Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
High Wall (EK platform)
AS092MGERA
• DC fan motor, higher efciency and lower sound level
• Built-in EEV, easier installation
• Negative ion, vitamin C and ESF lter optional
FEATURES & BENEFITS
Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
Indoor unit name:
Indoor unit model:
Type:
Rated cooling capacity(kW):
Sensible capacity(kW):
Cooling input power(kW):
Power supply(V/Hz/Ph):
Power supply connections:
Min. circuit Amps MCA (A):
Dimensions(H×W×D)(mm):
Panel(H×W×D)(mm):
Net weight(kg):
Panel weight(kg):
Airow rate (H/M/L)(m3/h):
Moisture removal(m3/h):
Gas pipe connection(mm):
Liquid pipe connection(mm):
Condensate connection(mm):
Sound pressure(H/M/L)(dBA):
Sound power level(H/M/L)(dBA):
AS092MGERA
High Wall
2.8
1.8
0.071
220-230/50/60/1
L,N, Ground
0.21
0.66
265×938×187
/
10.9
/
3.2
0.071
600/462/415
Φ12.7
Φ6.35
Φ16.8
37/34/31
48/44/42
0/0
Indoor(°C DB/WB):27/19
Ambient(°C DB/WB):35/24
Indoor(°C DB/WB):20/14.5
Ambient(°C DB/WB):7/6
Rated heating capacity(kW):
Heating input power(kW):
Rated cooling conditions:
Rated heating conditions:
Rated piping length (m):
Rated height separation(m):
PERFORMANCE
INDOOR UNIT DETAILS
Ext. static pressure
(Rated/Max)(Pa):
High Wall
(EK platform)
Max. fuse Amps MFA (A)：
Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
DIMENSIONAL DRAWING
①②⑨
⑦
⑧
⑤
④
③
⑥
pipe direction
938
above 100
(reserved space) (reserved space)
(pipe direction)
nameplate
187
265
above 30
above 50
when installed at high place
less than 120
(reserved space)
(reserved space)
(reserved space)
above 2500
Part Name
Connecting port for gas pipe
Connecting port for liquid pipe
Outlet grill
SN
1
2
3
4
5
6
7
Drain hose(accessory)
8
Grounding terminal
Panel
Inlet grill
Left side pipe connection port
9 Right side pipe connection port
