Dishwasher / User ManualEN

OM 6330-90 RT/1

OM 6330-90 RT X/1

Icon Type Meaning

WARNING Serious injury or death risk

RISK OF ELECTRIC SHOCK Dangerous voltage risk

FIRE

CAUTION Injury or property damage risk

IMPORTANT / NOTE Operating the system correctly

Thank you for choosing this product.

This User Manual contains important information on safety and instructions intended to

assist you in the operation and maintenance of your appliance.

Please take the time to read this User Manual before using your appliance and keep this

book for future reference.

CONTENTS

1.SAFETY INSTRUCTIONS 1 ................................................................................................

1.1. General Safety Warnings 1 ..............................................................................................

1.2. Installation Warnings .....................................................................................................2

1.3. During Use.....................................................................................................................3

2.INSTALLATION 6 .................................................................................................................

2.1. Machine Positioning 6 .....................................................................................................

2.2. Water Connection 6 ..........................................................................................................

2.3. Water Inlet Hose 6 ............................................................................................................

2. . Electrical Connection ....................................................................................................4 7

3. ......................................................................................TECHNICAL SPECIFICATIONS 11

3.1. General Appearance.....................................................................................................1 1

3.2. Technical Specifications ...............................................................................................1 1

4.BEFORE USING THE APPLIANCE .................................................................................12

4.1. Preparing your Dishwasher for first use ...................................................................... 1 2

4.2. ....................................................................................................................Salt usage .1 2

4. est Strip ...................................................................................................................4. T 13

4. . Water Hardness .................................................................................................5Table 13

4. . Water Softener System ...............................................................................................613

4. . Setting ...................................................................................................................7 13

4. . Detergent Usege .........................................................................................................813

4. . Filling the Detergent ....................................................................................................9 14

4. . Using Combined Detergents .....................................................................................10 14

4.1 . Rinse-aid Usege ........................................................................................................1 14

4.1 . Filling the Rinse-aid and Setting ................................................................................2 14

5.LOADING YOUR DISHWASHER ....................................................................................15

5.1. Recommendations....................................................................................................... 16

5.2. Alternative Basket Loads .............................................................................................17

6.PROGRAMME TABLE .................................................................................................... 19

7.THE CONTROL PANEL .................................................................................................. 21

7.1. Changing a Programme ............................................................................................. 23

7.2. Cancelling a Programme .............................................................................................23

7.3. Switching the Machine Off ...........................................................................................23

4.3. Fill the salt ...................................................................................................................12

EN - 2

2. Installation Warnings

• Choose a suitable and safe place to install your

machine.

• Only original spare parts should be used with the

machine.

Unplug the machine before installation.

Your machine must only be installed by an

authorised service agent. Installation by anyone other

than an authorised agent may cause your warranty to

be void.

Check that the indoor electrical fuse system is

connected in line with safety regulations.

All electrical connections must match the values on

the plate.

Ensure the machine does not stand on the

electrical supply cable.

Never use an extension cord or a multiple socket

connection.

The plug should be accessible after the machine is

installed.

• After installation, run your machine unloaded for the

first time.

The machine must not be plugged in during

positioning.

Always use the coated plug supplied with your

machine.

If the electrical cable is damaged, it should only

be replaced by a qualified electrician.

• Connect the hose directly to the water inlet tap. The

pressure supplied by the tap should be a minimum

of 0.03 MPa and a maximum of 1 MPa. If the

EN - 3

pressure exceeds 1 MPa, a pressure relief valve

must be fitted between the connection.

3. During Usage

• This machine is for domestic use only; do not use

• it for other purposes. Commercial use will void the

guarantee.

Do not stand, sit or place loads on the open door of

the dishwasher.

Only use detergents and rinse aids produced

specifically for dishwashers. Our company is not

responsible for any damage that may occur due to

misuse.

Do not drink water from the machine.

Due to the danger of explosion, do not place any

chemical dissolving agents into the machine’s washing

section.

• Check the heat-resistance of plastic items before

washing them in the machine.

Only put items in the machine which are suitable for

dishwashing, and take care not to overfill the baskets.

Do not open the door while the machine is in

operation, hot water may spill out. Safety devices

ensure the machine stops if the door is opened.

The machine door should not be left open. It may

cause accidents.

Place knives and other sharp objects in the cutlery

basket in a blade-down position.

For models with the automatic door-opening

system, when the EnergySave option is active, the

door will open at the end of a program. To prevent

damage to your dishwasher, do not attempt to close

EN - 4

• Some machine components and packaging consist of recyclable materials.

• Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. )

• The cardboard parts consist of recycled paper. They can be put into waste paper

containers for recycling.

• Material unsuitable for domestic waste must be disposed of at recycling centres.

• Contact a relevant recycling centre to obtain information about disposal of different

materials.

PACKAGING AND THE ENVIRONMENT

• Packaging materials protect your machine from damage that may occur during

transportation. The packaging materials are environmentally friendly as they are

recyclable. The use of recycled material reduces raw material consumption and

therefore decreases waste production.

RECYCLING

the door for one minute after it has opened. For

effective drying, keep the door open for 30 minutes

after a programme has ended. Do not stand in front of

the door after the auto-open signal sounds.

In the case of a malfunction, repair should only

be performed by an authorised service company,

otherwise the warranty will be void.

Before repair work, the machine should be

disconnected from the mains. Do not pull the cable to

unplug the machine. Switch off the water tap.

Operation at a low voltage will cause a decline in

performance levels.

For safety, disconnect the plug once a program has

finished.

To avoid an electric shock, do not unplug the

machine with wet hands.

Pull the plug to disconnect the machine from the

mains, never pull on the cord.
