INSTRUCTIONS BOOKLET
NOTICE D’UTILISATION
p.2
p.22
p.43
Cookers
| 5
EN
YOUR PRODUCT
Given the wide range of products available on the market, this booklet contains information about several models,
and it is therefore possible that not all of the information contained here in refers to your appliance or its accessories.
We are nevertheless at your disposition for any clarication you may require.
Your cooker consists of the following main parts:
• hob: at top part where the pan supports (supports for the pots), the gas burners, electric plates or the glass-
ceramic areas, depending on the size and the model of your cooker are located.
• : control panel cooker control devices zone (i.e. knobs and switches).
• oven door
SYMBOL MEANING
Burner / front left area
Burner / rear left area
Central burner
Burner / front right area
Burner / rear right area
Burner / left area
Oven temperature control (°C)
Timer / minute minder
SYMBOL MEANING
Multi-function electric oven features
Oven thermostat
Gas oven burner
Grill burner
Light button
Ignition button (spark)
Ventilated gas button (Multichef)
These two pilot lights indicate that the
electric oven is on and/or that the oven is
heating up.
HOW TO IDENTIFY THE SYMBOLS ON THE CONTROL PANEL
USE
HOB
USING THE HOB
If your cooker has a glass lid, make sure it is lifted open before turning on the burners, during use and the
subsequent cooling phase. Failure to do so may cause the breakage of the glass.
TURNING ON THE GAS BURNER
Place a lit match near the burner (or a spark or a ame generator), press and turn the corresponding knob counter-clockwise
to the MAX position. The hob can be equipped with electrical ignition activated through a separate button or by pressing
the knob. When it is lit, hold the knob down for approximately 10 seconds, then release it and adjust ame intensity, being
careful to position the knob in the area between maximum and minimum (included) and never between maximum and zero
to prevent turning it off unexpectedly. The burner may go out when you release the knob: this means that the thermocouple
is not hot enough. If it does not ignite within 15 seconds, wait 1 minute before trying again. If your model does not have a gas
safety valve (copper-coloured thermocouple near the burner), please check that, at regular intervals, the ame does not go out
due to possible liquid overowing from the pots during cooking.
USE OF ELECTRIC PLATES
The electrical plates are switched on by turning the knob clockwise, at a value between 0 and 4.
The higher the number, the greater the applied electrical power. By turning a plate on for the rst time or after a long period
of inactrivity, it is advisable to make it run idle without cooking on it, on the “minimum heating” position (position 1) for at least
15 minutes, so as to eliminate any humidity that the insulation may have absorbed. To optimize the use of electric plates, use
at-bottomed pots and avoid using pots with diameters smaller than the plates.
USING GLASS-CERAMIC HOBS (HIGHLIGHT)
Please refer to the booklet supplied with the appliance.
PREVENTING HOME ACCIDENTS
Do not leave the appliance unattended when cooking with fats or oil: it may cause a re.
Do not leave objects near the cooking surfaces.
If glass ceramic hobs crack, turn the appliance off to prevent possible electric shock.
8 | EN
PROGRAMMERS AND MINUTE MINDERS
MINUTE MINDER
The minute minder is switched on by turning the knob clockwise to the end of its run, in order to load the mechanism, then
counter-clockwise to set the required time. The time is expressed in minutes, a bell will let you know when the previously-set
minutes are up.
COOKING-END MECHANICAL TIMER (only in models with an electric oven)
This mechanical timer, in addition to sounding the bell, also acts as a switch, by switching off the power. It is different from the
minute minder because the ring nut around the knob (washer), in addition to indicating the minutes, also has the symbol of
a hand. To set it, turn the knob to the end of its run, in order to load the mechanism, then turn it in the opposite direction to
set the required time. If you wish to turn the oven on without setting any time, position the knob on the ‘hand’ symbol in the
manual position.
3 KEYS OF THE DIGITAL TIMER (g. 3 - page 8)
• Set the time: press the timer on/off button (bell) immediately followed by the + or – key to adjust the time. Once it has been
set, the time will automatically be set after 10 sec.
• Use the timer: to set the cooking time, press the + or – key until you reach the required amount of time (between 1 and 99
minutes). When the timer is on, it will appear on the screen. When the time is up, the timer will start ringing. To turn it off,
press the timer on/off key (bell).
• set the timer at 1 minute and when you hear the bell, press the - key to change the volume.
ELECTRONIC TIMER (g. 4 - page 8)
• Set the clock: when the oven is first connected, or after a power failure, ‘0.00’ will flash on the display. To set the clock, push
the middle set button and the (+) or (-) buttons immediately to the disered time. The time of day will be saved after 10
seconds.
• Use the timer: It can be set for a maximum period of 99 minutes and minimum of 10 seconds. To set the timer just push the
(+) or (-) button until you have set the required in minutes and seconds.
• When the timer is operating the timer on indicator will be lit. Once the pre-set time has elapsed, the timer will beep Push the
SET button switch Off. The (-) button can also be uset to change the volume of the beep.
TOUCH PROGRAMMER (g. 5 - page 8)
The touch programmer can work in 3 modes:
- MINUTE MINDER: once the time is set the timer will start counting down until it is up, and a bell will ring.
- AUTOMATIC END-COOKING: when the time is up, the oven will switch off and a bell will ring (only in models with electric ovens).
- DELAYED START: by setting the cooking time and the switch off time, the oven will start and stop automatically.
• Keyboard freeze: the programmer is equipped with automatic keyboard freeze after 7 seconds of inactivity. To unfreeze it,
press any key for 2 seconds.
• Set the programmer time: hold the + and - keys down at the same time until the central cursor between the hour and minutes
starts flashing. Then press + or - to set the time. Once you have reached the time you need to set, do not press any other key,
and after a few seconds a beep will confirm the set time.
• Setting the count down (minute minder feature): the minute minder operates separately from the oven, and can be used for
all cooking features. Hold the “Menu” key down until the screen changes. Release the key and adjust the time (minutes) by
using the + and - keys. Once you reach the required time, release the key and wait for the confirmation beep. A bell icon will
appear on the screen. At the end of the minutes, the bell will ring. Press any key to turn it off. To remove the bell icon from
the screen, press the “Menu” key. To check the remaining amount of time (before it expires), hold the “Menu” key down. To
delete the set amount of time, press the “Menu” key until the screen changes, and then press the + and - keys at the same
time. The set amount of times will thus be deleted.
• Setting Auto Power Off (only for electric ovens): turn the oven on by adjusting features and temperatures. Hold the “Menu”
key down until the screen changes, then press it again. The letters “DUR” (for ‘duration’) will appear on the screen. Press the
+ and - keys to adjust the cooking time. Wait for the confirmation beep without touching any keys. When the set amount of
time is over, the oven will switch off and the beeping sound will be set off. Press any key to turn it off. To remove the bell icon
from the screen, press the “Menu” key. To check the remaining amount of time (before it is over) hold the “Menu” key down.
To delete the set amount of time, press the “Menu” key until the screen changes, and then press the + and - keys at the same
time. Accordingly, the set amount of times will be deleted. At the end of cooking, remember to place the knob back to the
“0” position.
• Setting delayed start (only for electric ovens): hold the “Menu” key down until the screen changes, then press it again. The
letters ‘’DUR’’ (for ‘duration’) will appear on the screen. Press the + and - keys to adjust the cooking time. Then press the
“Menu” key once and the letters END will appear on the screen, indicating the menu to set the switch-off time. Press the +
and - keys to adjust the switch-off time. Then select the cooking feature and required temperature. Obviously the oven will
not start up immediately. Once the set amount of time has passed, the oven will switch off and the beep sound will start. Press
any key to turn it off. To remove the bell icon from the screen, press the “Menu” key.
• Setting the volume: press + and - at the same time, followed by “Menu”, to enter the tone setting mode and press the – key
repeatedly to change the tone of the alarm. Once you have selected the tone, the timer will memorize your selection until
you wish to change it again. Practical tips when using the programmer: please consider the amount of time for heating the
oven when the cooking time is being set. Please switch the oven off at the end of the cooking cycles.
ANALOGUE CLOCK with hands (g. 6)
• Setting the time: pull the rod (F) and turn clockwise until you have set the current time. When it is set, put the rod back in its
initial position.
• Setting the cooking time: turn the rod (without pulling it) (F) clockwise and set the required minutes on the clock disk set at
“9” (E). The maximum amount of time is 3 hours. When the time is over, a bell will ring. It will turn off automatically after three
minutes. If you wish to turn it off manually, turn the rod clockwise until you see E, 0 or a crossed-out bell on the disk and in
the E box.
• Setting the manual feature: Turn the rod clockwise to position I or to exclude the minute minder.
