X299 AORUS

Gaming 3 Pro

User's Manual

Rev. 1001

12ME-X29AG3P-1001R

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or

by any means without GIGABYTE's prior written permission.

For quick set-up of the product, read the Quick Installation Guide included with the product.

In order to assist in the use of this product, carefully read the User's Manual.

For product-related information, check on our website at: http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means

the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard

BIOS, drivers, or when looking for technical information.

Example:

Motherboard

X299 AORUS Gaming 3 Pro

Jul. 27, 2017

Motherboard

X299 AORUS Gaming 3 Pro

- 3 -

Table of Contents

X299 AORUS Gaming 3 Pro Motherboard Layout 4 ..........................................................

Chapter 1 Hardware Installation 5 .....................................................................................

1-1 Installation Precautions 5 ....................................................................................

1-2 ProductSpecications ...................................................................................... 6

1-3 Installing the CPU 9 ............................................................................................

1-4 Installing the Memory 9 .......................................................................................

1-5 Installing an Expansion Card 10 .........................................................................

1-6 Setting up AMD CrossFire™/NVIDIA® SLI™Conguration .............................. 11

1-7 Back Panel Connectors 12 ..................................................................................

1-8 Onboard Buttons and LEDs 13 ...........................................................................

1-9 Internal Connectors 14 ........................................................................................

Chapter 2 BIOS Setup 23 ..................................................................................................

2-1 Startup Screen 23 ...............................................................................................

2-2 M.I.T. .............................................................................................................. 24

2-3 System ........................................................................................................... 31

2-4 BIOS ............................................................................................................... 32

2-5 Peripherals ..................................................................................................... 35

2-6 Chipset ........................................................................................................... 38

2-7 Power ............................................................................................................. 39

2-8 Save & Exit 41 .....................................................................................................

Chapter 3 Appendix 42 ......................................................................................................

3-1 ConguringaRAIDSet .................................................................................. 42

3-2 Installing an Intel® Optane™ Memory 44 ..............................................................

3-3 Drivers Installation 46 ..........................................................................................

Regulatory Statements 47 ..............................................................................................

Contact Us 52 ................................................................................................................
