KITCHEN EXTRACTOR HOOD
OKAP WYSPOWY(WENTYLACYJNY)
KUCHYŇSKÁ VENTILAČNÍ DIGESTOŘ
KUCHYNSKÝ VENTILAČNÝ DIGESTOR
KONYHAI PÁRAELSZIVÓ
GZ-696
GZ-699
USER’S MANUAL
INSTRUKCJA OBSŁUGI
NÁVOD K OBSLUZE
NÁVOD NA OBSLUHU
ASZNÁLATI UTASITÁS
EN
PL
CZ
SK
HU
Dear customer!
Thank you for choosing the products of the We put our best efforts so you webrand " GUZZANTI ".
satisfied with your choice.
1. GENERAL INFORMATION
1.1 Prior to installing the extractor hood carefully read our recommendations, following whic
provide safe work of the appliance. Save this User’s manual, as it contains answers to the questions wh
may arise later.
BEFORE STARTING THE OPERATION (SWITCHING ON) THE APPLIANCE MUST BE HELD
AT THE ROOM TEMPERATURE FOR AT LEAST TWO HOURS.
1.2. This appliance is intended for extraction of polluted air from the space above the cooking app
and intended for domestic use and the household environment only.
USE OF THE APPLIANCE IN GOALS OTHER THAN DOMESTIC IS FORBIDDEN. THE RISK
OF INJURY AND PROPERTY DAMAGE INCREASES IN CASE OF USE OF THE EXTRACTOR
HOOD WITH PURPOSES OTHER THAN INTENDED, WHAT WILL LEAD TO WARRANTY
CANCELLATION.
1.3. Use of the extractor hood decreases the content of harmful products of incomplete combustion
natural gas, as well as odors produced during cooking in the air, and prevents pollution of walls, ceiling
furniture with grease and soot.
1.4. The appliance is an air purifying device of the exhaust type with a diameter fan (turbine), co
with a grease picking aluminum filter ( ) and has the option of upgrading with a carbon odor fiincluded
is manufactured from sheets of carbon steel with a decorative protective coating of powder paints -
mm in width.
1.5. Depending on the installation scheme over the cooker, the extractor hood can work in two varian
- in the mode of air extraction into the stationary ventilation shaft (chimney) of the kit
corrugated aluminum or plastic air-ducts Ø150mm or Ø120mm (see item 5.3);
- in the recirculation mode (closed circular air circulation in the kitchen), when the extractor
connected to chimney, and the air is passed through aluminum grease filter (included) and smotheri
carbon filter and is returned to the kitchen (see paragraph 5.3).
1.6. Attention! Do not start extractor hood installation before connecting it to electricity
checking its technical serviceability, and checking all of its functions.
1.7. We recommend that all installation works, connection, and repair of your extractor hood shoul
carried only by qualified specialists professionally engaged in the execution of such works.
1.8. The manufacturer does not bear responsibility for any damages and failures, caused by incor
installation, operation, and repair of the extractor hood.
1.9. The manufacturer reserves the right to modify the product in order to improve its qua
technical specifications.
1.10. Technical specifications for the extractor hood are indicated in this manual and on the label a
to the inner surface of the body (access to it opens when the filter is removed).
Attention! The extractor hood should be installed on the wall at the distance of 650-750mm above
the electric cooker and at the distance 750-850 mm above the gas cooker.
EN
2. MAIN TECHNICAL SPECIFICATIONS
Model of kitchen extractor hood
GZ-696, GZ-699
Network voltage, V
220-230
AC frequency, Hz
50
Control type
sensor
Number of operation modes
3
Rated power consumption, W
Of the motor 200
Lighting (LED) 2x3
General
206
Productivity while connecting to standard ventilation system m
3
/hour 632 / 634
Overall dimensions of the
extractor hood, mm
Width
600 / 900
Depth 467
Height
560-810
Connection size of ventilation duct, Ø150 / Ø120 mm
Weight, kg 6,8 / 7,2
Noise level, 52-70 / 50-69 dB
Protection class I
Operation mode S1 (long-lasting)
Electro cable type Armoured and grounded
3. PARTS SUPPLIED
Item
Quantity
Kitchen extractor hood
1 pcs.
Decorative chimney
1 pcs.
Plastic pipe adapter (from Ø150 to Ø120mm)
1 pcs.
Screw universal trim-head
6 pcs.
Screw universal trim-head
2 pcs.
Expansion wall plug
6 pcs.
User’s manual
1 pcs.
4. SAFETY REQUIREMENTS
ATTENTION!
IT IS FORBIDDEN TO CONNECT THE EXTRACTOR
HOOD
TO THE NETWORK OF THE ELECTRIC COOKER.
PROTECT ELECTRIC CORD FROM MECHANICAL AND
THERMAL DAMAGE.
