Gossen Metrawatt MAVOWATT 4 Bruksanvisning

Läs nedan 📖 manual på svenska för Gossen Metrawatt MAVOWATT 4 (24 sidor) i kategorin Mätinstrument. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Sida 1/24
3-348-721-02
5/4.17
Operating Instructions
MAVOWATT 4
Multifunction Power Meter
®
2 GMC-I Messtechnik GmbH
A V
1
2
3
4
5
6
Figure 1
GMC-I Messtechnik GmbH 3
Operating controls
1 Connection terminals Current I* (1), I (3)
Voltage L1 (2), L2 (5), L3 (8)
2 Mirror scale
3 Mechnical zero adjuster
4 Selector switch for voltage ranges 50 V / 100 V / 250 V / 500 V
5 Selector switch for current ranges 0.25 A /1 A /5 A / 25 A
6 Function switch
Symbols
The position of the function switch is marked by symbols. Where:
Meter in the "OFF" position
–1 Battery test for the voltage path of the meter
–2 Battery test for the current path of the meter
Measurement of the active power on a three-wire,
three-phase systems, balanced load
Measurement of the active power on a DC and single-phase AC system
U Measurement of AC voltage
I Measurement of AC current
U Measurement of DC voltage
I Measurement of DC current
cos ind Measurement of the power factor, inductive
cos cap Measurement of the power factor, capacitive
Phase sequence indication
Danger warning
((Caution: Note documentation)
Further symbols
Indicates EC conformity
This device may not be disposed of with the trash. Further informa-
tion regarding the WEEE mark can be accessed on the Internet at
www.gossenmetrawatt.com by entering the search term ’WEEE’.
L1L2L3
!
