Sida 1/36

GA-Z87M-HD3

GA-H87M-HD3

User's Manual

Rev. 1001

12ME-Z87MHD3-1001R

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by

any means without GIGABYTE's prior written permission.

For quick set-up of the product, read the Quick Installation Guide included with the product.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means the

revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard BIOS,

drivers, or when looking for technical information.

Example:

Motherboard

GA-Z87M-HD3

GA-H87M-HD3

Apr. 19, 2013

Motherboard

GA-Z87M-HD3

GA-H87M-HD3

- 3 -

Table of Contents

GA-Z87M-HD3/GA-H87M-HD3 Motherboard Layout 4 ......................................................

GA-Z87M-HD3/GA-H87M-HD3 Motherboard Block Diagram 5 .........................................

Chapter 1 Hardware Installation 6 .....................................................................................

1-1 Installation Precautions 6 ....................................................................................

1-2 Product Specications ...................................................................................... 7

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Back Panel Connectors 10 ..................................................................................

1-7 Internal Connectors 12 ........................................................................................

Chapter 2 BIOS Setup 17 ..................................................................................................

2-1 Startup Screen 18 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 18

2-3 System ........................................................................................................... 23

2-4 BIOS Features 24 ...............................................................................................

2-5 Peripherals ..................................................................................................... 26

2-6 Power Management 29 .......................................................................................

2-7 Save & Exit 30 .....................................................................................................

Chapter 3 Conguring SATA Hard Drive(s) ...................................................................31

Chapter 4 Drivers Installation 33 ........................................................................................

Regulatory Statements 34 ..............................................................................................

Contact Us 36 ................................................................................................................
