To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

For more product details, please visit GIGABYTE's website.

B360M GAMING HD

User's Manual

Rev. 1001

Feb. 23, 2018

Motherboard

B360M GA MING HD

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or

by any means without GIGABYTE's prior written permission.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Feb. 23, 2018

Motherboard

B360M GAMING HD

- 3 -

Table of Contents

B360M GAMING HD Motherboard Layout 4 ......................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 12 ........................................................................................

Chapter 2 BIOS Setup 18 ..................................................................................................

2-1 Startup Screen 18 ...............................................................................................

2-2 The Main Menu 19 ..............................................................................................

2-3 M.I.T. .............................................................................................................. 20

2-4 System ........................................................................................................... 26

2-5 BIOS ............................................................................................................... 27

2-6 Peripherals ..................................................................................................... 30

2-7 Chipset ........................................................................................................... 33

2-8 Power ............................................................................................................. 34

2-9 Save & Exit 36 .....................................................................................................

Chapter 3 Appendix 37 ......................................................................................................

3-1 Installing an Intel® Optane™ Memory 37 ..............................................................

3-2 Drivers Installation 38 ..........................................................................................

Regulatory Statements 39 ..............................................................................................

Contact Us 44 ................................................................................................................
