Sida 1/44

For more product details, please visit GIGABYTE's website.

https://ww w.gigabyte.com/Motherboard/B550- UD-AC -rev-12?m=ma#kf

GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.

Also, to reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

B550 UD AC

User's Manual

Rev. 1201

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

For detailed product information, carefully read the User's Manual.

For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's

website.

https://download.gigabyte.com/FileList/Manual/mb_manual_installation-guide_103.pdf?m=sw

For product-related information, check on our website at: https://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 3 -

Table of Contents

B550 UD AC Motherboard Layout 4 ...................................................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 Product Specications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 13 ........................................................................................

Chapter 2 BIOS Setup 21 ..................................................................................................

2-1 Startup Screen 21 ...............................................................................................

2-2 The Main Menu 22 ..............................................................................................

2-3 Favorites (F11) 23 ...............................................................................................

2-4 Tweaker .......................................................................................................... 24

2-5 Settings .......................................................................................................... 27

2-6 System Info. 33 ...................................................................................................

2-7 Boot ................................................................................................................ 34

2-8 Save & Exit 37 .....................................................................................................

Chapter 3 Appendix 38 ......................................................................................................

3-1 Conguring a RAID Set .................................................................................. 38

3-2 Drivers Installation 40 ..........................................................................................

Regulatory Notices 41 ....................................................................................................

Contact Us 44 ................................................................................................................
