Sida 1/23

Specifications are subject to change without notice.

All brand names and products are registered trademarks of their

respective companies

GIGABYTE ODIN

Power Supply User’s Manual

ATX 12V version 2.2 power supply

Products: ODIN GT / ODIN PRO

Models: GE-S800A-D1, GE-S680A-D1, GE-S550A-D1 /

GE-M800A-D1, GE-M680A-D1, GE-M550A-D1

Introduction

The GIGABYTE Odin series power supply delivers out-

standing compatibilities and performance for power users

and hardcore gamers. It also delivers a comprehensive set

of tuning utilities for performance optimization. Addition-

ally, the all Japan-made capacitor design within the Odin

series enhances overall system durability and stability.

The Odin series power supply complies with the newest

ATX 12V version 2.2 specifications, and goes beyond.

This includes 4 x 12V outputs that deliver powerful, safer

and more reliable power to your hardware. With 80%+

efficiency, the power supply helps save more energy and

money on user’s electricity cost compared to typical power

supplies. It also generates less heat thanks to the high

efficiency of the 14cm cooling fan keeping the power

supply itself cooler, silent and prolong its life. In addition,

the Odin series power supply includes a variety of industri-

al-grade protective circuitries.

The Odin series power supply features Smart Cable

Management function and all cables are in sleeved finish-

ing with connector protectors, allowing users to connect

the cables which are only in use for better internal air flow

and tidier internal space.

As a member of the global community, Gigabyte provides

environment friendly products and observes the European

Union’s Restriction of Hazardous Substances (RoHS)

directive, which limits the use of lead, mercury, cadmium

and other hazardous substances in electronic products.

From components and material selection to production

processes, making up of accessories, packaging/color

boxes etc; GIGABYTE has carefully examined and

designed this product to be 100% RoHS compliant.

English

GIGABYTE will continue to develop RoHS compliant PC

components and provide valuable resources to promote

and advance RoHS directive goals and objectives.

The following are not covered by the warranty:

1. Using the product incorrectly or in a manner other

than the designed purpose.

2. Nonobservance of the proper operation provided.

3. Malfunction due to interference from other devices

4. Unapproved medication of the product.

5. Consequential damage to other objects due to the

product’s fault.

6. Malfunction arising from natural hazards E.g.

earthquake, lightning, fire, and floods.

7. The product’s warranty label has been removed or

damaged.

8. The devices inside, including power supply, hard

disk, CD-ROM drive, motherboard, ventilator, etc,

are not detached from the casing prior to transpor-

tation of the computer system, resulting in damage

to the casing or computer-related devices.

9. Any loss/damage caused by failure to follow the

installation process within the user manual.

Caution!

Hazardous

Do not open this power supply unit!

No serviceable components inside!

Refer Servicing to Qualified service personnel only!

No modification to this power supply unit!

Incorrect connector installation may possible burn

out the motherboard and other components. Be

sure to observe the instructions on installation in the

manual.

Please refer to the English version for all pictures.

English
