Manualer

Nyaste Torktumlare Manualer

IFB Executive ZXB Bruksanvisning

26 Oktober 2024

Whirlpool FFT M11 8X3BY SPT Bruksanvisning

26 Oktober 2024

Whirlpool FFT CM10 8BB NA Bruksanvisning

26 Oktober 2024

Whirlpool FFT D 9X3SK EX Bruksanvisning

26 Oktober 2024

Whirlpool FFT M22 8X3B SPT Bruksanvisning

26 Oktober 2024

Whirlpool FFT M22 9X2WS EE Bruksanvisning

26 Oktober 2024

Whirlpool FFTN M11 82 SPT Bruksanvisning

26 Oktober 2024

Whirlpool FFT M22 9X2SBX GCC Bruksanvisning

26 Oktober 2024

Whirlpool W6 D94SB IT Bruksanvisning

26 Oktober 2024

Electrolux EDP2074PDW Bruksanvisning

26 Oktober 2024
