Sida 1/12
www.glemm.eu
PAA 60M2Z
PAA 120M2Z
PA amplifier
Amplificatore PA
MANUALE DI ISTRUZIONI
Instruction Manual
2
• OTHER LANGUAGES •
• OTROS IDIOMAS •
• AUTRES LANGUES •
• OUTRAS LÍNGUAS •
PT
ES
FR
DE
Faça a leitura deste código QR para verificar a
disponibilidade do manual na sua língua
Escanea este código QR para comprobar la
disponibilidad del manual en tu idioma
Scannez le code QR pour vérifier la
disponibilité du mode d’emploi dans votre
langue.
Scannen Sie den QR-Code, um nach
dem Handbuch in Ihrer Sprache,
wenn es verfügbar is, zu suchen
INDICE / INDEX
CONTENUTO DELLA CONFEZIONE / INSIDE THE PACKAGING
TELECOMANDO
Remote control
MANUALE
Manual
• ITALIANO
• ENGLISH
PAG. 4
PAG. 8
AMPLIFICATORE
Amplifier
CAVO ALIMENT.
Power cable
3
Il fabbricante, allo scopo di migliorare i propri prodotti, si riserva il diritto di modificarne le caratteristiche siano
esse tecniche o estetiche, in qualsiasi momento e senza alcun preavviso.
The manufacturer, in order to improve its products, reserves the right to modify their characteristics whether
technical or aesthetic, at any time and without notice.
IT
EN
SPECIFICHE TECNICHE - TECHNICAL SPECIFICATIONS
Articolo PAA 60M2Z PAA 120M2Z
Potenza Max 2 x 60W 2 x 120W
Potenza RMS 2 x 30W 2 x 60W
Tensione costante 70/100V
Impedenze supportate 4 - 8 - 16 Ohm
Ingressi MIC 1-3: 5-8mV, 600 Ohm, LINE: 150-470mV, 10KOhm, RCA sbilanciati
Rapporto S/N Line >85dB, Mic > 72dB
Line Out 0,775(0dBV)
Risposta in frequenza 60 Hz - 15 Khz (+/-3dB)
THD Inferiore a 0,5%
Assorbimento 60W 100W
Protezioni Corto circuito, sovraccarichi, surriscaldamento
Alimentazione 230V ~& 24V ; 50-60Hz
Batteria telecomando Litio 3V CR 2025 (non inclusa)
Frequenza BT 2,4 Ghz
Dimensioni 320 x 210 x 90 mm
Peso 3,7 Kg 4,2 Kg
Item PAA 60M2Z PAA 120M2Z
Max Power 2 x 60W 2 x 120W
RMS power 2 x 30W 2 x 60W
Constant voltage 70/100V
Supported
impedance
4 - 8 - 16 Ohm
Inputs MIC 1-3: 5-8mV, 600 Ohm, LINE: 150-470mV, 10KOhm, RCA unbalanced
S/N ratio Line >85dB, Mic > 72dB
Line Out 0,775(0dBV)
Frequency response 60 Hz - 15 Khz (+/-3dB)
THD Less than 0,5%
Power consumption 60W 100W
Protections Short circuit, overload and high temp protection
Power supply 230V ~& 24V ; 50-60Hz
Remote battery Lithium 3V CR 2025 (not included)
BT frequency 2,4 Ghz
Dimensions 320 x 210 x 90 mm
Weight 3,7 Kg 4,2 Kg
