Sida 1/44
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
Owner’s Manual
Spark-Ignited Stationary Generators
Residential and Commercial
48 kW 4.5L
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(888-436-3722)
Para español , visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter : http://www.generac.com/service-support/product-support-lookup
SAVE THIS MANUAL FOR FUTURE REFERENCE
®
ii Owner’s Manual for Spark-Ignited Stationary Generators
Use this page to record important information about the generator.
For quick and easy reference, copy the information
printed on the Unit Identification Label onto the sample
label printed here. The Unit Identification Label is located
on the base frame adjacent to the front engine mount on
all models.
Always provide the complete model number and serial
number when contacting an Independent Authorized Ser-
vice Dealer (IASD) about parts and/or service.
Operation and Maintenance: Correct maintenance and
care of the unit ensures a minimum number of problems,
and keeps operating expenses at a minimum. It is the
operator’s responsibility to perform all safety inspections,
to verify all maintenance for safe operation is performed
promptly, and to have the equipment inspected periodi-
cally by an IASD. Normal maintenance, service, and
replacement of parts are the responsibility of the owner/
operator and are not considered defects in materials or
workmanship within the terms of the warranty. Individual
operating habits and usage may contribute to the need
for additional maintenance or service.
When the generator requires servicing or repairs, Gen-
erac recommends contacting an IASD for assistance.
Authorized service technicians are factory-trained and
are capable of handling all service needs. To locate the
nearest IASD, please visit the dealer locator at:
www.generac.com/Dealer-Locator.
INDEPENDENT AUTHORIZED
SERVICE DEALER LOCATION
To locate the nearest
INDEPENDANT AUTHORIZED SERVICE
DEALER,
please call this number:
1-800-333-1322
or visit the dealer locator at:
www.generac.com/Service/DealerLocator/
GENERATOR UNIT
GEN MODEL:
MODEL:
SERIAL:
ALTERNATE
PROD DATE:
COUNTRY OF ORIGIN:
GENERATOR DATA
KW KVA HZ PF
UPSIZE ALT KW KVA
VOLT / AMP
ENG RPM ALT RPM
BREAKER KW AMP
X’D X”D
ROTOR STATOR CLASS
WINDINGS @ AMBIENT TEMP
MANUF.
LOC
003564
Figure 1-1. Sample Label
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.
Owner’s Manual For Spark-Ignited Stationary Generators iii
Table of Contents
Section 1: Safety Rules & General
Information
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
Safety Rules .........................................................1
How to Obtain Service .................................................1
General Hazards ..................................................2
Exhaust Hazards ..................................................2
Fire Hazards .........................................................2
Electrical Hazards ................................................3
Explosion Hazards ...............................................3
Battery Hazards ...................................................4
Section 2: General Information
Emissions .............................................................5
Emissions Data Plate ..................................................5
Specifications ......................................................6
Engine Oil Recommendations ............................7
Weather and Maintenance Kits ...........................7
Coolant Water Treatment ....................................7
Fuel Requirements ..............................................8
Reconfiguring the Fuel System ..........................8
Change Fuel Selection ................................................8
Battery Requirements .........................................8
Battery Charger ...........................................................8
Battery Safety Precautions ..........................................8
Corrosion Protection ...........................................9
Section 3: Activation and Startup
Orientation ..........................................................11
Removing the Side Access Panels ..................11
Installing the Battery .........................................11
Opening the Viewing Window ..........................12
Activating the Unit .............................................13
Starting and Running Engine ...........................14
Operational Checks ...........................................14
Self Test ....................................................................14
Checking Manual Transfer Switch
Operation ............................................................15
Electrical Checks ............................................... 15
Testing Generator Under Load ..................................15
Testing Auxiliary Shutdown Switch Operation ...........16
Checking Automatic Operation ..................................16
Securing the Generator .................................... 16
Section 4: Operation
Control Panel ..................................................... 17
AUTO/MANUAL/OFF ......................................... 18
Menu Navigation ................................................ 18
Alarm/Warning Conditions ............................... 20
Changing Date/Time .......................................... 20
Programmable Timers ...................................... 20
Dealer Programmable ...............................................20
User Programmable ..................................................20
USB Port for Firmware Updates ....................... 20
Battery Charger ................................................. 21
Transfer Switch Automatic Operation ............. 21
Automatic Sequence of Operation ............................21
Transfer Switch Manual Operation .................. 22
Transfer to Generator Power .....................................22
Transfer Back to Utility Power ...................................22
Section 5: Maintenance
Component Locations ...................................... 23
Access Panels ................................................... 24
Removal ....................................................................24
Installation .................................................................24
Maintenance ....................................................... 24
Service Maintenance Schedule ................................. 25
Remove From Service ....................................... 26
25 Hour Break-In ................................................ 26
Daily Maintenance ............................................. 26
Schedule A Maintenance .................................. 27
Schedule A Maintenance Item Locations ..................27
Preliminary Instructions .............................................27
Inspecting the Enclosure Louvers ............................. 27
Inspecting the Fuel Lines ..........................................27
Inspecting Coolant Level and Hoses .........................27
Inspecting Radiator for Clogging ...............................27
Checking Lubricating Oil Level and Drain Hose ........ 28
Replacing Lubricating Oil and Oil Filter .....................28
