Gigabyte X570S UD Bruksanvisning
Läs nedan 📖 manual på svenska för Gigabyte X570S UD (43 sidor) i kategorin moderkort. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/43
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
For more product details, please visit GIGABYTE's website.
X570S UD
User's Manual
Rev. 1002
12ME-X57SUD-1002R
Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
In order to assist in the use of this product, carefully read the User's Manual.
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV:
1.0" means the revision of the motherboard is 1.0. Check your motherboard revision before
updating motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
X570S UD Motherboard Layout 4 ......................................................................................
Chapter 1 Hardware Installation 5 .....................................................................................
1-1 Installation Precautions 5 ....................................................................................
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the CPU 9 ............................................................................................
1-4 Installing the Memory 9 .......................................................................................
1-5 Installing an Expansion Card 10 .........................................................................
1-6 Back Panel Connectors 10 ..................................................................................
1-7 Internal Connectors 13 ........................................................................................
Chapter 2 BIOS Setup 22 ..................................................................................................
2-1 Startup Screen 22 ...............................................................................................
2-2 The Main Menu 23 ..............................................................................................
2-3 Smart Fan 6 24 ..................................................................................................
2-4 Favorites (F11) 25 ...............................................................................................
2-5 Tweaker .......................................................................................................... 26
2-6 Settings .......................................................................................................... 29
2-7 System Info. 34 ...................................................................................................
2-8 Boot ................................................................................................................ 35
2-9 Save & Exit 38 .....................................................................................................
Chapter 3 Appendix 39 ......................................................................................................
3-1 ConguringaRAIDSet .................................................................................. 39
3-2 Drivers Installation 41 ..........................................................................................
RegulatoryNotices .................................................................................................... 42
Contact Us 43 ................................................................................................................
