G1.Sniper A88X
User's Manual
Rev. 3002
12ME-G1SNP88-3002R
Copyright
© 2016 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by
any means without GIGABYTE's prior written permission.
In order to assist in the use of this product, carefully read the User's Manual.
For quick set-up of the product, read the Quick Installation Guide included with the product.
For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means the
revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard BIOS,
drivers, or when looking for technical information.
Example:
Motherboard
G1.Sniper A88X
Aug. 19, 2013
Aug. 19, 2013
Motherboard
G1.Sniper A88X
- 3 -
Table of Contents
G1.Sniper A88X Motherboard Layout 4
..............................................................................
G1.Sniper A88X Motherboard Block Diagram 5
.................................................................
Chapter 1 Hardware Installation 6
.....................................................................................
1-1 Installation Precautions 6
....................................................................................
1-2 Product Specications ......................................................................................
7
1-3 Installing the APU .............................................................................................
9
1-4 Installing the Memory 9
.......................................................................................
1-5 Installing an Expansion Card 10
.........................................................................
1-6 Setup of the AMD Dual Graphics Conguration .............................................
10
1-7 Back Panel Connectors 10
..................................................................................
1-8 Changing the Operational Amplier ...............................................................
12
1-9 Internal Connectors 13
........................................................................................
Chapter 2 BIOS Setup 19
..................................................................................................
2-1 Startup Screen 19
...............................................................................................
2-2 M.I.T. ..............................................................................................................
20
2-3 System Information 23
........................................................................................
2-4 BIOS Features 24
...............................................................................................
2-5 Peripherals .....................................................................................................
26
2-6 Power Management 28
.......................................................................................
2-7 Save & Exit 30
.....................................................................................................
Chapter 3 Appendix 31
......................................................................................................
3-1 Conguring SATA Hard Drive(s) .....................................................................
31
3-2 Drivers Installation 34
..........................................................................................
Regulatory Statements 35
..............................................................................................
Contact Us 36
................................................................................................................

Produktspecifikationer

Varumärke: Gigabyte
Kategori: moderkort
Modell: G1.Sniper A88X
