GV-IPCam H.264

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

Fixed IP Dome

Target Fixed Dome

ICH264TG2V10

Under the copyright laws, this manual may not be copied, in whole or in

part, without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any

kind and assumes no responsibility for errors or omissions. No liability is

assumed for incidental or consequential damages arising from the use of

the information or products contained herein. Features and specifications

are subject to change without notice. Note: no memory card slot or local

storage function for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows

XP are registered trademarks of Microsoft Corporation.

September 2015

Contents

Contents ..............................................................................i

Options .............................................................................. iii

Note for Adjusting Focus and Zoom..............................

Chapter 1 Fixed IP Dome .................................................1

1.1 Packing List ..............................................................................3

1.1.1 Packing List for Hard-Ceiling Mount .............................3

1.1.2 Packing List for In-Ceiling Mount..................................4

1.2 Features ...................................................................................5

1.3 Overview ..................................................................................7

1.4 Installation ................................................................................9

1.4.1 Hard-Ceiling Mount ......................................................9

1.4.2 In-Ceiling Mount.........................................................

1.4.3 Wall-Surface Mount ...................................................17

1.5 Connecting the Camera..........................................................19

1.6 I/O Terminal Block ..................................................................

1.6.1 Pin Assignment..........................................................

1.6.2 Voltage Load Expansion (Optional)............................

1.7 Loading Factory Default..........................................................

Chapter 2 Target Fixed Dome........................................

2.1 Packing List ............................................................................

2.2 Features ................................................................................. 25

2.3 Overview ................................................................................27

2.4 Installation ..............................................................................29

2.5 Connecting the Camera..........................................................

2.6 Loading Factory Default..........................................................

Options

Optional devices can expand your camera’s capabilities and versatility.

Contact your dealer for more information.

Device Description

Power Adapter

The power adapter is available for all Fixed IP Dome

Camera. Contact your sales representative for the

countries and areas supported.

GV-PA191 PoE

Adapter

The GV-PA191 PoE adapter is designed to provide

power and network connection to the cameras over

a single Ethernet cable.

GV-POE Switch

The GV-POE Switch is designed to provide power

along with network connection for IP devices. The

GV-POE Switch is available in various models with

different numbers and types of ports.

GV-Mount

Accessories

The GV-Mount Accessories provide a

comprehensive lineup of accessories for installation

on ceiling, wall corner and pole. For details, see GV-

Mount Accessories Installation Guide on the

Software DVD.

GV-Relay V2

The GV-Relay V2 is designed to expand the voltage

load of GV IP devices. It provides 4 relay outputs,

and each can be set as normally open (NO) or

normally closed (NC) independently as per your

requirement.

Smoked Cover

The smoked cover is an IK7, tinted camera cover

designed for GV-Fixed IP Dome to conceal the

direction of the camera lens.

iii

Note for Adjusting Focus and Zoom

When adjusting the Focus and Zoom Screws, do not over tighten the

Focus and Zoom screws. The screws only need to be as tight as your

finger can do it. It is not necessary to use any tools to get them tighter.

Doing so can damage the structure of lens.

For example,

Focus Screw

Zoom Screw

Fixed IP Camera

The maximum torque value for all the zoom and focus screws is 0.049 N.m

Fixed IP Camera

Chapter 1 Fixed IP Dome

The Fixed IP Dome is a series of indoor camera designed with 3-axis

mechanism for easy and flexible installation. The Fixed IP Dome features

IR LED for infrared illumination for night surveillance. The WDR Pro

models can produce clear image for scenes containing contrasting intensity

of lights. The motorized varifocal lens models allow the user to remotely

adjust the zoom and focus through the Web interface. The super low lux

models are able to display color live view in near darkness. For related

models, see 1.2 Features. The models are detailed below:

Model No. Specification Description

GV-FD220D

GV-FD320D

Auto Iris, f:3 ~ 9

mm, F/1.3, 1/3”

ø 14 mm lens mount

1.3 MP Low Lux / 2

MP / 3 MP, H.264,

D/N, Fixed IP Dome

GV-FD1200

1.3 MP Low Lux,

H.264, D/N, Fixed IP

Dome

GV-FD1500

GV-FD2400

GV-FD2500

GV-FD3400

Varifocal

Lens Auto Iris, f: 3 ~ 9

mm, F/1.2, 1/2.7’’

ø 14 mm Mount

1.3 MP Super Low

Lux / 2 MP WDR Pro

/ 2 MP Super Low

Lux / 3 MP WDR

Pro, H.264, D/N,

Model No. Specification Description

GV-FD1210

1.3 MP Low Lux,

H.264, D/N, 3x

Optical Zoom, Fixed

IP Dome

GV-FD1510

GV-FD2510

1.3 MP / 2 MP Super

Low Lux, H.264,

D/N, 3x Optical

Zoom, Fixed IP

Dome

GV-FD2410

GV-FD3410

Motorized

varifocal

Lens

Auto Iris, f: 3 ~ 9

mm, F/1.2, 1/2.7’’

ø 14 mm Mount

2 MP / 3 MP, H.264,

D/N, WDR Pro, 3x

Optical Zoom, Fixed

IP Dome

Models with P-Iris (Coming)

Model No. Specification Description

GV-FD1500

GV-FD2500

GV-VD3400

Varifocal

Lens

GV-FD1510

GV-FD2510

GV-FD3410

Motorized

varifocal

Lens

P-Iris, f: 3 ~ 9 mm,

F/1.2, 1/2.7’’

ø 14 mm Mount

1.3 MP Super Low

Lux / 2 MP Super

Low Lux / 3 MP

WDR Pro, H.264,

D/N, Fixed IP Dome

Fixed IP Camera

1.1 Packing List

1.1.1 Packing List for Hard-Ceiling Mount

 Fixed IP Dome

 Torx Wrench

 Mounting Plate

 Short Screw Anchor x 3

 Ceiling Screw x 3

 Plate Screw x 3

 TV-out Wire  Sticker

  Power Adapter GV-IPCAM H.264 Software

DVD

 GV-NVR Software DVD  Warranty Card

Note: The power adapter can be excluded upon request.

1.1.2 Packing List for In-Ceiling Mount

 In-Ceiling Housing Cover

 Mounting Plate

 Mounting Bracket x 3  Copper Pillar x 3

 Copper Pillar Screw x 6

 Bracket Screw x 3

 Thread Lock Screw

 Housing Cover Thread

 Sticker (In-Ceiling Mount)

Fixed IP Camera

1.2 Features

 Image sensor

Camera Model Image Sensor

GV-FD1200 / 1210 1/3’’ progressive scan low lux CMOS

GV-FD1500 / 1510 1/3’’ progressive scan super low lux CMOS

GV-FD2500 / 2510 1/2.8’’ progressive scan super low lux

CMOS

GV-FD2400 / 2410

GV-FD3400 / 3410 1/3.2’’ progressive scan CMOS

GV-FD220D

GV-FD320D 1/2.5’’ progressive scan CMOS

 Dual streams from H.264 or MJPEG

 Frame rate

Camera Model Frame Rate

GV-FD1200 / 1210

GV-FD1500 / 1510 30 fps at 1280 x 1024

GV-FD220D

GV-FD2400 / 2410

GV-FD2500 / 2510

30 fps at 1920 x 1080

GV-FD320D

GV-FD3400 / 3410 20 fps at 2048 x 1536

 Day and night function (with removable IR-cut filter)

 P-Iris for auto iris adjustment (Coming, for GV-FD1500 / 1510 / 2500 /

2510 / 3400 / 3410 only)

 Wide Dynamic Range Pro (for GV-FD2400 / 2410 / 3400 / 3410 only)

 Defog

 3-axis mechanism (pan / tilt / roll)

 Built-in IR LED

 Micro SD card slot (SD/SDHC) for local storage

 NAS recording

 Recording assigned by GV-Edge Recording Manager (Windows &

Mac)

 One sensor input and alarm output

 TV-out support

 Two-way audio

 3D noise reduction (for GV-FD1500 / 1510 / 2500 / 2510)

 2D noise reduction (except for GV-FD1500 / 1510 / 2500 / 2510)

 Motion detection

 Tampering alarm

 Visual automation

 Text overlay

 Privacy mask

 IP address filtering

 DC 12V / AC 24V / PoE (IEEE 802.3af)

 Megapixel lens

 Support for iPhone, iPad, Android and 3GPP

 31 languages on Web interface

 ONVIF (Profile S) conformant

Fixed IP Camera

1.4 Installation

The Fixed IP Dome is designed for indoors. With the standard packing,

there are three ways to install the Fixed IP Dome: hard-ceiling mount, in-

ceiling mount and wall-surface mount.

Note: You may also install the camera to ceilings, wall corners

(concave or convex), and poles with optional mounting kits. For details,

see GV-Mount Accessories Installation Guide on the Software CD.

1.4.1 Hard-Ceiling Mount

Figure 1-2

1. Paste the supplied sticker onto a desired location on the ceiling. Drill

the three red dots and the ellipse mark only if you wish to run the

wires into the ceiling.

2. Unpack the camera package and take out the camera body.

A. Use the torx wrench to loosen the housing cover at the front and

the back.

Figure 1-3

B. Take out the camera body

Figure 1-4

3. Secure the camera body to the mounting plate with three ceiling

screws.

Figure 1-5

Fixed IP Camera

4. Connect the network, power and other cables to the camera. See 1.5

Connecting the Camera.

5. Access the live view. See 2.1 Accessing the Live View, GV-IPCam

H.264 Firmware Manual.

6. Based on the live view, adjust the camera to a desired angle as

illustrated below.

Tip: The 3-axis mechanism offers flexible and easy ceiling / wall

installation.

Pan Adjustment

Figure 1-6

Tilt Adjustment

Figure 1-7

Rotational Adjustment

Figure 1-8

7. Adjust image clarity using the GV-IP Device Utility program. For

details, see 2.2 Adjusting Image Clarity, GV-IPCam H.264 Firmware

Manual.

8. Secure the housing cover as shown in step 2. Remove the indicated

part when necessary.

Figure 1-9

Note: Adjust the black mask inside the housing cover to make sure the

camera view is not obscured.

Fixed IP Camera

1.4.2 In-Ceiling Mount

Figure 1-10

1. Follow step 2 in the 1.4.1 Hard-Ceiling Mount to remove the housing

cover and take out the camera body.

2. Paste the supplied sticker onto a desired location on the ceiling and

cut a circle on the ceiling along the edge of the sticker.

3. On the mounting plate, locate the 3 holes labeled as 1 and insert the

3 copper pillars from the back side.

Figure 1-11

4. From the side with the numbering, secure the copper pillars with 3

copper pillar screws.

Figure 1-12

5. Place the 3 mounting brackets at the indent next to the copper pillars

(labeled as 2 on the mounting plate) and secure them using the 3

bracket screws.

Figure 1-13

Fixed IP Camera

6. Place the mounting plate on the camera body with the copper pillars

inserted in the locations indicated below. The arrow on the mounting

plate should be pointing toward the front of the camera.

Figure 1-14

7. From the bottom of the camera, secure the copper pillars using the 3

copper pillars screws.

8. Place the camera into the ceiling opening.

9. On the back side, make sure the black plastic clips are slightly above

the ceiling board and pointing outward.

Back Side Front Side

Figure 1-15

10. Tighten the bracket screws from the front side of the camera.

Produktspecifikationer

Varumärke:	GeoVision
Kategori:	övervakningskamera
Modell:	GV-VD3430

Behöver du hjälp?

Om du behöver hjälp med GeoVision GV-VD3430 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

övervakningskamera GeoVision Manualer

GeoVision GV-FER5302 Bruksanvisning

26 Oktober 2024

GeoVision GV-MFD2401-2F Bruksanvisning

17 September 2024

GeoVision GV-CR420 Bruksanvisning

17 September 2024

GeoVision GV-TVD4711 Bruksanvisning

17 September 2024

GeoVision GV-FD1500 Bruksanvisning

17 September 2024

GeoVision GV-BX320D-1 Bruksanvisning

17 September 2024

GeoVision GV-PT320D Bruksanvisning

17 September 2024

GeoVision GV-MFD1501-1F Bruksanvisning

17 September 2024

GeoVision GV-MFD120 Bruksanvisning

17 September 2024

GeoVision GV-MFD1501-0F Bruksanvisning

17 September 2024

övervakningskamera Manualer

Nyaste övervakningskamera Manualer

Philips B120E Bruksanvisning

16 Januari 2025

Dahua Technology Pro IPC-HDPW5442G-Z Bruksanvisning

10 Januari 2025

Hikvision DS-2CE59U1T-AVPIT3ZF Bruksanvisning

8 Januari 2025

Hikvision IDS-2CD7526G0-IZHSY Bruksanvisning

8 Januari 2025

Hikvision DS-2CD2163G0-I(S) Bruksanvisning

8 Januari 2025

Hikvision DS-2CD2H83G1-IZS Bruksanvisning

8 Januari 2025

Speco Technologies O5LB1 Bruksanvisning

8 Januari 2025

ZKTeco AntarVis 2.0 Bruksanvisning

8 Januari 2025

Speco Technologies O2P30X Bruksanvisning

8 Januari 2025

TP Link InSight S345ZI Bruksanvisning

8 Januari 2025
