Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Box Camera
Ultra Box Camera
Arctic Box Camera
Target Box Camera
ICH265HISIV104-A-EN
© 2016 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in
part, without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note: no memory card slot or local
storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: +886-2-8797-8377
Fax: +886-2-8797-8335
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc.
October 2016
i
Contents
Contents ..............................................................................i
Caution.............................................................................. iv
Options .............................................................................. v
Note for Installing Camera Outdoor.............................. vii
Note for USB Storage and WiFi Adapter ..................... viii
Note for Silica Gel Bags ................................................ viii
Chapter 1 Box Camera .....................................................1
1.1 Packing List..............................................................................6
1.1.1 For H.265 Cameras .....................................................6
1.1.2 For H.264 Cameras .....................................................7
1.2 Features ...................................................................................8
1.2.1 Wide Dynamic Range Pro..........................................11
1.3 Overview ................................................................................12
1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D .............................................................12
1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400
Series / 2500 Series / 2600 / 2700 Series /3400 Series / 4700
Series / 5300 Series / 5700 Series / 12201..........................14
1.4 Connecting the Camera..........................................................17
1.4.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D .............................................................17
ii
1.4.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400
Series / 2500 Series / 2600 / 2700 Series / 3400 Series / 4700
Series / 5300 Series / 5700 Series / 12201 ..........................19
1.5 Accessory Installation.............................................................21
1.5.1 C-Mount Lenses.........................................................21
1.5.2 Infrared Illuminators (Optional)...................................22
1.6 I/O Terminal Block ..................................................................23
1.6.1 Pin Assignment..........................................................23
1.6.2 Connecting to GV-Relay V2 (Optional).......................24
1.7 Loading Factory Default..........................................................25
Chapter 2 IR Arctic Box Camera ...................................26
2.1 Packing List ............................................................................28
2.2 Features .................................................................................30
2.3 Overview ................................................................................32
2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /
2400-E / 3400-E / 4700-E / 5300-E......................................32
2.3.2 GV-BX2510-E / 5310-E. 33..............................................
2.4 Installation ..............................................................................34
2.5 Connecting the Camera..........................................................39
2.5.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /
2400-E / 3400-E / 4700-E / 5300-E......................................39
2.5.2 GV-BX2510-E / 5310-E..............................................41
2.6 Notice for Using the IR Arctic Box Camera .............................44
2.6.1 Enabling IR LED after Loading Default.......................45
2.6.2 Disabling Status LED under Low Light Conditions......46
iii
2.7 Loading Factory Default..........................................................47
Chapter 3 Ultra Box Camera ..........................................48
3.1 Packing List............................................................................49
3.2 Features .................................................................................50
3.3 Overview .................................................................................51
3.4 Installation ..............................................................................52
3.5 Connecting the Camera..........................................................54
3.6 55Loading Factory Default ..........................................................
Chapter 4 Target Box Camera .......................................56
4.1 Packing List............................................................................56
4.2 Features .................................................................................57
4.3 Overview ................................................................................58
4.4 Installation ..............................................................................59
4.5 Connecting the Camera..........................................................61
4.6 Loading Factory Default..........................................................62
Appendix...........................................................................63
A.Supported Lenses for Box Camera..........................................63
iv
Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Safety Notice
The GV-IPCAM uses a Lithium battery as the power supply for its internal
real-time clock (RTC). The battery should not be replaced unless required!
If the battery does need replacing, please observe the following:
Danger of Explosion if battery is incorrectly replaced
Replace only with the same or equivalent battery, as recommended by
the manufacturer
Dispose of used batteries according to the manufacturer's instructions
v
Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Device Description
Power Adapter
The power adapter is available for all Box Camera,
Ultra Box Camera, and Target Box Camera. Contact
your sales representative for the countries and areas
supported.
GV-PA191 PoE
Adapter
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over
a single Ethernet cable.
GV-PA482 PoE
Adapter
The GV-PA482 PoE adapter is designed to provide
power and network connection to GV-BX1500-E /
2400-E / 2510-E / 3400-E / 5300-E / 4700-E / 5310-
E over a single Ethernet cable.
GV-POE Switch
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
GV-Mount
Accessories
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see GV-
Mount Accessories Installation Guide on the
Software DVD.
vi
Device Description
GV-WiFi Adapter
The GV-WiFi Adapter is a plug-and-play device
designed to connect GV-BX1200 Series / 1300
series / 1500 series / 2400 series / 2500 series /
3400 series / 4700 series / 5300 series / 5700 series
and GV-MFD1501 series / 2401 series / 2501 series
/ 3401 series / 5301 series to wireless network. This
product complies with IEEE 802.11 b/g/n (Draft 3.0)
standards for wireless networking.
GV-Relay V2
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
vii
Note for Installing Camera Outdoor
When installing the IR Arctic Box Camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
3. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
viii
Note for USB Storage and WiFi
Adapter
Mind the following limitations and requirements for using USB storage and
GV-WiFi Adapter:
1. The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above.
2. The USB hard drive’s storage capacity must not exceed 2TB.
3. USB flash drives and USB hubs are not supported.
4. External power supply is required for the USB hard drive.
5. To connect a GV-WiFi Adapter, make sure it is connected before the
camera is powered on.
Note for Silica Gel Bags
1. The silica gel bag loses its effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel
bag every time you open the camera, and conceal the gel bag in
camera within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.
Box Camera
1
1
Chapter 1 Box Camera
The Box Camera is a series of indoor IP cameras consisting of fixed focal
and varifocal models in different resolutions. The Box Camera supports
lens replacement and features an automatic infrared-cut filter for day and
night surveillance. The super low lux models are capable of displaying
color live view in near darkness. Models equipped with a mini USB port
can be connected wirelessly through a GV-WiFi Adapter (optional). The
WDR Pro models can produce clear image for scenes with contrasting
intensity of lights (see 1.2.1 Wide Dynamic Range Pro for details). Models
using P-Iris allow for precise control of exposure, producing images with
better clarity and contrast. For details on related models, see 1.2 Features.
The Box Camera models are detailed below:
Box Camera
Model No. Specifications Description
GV-BX120D
Auto Iris, f:2.8 ~ 12
mm, F/1.4, 1/3” CS
Lens
1.3 MP, H.264,
Low Lux, D/N
GV-BX130D-0
Varifocal
Lens Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
1.3 MP, H.264,
D/N
GV-BX130D-1 Fixed Lens Fixed Iris, f: 4 mm,
F/1.4, 1/3’’ CS Lens
1.3 MP, H.264,
D/N
GV-BX140DW
Fixed Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
1 MP, H.264,
D/N, WDR Pro
GV-BX220D-2
Varifocal
Lens Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
2 MP, H.264,
D/N
2
Model No. Specifications Description
GV-BX220D-3 Varifocal
Lens
Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3’’ CS
Lens
2 MP, H.264,
D/N
GV-BX320D-0
Auto Iris, f:3.1 ~ 8
mm, F/1.2, 1/3” CS
Lens
GV-BX320D-1
Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
3 MP, H.264,
D/N
GV-BX520D
Varifocal
Lens
Manual Iris, f: 4.5 ~
10 mm, F/1.6, 1/2’’
CS Lens
5 MP, H.264,
D/N
GV-BX1200-0F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-0F
Fixed Lens Fixed Iris, f: 4 mm,
F/1.5, 1/3’’ CS Lens 1.3 MP, H.264,
D/N
GV-BX1200-1F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-1F 1.3 MP, H.264,
D/N
GV-BX1500-1F
1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2400-1F 2 MP, H.264,
D/N, WDR Pro
GV-BX2500-1F
2 MP, H.264,
Super Low
Lux, D/N
GV-BX3400-1F
Fixed Lens
Fixed Iris, f: 8 mm,
F/1.6, 1/2.5’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
Box Camera
3
1
Model No. Specifications Description
GV-BX1200-2F 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-2F 1.3 MP, H.264,
D/N
GV-BX1500-2F
1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2400-2F 2 MP, H.264,
D/N, WDR Pro
GV-BX2500-2F
2 MP, H.264,
Super Low
Lux, D/N
GV-BX3400-2F
Fixed Lens
Fixed Iris, f: 12 mm,
F/1.6, 1/2.5’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
GV-BX1200-3V 1.3 MP, H.264,
Low Lux, D/N
GV-BX1300-3V 1.3 MP, H.264,
D/N
GV-BX1500-3V
1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2500-3V
Auto Iris, f:2.8 ~ 12
mm, F/1.4, 1/2.7” CS
Lens
2 MP, H.264,
Super Low
Lux, D/N
GV-BX2600
Auto Iris, f:3 ~ 10.5
mm, F/1.4, 1/2.7” CS
Lens
2 MP, H.264,
Super Low
Lux, D/N,
WDR Pro
GV-BX3400-5V
Varifocal
Lens
Auto Iris, f: 2.8 ~ 6
mm, F/1.3, 1/3’’ CS
Lens
3 MP, H.264,
D/N, WDR Pro
4
GV-BX5300-6V
Manual Iris, f: 4.5 ~
10 mm, F/1.6, 1/2’’
CS Lens
5 MP, H.264,
D/N
GV-BX1500-8F
1.3 MP, H.264,
Super Low
Lux, D/N
GV-BX2500-8F
2 MP, H.264,
Super Low
Lux, D/N
GV-BX3400-8F 3 MP, H.264,
D/N, WDR Pro
GV-BX5300-8F
Fixed Iris, f: 2.8 mm,
F/1.8, 1/2.5’’ CS
Lens
5 MP, H.264,
D/N
GV-BX4700-8F
Fixed Iris, f: 2.8 mm,
F/1.8, 1/2.5’’ CS
Lens
4 MP, H.265,
Super Low
Lux, D/N,
WDR Pro
GV-BX2700-8F
Fixed Iris, f: 2.8 mm,
F/1.8, 1/2.5’’ CS
Lens
2 MP, H.265,
Super Low
Lux, D/N,
WDR Pro
GV-BX5700-8F
Fixed Lens
Fixed Iris, f: 2.95
mm, F/2.0, 1/1.8’’ CS
Lens
5 MP, H.265,
Low Lux, D/N,
WDR
GV-BX12201 Varifocal
Lens
DC drive Iris, f: 4.1 ~
9 mm, F/1.6, 1/1.8”
CS Lens
12 MP, H.264,
D/N
Box Camera
5
1
P-Iris Models
Model No. Specifications Description
GV-BX1500-3V 1.3 MP, H.264,
Super Low Lux, D/N
GV-BX2500-3V 2 MP, H.264, Super
Low Lux, D/N
GV-BX3400-3V
P-Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.5”
CS Lens
3 MP, H.264, D/N,
WDR Pro
GV-BX2700-3V
P-Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.7”
CS Lens
2 MP, H.265, Super
Low Lux, D/N, WDR
Pro
GV-BX4700-3V
P-Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.7”
CS Lens
4 MP, H.265, Super
Low Lux, D/N, WDR
Pro
GV-BX5300-6V
Varifocal
Lens
P-Iris, f: 3.3 ~ 10.5
mm, F/1.4, 1/2.5’’
CS Lens
5 MP, H.264, D/N
GV-BX5700-3V
P-Iris, f: 3.6 ~ 10
mm, F/1.5, 1/1.8”
CS Lens
5 MP, H.265, Low
Lux, D/N, WDR
6
1.1 Packing List
1.1.1 For H.265 Cameras
Box Camera
Terminal Block (2-Pin and 3-Pin)
Fixed Focal or Varifocal Megapixel Lens
Six Lens Rings (only for Varifocal Lens)
Video Out Wire
Camera Holder
Holder Screw x 2
GV-IPCAM Software DVD
GV-Software DVD
Warranty Card
Box Camera
7
1
1.1.2 For H.264 Cameras
Box Camera
Terminal Block (2-Pin and 3-Pin)
Fixed Focal or Varifocal Megapixel Lens
Six Lens Rings (only for Varifocal Lens)
Video Out Wire
Camera Holder
Holder Screw x 2
Power Adapter
GV-IPCAM Software DVD
GV-Software DVD
Warranty Card
Note: The power adapter can be excluded upon request.
8
1.2 Features
Image sensor
Camera Model Image Sensor
GV-BX120D
GV-BX1200 Series 1/3’’ progressive scan low lux CMOS
GV-BX130D Series
GV-BX1300 Series
GV-BX220D Series
GV-BX320D Series
GV-BX520D
GV-BX5300 Series
1/2.5’’ progressive scan CMOS
GV-BX1500 Series 1/3’’ progressive scan super low lux CMOS
GV-BX2500 Series
GV-BX2600
GV-BX2700 Series
1/2.8’’ progressive scan super low lux CMOS
GV-BX2400 Series
GV-BX3400 Series 1/3.2’’ progressive scan CMOS
GV-BX4700 Series 1/3’’ progressive scan CMOS
GV-BX5700 Series 1/1.8’’ progressive scan CMOS
GV-BX12201 1/1.7’’ progressive scan CMOS
Box Camera
9
1
Frame Rate
Camera Model Frame Rate
GV-BX120D
GV-BX130D Series
GV-BX1200 Series
GV-BX1300 Series
GV-BX1500 Series
Up to 30 fps at 1280 x 1024
GV-BX140DW Up to 30 fps at 1280 x 720
GV-BX220D Series
GV-BX2400 Series
GV-BX2500 Series
GV-BX2600
GV-BX2700 Series
Up to 30 fps at 1920 x 1080
GV-BX320D Series
GV-BX3400 Series Up to 20 fps at 2048 x 1536
GV-BX520D
GV-BX5300 Series Up to 10 fps at 2560 x 1920
GV-BX4700 Series Up to 25 fps at 2560 x 1440
Up to 30 fps at 2048 x 1520
GV-BX5700 Series Up to 30 fps at 2592 x 1944
GV-BX12201 Up to 15 fps at 4000 x 3000
Up to 30 fps at 3840 x 2160
Dual streams from H.264 or MJPEG
Dual streams from H.265, H.264 or MJPEG (for GV-BX2700 Series /
4700 Series / 5700 Series)
Day / Night function (with removable IR-cut filter)
Wide Dynamic Range Pro
(for GV-BX140DW / 2400 Series / 2500 Series / 2600 / 2700 Series /
3400 Series / 4700 Series
)
P-Iris for auto iris adjustment (for GV-BX1500-3V / 2500-3V / 2700-3V
/ 3400-3V / 4700-3V / 5300-6V / 5700-3V)
Defog
10
Two-way audio
One sensor input and alarm output
TV-out support
Micro SD card slot (SD/SDHC) for local storage (GV-BX2700 Series /
4700 Series / 5700 Series support SDXC card as well)
NAS recording (for Box Camera using firmware V3.0 or later)
Recording assigned by GV-Edge Recording Manager (Windows &
Mac) for Box Camera using firmware V3.0 or later
Mini USB slot for WiFi Adapter or a USB hard drive (for GV-BX1200
Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600
/ 2700 Series / 3400 Series / 4700 Series / 5300 Series / 5700 Series
only)
3D noise reduction (for GV-BX1500 Series / 2500 Series / 2600 /
2700 Series / 4700 Series / 5700 Series)
2D noise reduction (except GV-BX1500 Series / 2500 Series / 2600)
Smart streaming (for GV-BX2700 Series / 4700 Series / 5700 Series)
Motion detection
Tampering alarm
Privacy mask
Text overlay
Video Analysis (GV-BX2600 only)
IP address filtering
DC 12V and PoE (IEEE 802.3af)
Megapixel lens
Support for iPhone, iPad, Android and 3GPP
31 languages on Web interface
ONVIF (Profile S) conformant
Note: GV-BX12201 does not support the memory card and external
USB hard drive for local storage.
Box Camera
11
1
1.2.1 Wide Dynamic Range Pro
Objects may appear as silhouettes when they are backed with intense
lights. The Wide Dynamic Range Pro (WDR Pro) is designed to solve this
problem using a WDR sensor. In GV-BX140DW, GV-BX2400 Series, GV-
BX2600, GV-BX2700 Series, GV-BX3400 Series and GV-BX4700 Series,
the WDR sensor is able to process the image and show details in bright
and dark areas at the same time. An example of WDR Pro in action is
shown below.
No WDR: underexposure
WDR: perfect exposure
For GV-IPCam models that support WDR, the WDR effect is achieved
through software programming.
12
1.3 Overview
1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D
1 2 3 4 5 6
7 8 9 10
12 13
14
16
15
11
Figure 1-1
Note:
1. The Auto Iris connector (No. 7) is only functional in GV-BX120D,
GV-BX130D-0, GV-BX220D and GV-BX320D.
2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep
the Light Sensor unobscured for accurate light detection.
3. The Iris Screw (No.13) is only available for GV-BX520D.
4. The Zoom Screw (No. 15) is not available for GV-BX130D-1.
No. Name Description
1 Video Out
Connects to a portable monitor for setting the
focus and angle of Box Camera during initial
installation.
2 Memory Card
Slot
Inserts a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
Box Camera
13
1
No. Name Description
3 Audio Out Connects a speaker for audio output.
4 Audio In Connects a microphone for audio input.
5 I/O Terminal
Block For details, see 1.6 I/O Terminal Block.
6 Power LED Indicates the power is supplied. For detail, see
the table below.
7 Auto Iris
Connector Plug the iris control cable to the connector.
8 DC 12V Port Connects to power.
9 LAN / PoE Connects to a 10/100 Ethernet or PoE.
10 Default Restores the camera to the factory default. For
details, see 1.7 Loading Factory Default.
11 Light Sensor Detects light to switch between day and night
mode.
12 Focus Screw Adjusts the focus of the camera.
13 Iris Screw Adjusts the iris of the camera.
14 Microphone Records the sounds.
15 Zoom Screw Adjusts the zoom of the camera.
16 Status LED Turns on when the unit is ready for use. For
detail, see the table below.
LED Description
Power LED turns green The system powers on and succeeds to boot
up.
Status LED turns green The system is ready for use.
14
1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series /
2400 Series / 2500 Series / 2600 / 2700 Series /3400
Series / 4700 Series / 5300 Series / 5700 Series / 12201
1 2 4 5 6 7
8 9 10
3
11
12 13 14
16
15
Figure 1-2-1 Figure 1-2-2:
GV-BX1200 Series / 1300 Series / 1500
Series / 2400 Series / 2500 Series / 2600
/ 2700 Series / 3400 Series / 4700 Series
/ 5300 Series / 5700 Series
Figure 1-2-1:
GV-BX12201
Box Camera
15
1
Note:
1. The Auto Iris Connector (No. 8) is only functional for varifocal
models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 2700 /
3400 / 4700 / 5700.
2. The Iris Screw (No. 12) is only available in GV-BX5300-6V.
3. The Zoom Screw (No. 13) is only available for varifocal models of
GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 2700 / 3400 /
4700 / 5300 / 5700 / 12201.
4. The Memory Card Slot (No. 2) is currently not supported for GV-
BX12201.
5. Mini USB Slot (No. 3) connected to USB hard drive is currently not
supported for GV-BX12201.
6. Built-in microphone is not available for GV-BX2600.
No. Name Description
1 Video Out
Connects to a portable monitor for setting the
focus and angle of Box Camera during initial
installation.
2 Memory Card
Slot
Inserts a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
3 Mini USB Slot Connects to a GV-WiFi Adapter or a USB
hard drive.
4 Audio Out Connects a speaker for audio output.
5 Audio In Connects a microphone for audio input.
6 I/O Terminal
Block
Connects to I/O devices. For details, see 1.6
I/O Terminal Block.
7 Power LED Indicates the power is supplied. For detail,
see the table below.
8 Auto Iris
Connector Plug the iris control cable to the connector.
9 DC 12V Port Connects to power.
16
No. Name Description
10 LAN / PoE Connects to a 10/100 Ethernet or PoE.
11 Default Restores the camera to factory default. For
details, see 1.7 Loading Factory Default.
12 Iris Screw Adjusts the iris of the camera.
13 Zoom Screw Adjusts the zoom of the camera.
14 Microphone Records the sounds.
15 Focus Screw Adjusts the focus of the camera.
16 Status LED Turns on when the unit is ready for use. For
detail, see the table below.
LED Description
Power LED turns green The system powers on and succeeds to boot
up.
Status LED turns green The system is ready for use.
Box Camera
17
1
1.4 Connecting the Camera
The Box Camera is designed for indoor use. Please make sure the
installing site is shielded from rain and moisture.
1.4.1 GV-BX120D / 130D Series / 140DW / 220D Series /
320D Series / 520D
Figure 1-3
1. If you are using an auto iris model, plug the iris control cable to the
Auto Iris Connector on the camera.
2. Use a standard network cable to connect the camera to your network.
3. Optionally connect a speaker and an external microphone.
4. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out field on the
Web interface. See 4.1.1 Video Settings, GV-IPCam Firmware
Manual.
18
5. Optionally connect to input / output devices or an infrared illuminator.
For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block.
6. Connect power using one of the following methods:
plugging the power adapter to the power port.
using the Power over Ethernet (PoE) function and the power will
be provided over the network cable.
7. The status LED of the camera will be on.
8. You are ready to access the live view, adjust the image clarity and
configure the basics. See Getting Started, Chapter 2, GV-IPCam
Firmware Manual.
Box Camera
19
1
1.4.2 GV-BX1200 Series / 1300 Series / 1500 Series /
2400 Series / 2500 Series / 2600 / 2700 Series / 3400
Series / 4700 Series / 5300 Series / 5700 Series / 12201
Figure 1-4
1. If you are using an auto iris model, plug the iris control cable to the
Auto Iris Connector on the camera.
2. Connect to network using one of the following methods:
Wired Connection: Use a standard network cable to connect the
camera to your network and optionally connect a USB hard drive
to the mini USB port.
Wireless Connection: Connect a GV-WiFi Adapter (optional
accessory).
3. Optionally connect a speaker and an external microphone.
20
4. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out field on the Web
interface. See 4.1.1 Video Settings, GV-IPCam Firmware Manual.
5. Optionally connect to input / output devices or an infrared illuminator.
For details, see 1.5.2 Infrared Illuminator and 1.6 I/O Terminal Block.
6. Connect power using one of the following methods:
plugging the power adapter to the power port.
using the Power over Ethernet (PoE) function and the power will
be provided over the network cable.
7. The status LED of the camera will be on.
8. You are ready to access the live view, adjust the image clarity and
configure the basics. See Getting Started, Chapter 19, GV-IPCam
Firmware Manual.
Note: For details on limitations and requirements of the mini USB port,
refer to the Note for USB Storage and WiFi Adapter at the beginning of
this manual.
Box Camera
21
1
1.5 Accessory Installation
1.5.1 C-Mount Lenses
If you use a C-mount lens, it requires a certain distance from the camera’s
imaging chip to focus the lens. Mount the supplied C-mount lens adapter /
lens ring to the camera, and then secure the lens onto the camera body.
Three types of C-mount lens rings are provided for Box Camera:
0.188 mm (transparent color) x 2
0.125 mm (black color with a glossy surface) x 2
0.254 mm (black color with a matt surface) x 2
For GV-BX140DW, a 0.125 mm is provided.
Note: The C-mount lens rings are specially designed for Box Camera.
Besides the supplied C-mount lens rings, each of these models has
already included with the necessary lens ring.
Figure 1-5
22
1.5.2 Infrared Illuminators (Optional)
If you use an infrared (IR) illuminator with I/O function, follow the steps
below to install it.
1. Connect the infrared illuminator to the terminal block on the camera.
See 1.6 The I/O Terminal Block.
2. Access the Web interface of the camera.
3. Select Video and Motion, select Video Settings, select Streaming 1
and set the IR Check Function setting to Trigger by Input.
4. Click Apply.
For details on the Trigger by Input function, see 4.1.1 Video Settings, GV-
IPCam Firmware Manual.
Box Camera
23
1
1.6 I/O Terminal Block
The terminal block, located on the back panel of the Box Camera, provides
the interface to one input and one output devices. The I/O terminal block
can be used for applications such as motion detection, event alerts via E-
Mail and FTP, and center monitoring through Center V2 and VSM.
1.6.1 Pin Assignment
The pin assignment for the I/O terminal block:
For the output point, please check if your output device meets the following
Absolute Maximum Ratings before connecting it to the output point.
Breakdown Voltage 277V AC, 30V DC
Continuous Load Current 5A (NO), 3A (NC)
Note: Absolute Maximum Ratings are those values beyond which
damage to the camera may occur. Continuous operation of the camera at
the absolute rating level may affect the camera reliability.
The Box Camera support one digital input and one digital output of dry
contact.
Pin Function
1 Digital Input
2 GND
I/O
1 2 3
Figure 1-6 3 Digital Output
For details on how to enable an installed I/O device, see 4.2 I/O Settings,
GV-IPCam Firmware Manual.
24
1.6.2 Connecting to GV-Relay V2 (Optional)
The Box Camera can only drive a maximum load of 200mA 5V DC. To
expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A
100V DC, connect the camera to a GV-Relay V2 module (optional product).
Refer to the figure and table below.
Connect to Power
Output Device
I/O
1 2 3
Figure 1-7
GV-Relay V2 I/O Terminal Block
COM Pin 2 (GND)
DO1 Pin 3 (Digital Output)
Box Camera
25
1
1.7 Loading Factory Default
1. Keep the power and network cables connected to the camera.
2. Use a pin to press and hold the default button on the back panel of
the camera.
Default button
Figure 1-8
3. Release the default button when the status LED blinks. This shall
take about 8 seconds.
Status LED
Figure 1-9
4. When the status LED fades, the process of loading default settings is
completed and the camera reboots automatically.
26
Chapter 2 IR Arctic Box Camera
The IR Arctic Box Camera is a series of outdoor cameras designed for
environments of extreme temperatures. The cameras adhere to IP67 and
IK10 protection standards, and are equipped with IR LEDs and removable
IR-cut filter for day and night surveillance. The GV-BX2400-E / 3400-E /
4700-E are equipped with WDR Pro to produce clear image for scenes
containing contrasting intensity of lights (see 2.2.1 Wide Dynamic Range
Pro for details). Models using P-Iris allow for precise control of exposure,
producing images with better clarity and contrast.
IR Arctic Box Camera
Model No. Specifications Description
GV-BX120D-E
Auto Iris, f: 2.8 ~ 12
mm, F/1.4, 1/3” CS
Lens
1.3 MP, H.264,
Low Lux, D/N
GV-BX220D-E Auto Iris, f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens 2 MP, H.264, D/N
GV-BX320D-E Auto Iris, f: 2.8 ~ 6 mm,
F/1.3, 1/3’’ CS Lens 3 MP, H.264, D/N
GV-BX520D-E
Manual Iris, f: 4.5 ~ 10
mm, F/1.6, 1/2’’ CS
Lens
5 MP, H.264, D/N
GV-BX1500-E
Auto Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.7’’ CS
Lens
1.3 MP, H.264,
Super Low Lux,
D/N
GV-BX2400-E
GV-BX3400-E
Auto Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.7’’ CS
Lens
2 MP / 3 MP,
H.264, D/N, WDR
Pro
GV-BX4700-E
Varifocal
Lens
Auto Iris, f: 3 ~ 10.5
mm, F/1.4, 1/2.7’’ CS
Lens
4 MP, H.265, D/N,
WDR Pro
IR Arctic Box Camera
27
2
Model No. Specifications Description
GV-BX5300-E Varifocal Lens
Manual Iris, f: 4.5 ~
10 mm, F/1.6, 1/2’’
CS Lens
5 MP, H.264
D/N
GV-BX2510-E
P-Iris, f: 3.7 ~ 9 mm,
F/1.2, 1/2’’, ø 14
mm mount
2 MP, H.264,
Super Low Lux,
D/N
GV-BX5310-E
Motorized
Varifocal Lens P-Iris, f: 4.5 ~ 9 mm,
F/1.2, 1/2’’, ø 14
mm mount
5 MP, H.264
D/N
28
2.1 Packing List
For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E /
3400-E / 4700-E / 5300-E
IR Arctic Box Camera
Screw Anchor x 4
Screw x 4
Washer x 4
4 mm Torx Wrench
5 mm Torx Wrench
Silica Gel Bag x 2
Adhesive Tape for Silica Gel Bag x 2
GV-IPCAM Software DVD
GV-Software DVD
Warranty Card
Note: Optionally purchase a GV-PA482 PoE Adapter for GV-BX1500-E
/ 2400-E / 3400-E / 4700-E / 5300-E.
IR Arctic Box Camera
29
2
For GV-BX2510-E / 5310-E
IR Arctic Box Camera
Screw Anchor x 4
Screw x 4
Washer x 4
5 mm Torx Wrench
Silica Gel Bag
Adhesive Tape for Silica Gel Bag
Power Adapter (DC 48V, 2.5A, 120 W max.)
GV-IPCAM Software DVD
GV-NVR Software DVD
Warranty Card
Note: Optionally purchase a GV-PA482 PoE Adapter for GV-BX2510-E
/ 5310-E.
30
2.2 Features
Image sensor
Camera Model Image Sensor
GV-BX120D-E 1/3" progressive scan low lux CMOS
GV-BX1500-E 1/3" progressive scan super low lux CMOS
GV-BX220D-E
GV-BX320D-E
GV-BX520D-E
GV-BX5300-E
1/3.2" progressive scan CMOS
GV-BX2510-E 1/2.8” progressive scan super low lux CMOS
GV-BX2400-E
GV-BX3400-E
GV-BX5310-E
1/2.5” progressive scan CMOS
GV-BX4700-E 1/3” progressive scan super low lux CMOS
Dual streams from H.264 or MJPEG
Dual streams from H.264, H.265 or MJPEG (for GV-BX4700-E)
Frame rate:
Camera Model Frame Rate
GV-BX120D-E
GV-BX1500-E Up to 30 fps at 1280 x 1024
GV-BX220D-E
GV-BX2400-E
GV-BX2510-E
Up to 30 fps at 1920 x 1080
GV-BX320D-E
GV-BX3400-E Up to 20 fps at 2048 x 1536
GV-BX520D-E
GV-BX5300-E
GV-BX5310-E
Up to 10 fps at 2560 x 1920
GV-BX4700-E Up to 25 fps at 2560 x 1440
Up to 30 fps at 2048 x 1520
IR Arctic Box Camera
31
2
Day / Night function (with removable IR-cut filter)
Wide Dynamic Range Pro (for GV-BX2400-E / 3400-E / 4700-E)
Defog
Ingress protection (IP67)
P-Iris for auto iris adjustment (for GV-BX2510-E / 5310-E)
Vandal resistance (IK10 for metal casing)
Built-in heater and fan
Support for TV-out
Micro SD card slot (SD/SDHC) for local storage (for GV-BX2510-E /
5310-E)
NAS recording
Recording assigned by GV-Edge Recording Manager (Windows &
Mac)
Two-way audio
One sensor input and one sensor output (for GV-BX2510-E / 5310-E)
3D noise reudction (for GV-BX1500-E / 2510-E / 4700-E)
2D noise reudction (except GV-BX1500-E / 2510-E / 4700-E)
Smart Streaming(for GV-BX4700-E)
Motion detection
Tampering alarm
Privacy mask
Text overlay
IP address filtering
Power supplied through PoE+ (IEEE 802.3at, Except GV-BX2510-E /
5310-E)
Power supplied through AC / DC / PoE++ (50W, for GV-BX2510-E /
5310-E)
Megapixel lens
Support for iPhone, iPad, Android and 3GPP
31 languages on Web interface
ONVIF (Profile S) conformant
32
2.3 Overview
2.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /
2400-E / 3400-E / 4700-E / 5300-E
1 2 34
5
7 6
Figure 2-1
Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV-
BX5300-E.
No. Name Description
1. Silica gel bag Desiccant that keeps the camera housing dry.
2. IR power plug Supplies power to the built-in IR LEDs.
3. Focus Screw Adjusts the focus of the camera.
4. Module screw Holds the module in place.
5. Status LED Turns on when the camera is ready for use.
6. Zoom Screw Adjusts the zoom of the camera.
7. Iris Screw Adjusts the iris of the camera.
IR Arctic Box Camera
33
2
2.3.2 GV-BX2510-E / 5310-E
1
2
5
3
4
Figure 2-2
No. Name Description
1. Silica gel bag Desiccant that keeps the camera housing dry.
2. Memory Card
Slot
Inserts a micro SD card (SD/SDHC, version
2.0, Class 10) to store recording data.
3. Power LED Turns on when the camera is supplied with
power.
4. Status LED Turns on when the camera is ready for use.
5. Default Resets all configurations to factory default. For
details, see 2.7 Loading Factory Default.
34
2.4 Installation
The IR Arctic Box Camera is designed for outdoor use. Follow the steps
below to install your camera.
1. Mark the installation site and drill four holes for screw anchors.
2. Insert the supplied screw anchors.
3. Secure the camera to the wall using the supplied washers and screws.
Figure 2-3
4. Connect the camera with wires and cables. See 2.5 Connecting the
Camera.
5. Access the live view. See 2.1 Accessing the Live View, GV-IPCam
Firmware Manual.
6. Based on the live view, adjust the angle of the camera. Loosen the
indicated screw with the supplied big torx wrench and adjust the joint.
Figure 2-4
IR Arctic Box Camera
35
2
Tilt Adjustment
Figure 2-5
Pan Adjustment
Figure 2-6
7. For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E /
3400-E / 4700-E / 5300-E, adjust for image clarity based on the live
view.
A. Unscrew the cover with the supplied 4 mm torx wrench.
Figure 2-7
36
B. Hold and unplug the connector.
Figure 2-8
IMPORTANT: Unscrew and remove the cover carefully. Pulling the
cover off may cause damages to the inner wiring of the camera.
C. Adjust the focus, zoom and iris screws. For a more precise
focus, use GV-IP Device Utility. For details, see 2.2 Adjusting
Image Clarity, GV-IPCam Firmware Manual.
Figure 2-9
Note: Only GV-BX520D-E and GV-BX5300-E contain an iris screw.
IR Arctic Box Camera
37
2
D. Replace the silica gel bag. Paste the sticker to the silica gel bag.
Press the sticker several times onto the camera cover to make
sure it adheres properly.
Figure 2-10
E. Follow steps 7B and 7A to plug the connector back and close
the camera cover.
8. For GV-BX2510-E / 5310-E, optionally insert a memory card.
A. Open the camera cover using the supplied torx wrench.
Figure 2-11

Produktspecifikationer

Varumärke: GeoVision
Kategori: övervakningskamera
Modell: GV-BX2400

Behöver du hjälp?

Om du behöver hjälp med GeoVision GV-BX2400 ställ en fråga nedan och andra användare kommer att svara dig


övervakningskamera GeoVision Manualer

GeoVision

GeoVision GV-FER5302 Bruksanvisning

26 Oktober 2024
GeoVision

GeoVision GV-MFD2401-2F Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-CR420 Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-TVD4711 Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-FD1500 Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-BX320D-1 Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-PT320D Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-MFD1501-1F Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-MFD120 Bruksanvisning

17 September 2024
GeoVision

GeoVision GV-MFD1501-0F Bruksanvisning

17 September 2024

övervakningskamera Manualer

Nyaste övervakningskamera Manualer

Philips

Philips B120E Bruksanvisning

16 Januari 2025
Dahua Technology

Dahua Technology Pro IPC-HDPW5442G-Z Bruksanvisning

10 Januari 2025
Hikvision

Hikvision DS-2CE59U1T-AVPIT3ZF Bruksanvisning

8 Januari 2025
Hikvision

Hikvision IDS-2CD7526G0-IZHSY Bruksanvisning

8 Januari 2025
Hikvision

Hikvision DS-2CD2163G0-I(S) Bruksanvisning

8 Januari 2025
Hikvision

Hikvision DS-2CD2H83G1-IZS Bruksanvisning

8 Januari 2025
Speco Technologies

Speco Technologies O5LB1 Bruksanvisning

8 Januari 2025
ZKTeco

ZKTeco AntarVis 2.0 Bruksanvisning

8 Januari 2025
Speco Technologies

Speco Technologies O2P30X Bruksanvisning

8 Januari 2025
TP Link

TP Link InSight S345ZI Bruksanvisning

8 Januari 2025
