Sida 1/4

This Certificate is for the exclusive use of Intertek's client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and

conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this

Certificate. Only the Client is authorized to permit copying or distribution of this Certificate. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material,

product or service must first be approved in writing by Intertek.

Intertek Page 1 of 4 - - -23a ( -August- 9) SFT PV OP 29 201

Certificate of Conformity

Certificate Number: - -CN PV 190066

Applicant Name & Address:

Shenzhen Growatt New Energy Technology CO.,Ltd

1st East & 3rd Floor of Building A, Building B, Jiayu Industrial Park, #28,

GuangHui Road, LongTeng Community, Shiyan Street, Baoan District,

Shenzhen, P.R.China

Product Description:

Hybrid inverter / AC Coupled inverter

Ratings & Principle

Characteristics:

See Annex to Certificate of Conformity

Models/Type References:

Brand Name:

SPH 4000TL3 BH, SPH 5000TL3 BH, SPH 6000TL3 BH, SPH 7000TL3 BH,

SPH 8000TL3 BH, SPH 10000TL3 BH, SPA 4000TL3 BH, SPA 5000TL3 BH,

SPA 6000TL3 BH, SPA 7000TL3 BH, SPA 8000TL3 BH, SPA 10000TL3 BH

Growatt

Specification/Standard:

EN 50549-1: February 2019, Requirements for generating plants to be

connected in parallel with distribution networks

Part 1: Connection to a LV distribution network - Generating

plants up to and including Typ e B

Compliant with COMMISSION REGULATION (EU) 2016/631 (NC RfG)

Type approval for type B

Certificate Issuing Office Name

& Address:

Intertek Testing Services Ltd. Shanghai

2/F (West Side), No. 707, Zhangyang Road, Free Trade Experimental Area,

Shanghai, P. R. China

Test Report Number:

180820119 -001 GZU

Additional information in Appendix.

Signature

Name: Grady Ye

Position: Certifier

Date: 27 November 2019

On the basis of the tests undertaken, the samples of the below product have been found to comply with the

requirements of the referenced specifications /standards at the time the tests were carried out. It does not imply that

Intertek has performed any surveillance or control of the manufacture. The manufacturer shall ensure that the

manufacturing process assures compliance of the production units with the examined products mentioned in this

certificate.

conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this

product or service must first be approved in writing by Intertek.

Intertek Page 2 of 4 - - -23a ( -August- 9) SFT PV OP 29 201

Ratings &

Principle

Characteristics:

Model

SPH 4000 TL3

SPH 5000

TL3 BH

SPH 6000 TL3

SPH 7000 TL3

SPH 8000 TL3

SPH 10000

TL3 BH

Input data(DC)

Max.

recommended

power (for

module STC)

5200W

6500W

7800W

9100W

10400W

13000W

Max. DC

voltage

1000V

1 000V

Start voltage

160V

Nominal

voltage

600V

MPP voltage

range

160~1000V

160~10 00V

160~1000V

No. of MPP

trackers

No. of PV

strings per M PP

trackers

Max. input

current per

MPP

trackers

12A/12A

Max. short-

circuit current

per

MPP trackers

15A/15A

Output / Input data(AC)

AC nominal

power

4 000W

5000W

6000W

7000W

8000W

10000W

Max. AC

apparent power

4000VA

5000VA

6000VA

7000VA

8000VA

10000VA

Nominal AC

voltage

3W+N+PE 230V/400V; ,

AC grid

frequency

50 Hz;

Max. output

current

6.1A

7.6A

9.1A

10.6A

12.1A

15.2A

Power factor

0.8leading ~ 0.8lagging

APPENDIX Certificate of Conformity :

This is an Appendix to Certificate of Conformity Number: - -190066 CN PV .
