Please read this operation manual before using the air conditioner.
Keep this operation manual for future reference.
SPLIT TYPE ROOM AIR CONDITIONER
OPERATION MANUAL
0011511007
7
1
2
6
5
Contents
PARTS AND FUNCTIONS
OPERATION
MAINTENANCE
CAUTIONS
TROUBLE SHOOTING
AS09TACHRA
AS12TBCHRA
AS18TCCHRA
AS24TECHRA
AS26TACHRA
AS35TBCHRA
AS53TCCHRA
AS71TECHRA
条形码绘制区
Outdoor Unit
4
OUTLET
INLET
CONNECTING PIPING
AND ELECTRICAL WIRING
DRAIN HOSE
4
Loading of the battery
1
2
3
4
Remove the battery cover;
Load the batteries as illustrated.
2 R-03 batteries, resetting key
(cylinder);
Be sure that the loading
is in line with the" + "/"-";
Load the battery,then put on the cover again.
The distance between the signal transmission head and the rece-
iver hole should be within 7m without any obstacle as well.
When electronic-started type fluorescent lamp or change- over
wireless telephone is installed in the
ver is apt to be disturbed in receiving the signals,
so the distance to the indoor unit should be shorter.
type fluorescent lamp or
room, the recei
Note:
Full display or unclear display during operation indicates the
ries have been used up.Please change batteries.
If the remote controller can't run normally during operation, please
reload several minutes later.
batte
remove the batteries and
Parts and Functions
Remote controller
If the unit which you purchased has healthy function,follow it.If not,please ignore.
NOTE:
Cooling only unit do not have displays and functions related with heating
Indoor Unit
1. Mode display
2. Signal sending display
4. FAN SPEED display
5. LOCK display
6. TIMER OFF display
TIMER ON display
7. TEMP display
Used to lock buttons and LCD display
25. RESET button
When the remote controller appears
abnormal, use a sharp pointed
article to press this button to reset
22. HOUR button
Control the lightening and
extinguishing of the indoor LED
display board.
8.
9. QUIET button
10. HEAT button
11. COOL button
12. AUTO button
13. FAN SPEED button
14. TIMER button
15. SELF CLEAN button
16. LOCK button
17. LIGHT button
18. POWER ON/OFF button
19. DRY button
20. TEMP button
21. SWING button
23. EXTRA FUNCTION button
24.CANCEL/CONFIRM button
Function: Setting and cancel to the
timer and other additional functions.
3. SWING display
Operation mode AUTO FANCOOL DRY
Remote controller
HEAT
LO MED HI AUTO
Display
circulated
the remote.
Additional functions display
1
2
3
4
5
9
10
11
12
13
14
15
16
17
8
22
23
24
25
19
20
21
18
7
6
Operation mode
Remote controller
QUIET TURBO
SLEEP
Function: Sleeping---- Healthy
airflow position1--- Healthy airflow
position 2 --- Power --- sending
--- A-B yard---
Actual inlet grille may vary from the one shown in the
manual according to the product purchased
1
Display board
(adjust left and
ow)
Vertical blade
right air fl
Air Purifying FilterInlet
(inside)
Emergency
Switch
Horizontal flap
(adjust up and down air flow
Don't adjust it manually)
Outlet
Inlet grille
6
5
2
1
4
3
6
4
2
1
5
3
(inside)
7
8
Anion generator
Display board
4
2
3
1
Operation mode indicator
(lights up when the compressor is on.)
Timer mode indicator
(Lights up whenTimer operation is selected.)
Power indicator
(Lights up when unit starts.)
Remote signal receiver
(A beeping sound is generated when a signal from remote controller isreceived.)
HEALTH
Air
HEALTH
2
Operation
Unit start / stop
In HEAT mode,warm air will blow out after a short
periodof the time due to cold-draft prevention function.
When FAN is set to AUTO, the air conditioner automatically
adjusts the fan speed according to room temperature.
Cooling only unit do not have displays and functions
related with heating
Display Board
Remote
Controller Note
COOL
DRY
HEAT
FAN nothing
In DRY mode, when room temperature becomes
lower than temp.setting+2oC,unit will run intermittently
at LOW speed regardless of FAN setting.
Under the mode of auto operation, air conditioner will
automatically select Cool or Heat operation according
to room temperature.
air conditioner automatically adjusts the fan speed
temperature.
When FAN is set to AUTO, the
according to room
In FAN operation mode, the unit will not operate in
COOL or HEAT mode but only in FAN mode ,AUTO is
not available in FAN mode.And temp.setting is disabled.
In FAN mode,SLEEP operation is not available.
Operation
Mode
AUTO
Press FAN button. For each press, fan speed
Remote controller:
Press button
Every time the button is pressed, temp.setting
increase 1o
C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
decrease 1
oC,if kept depressed, it will
decrease rapidly
Select a desired temperature.
3.Fan speed selection
2.Select temp.setting
Air conditioner is running under displayed fan speed.
When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed according to room
temperature.
1. Unit start
Press ON/OFF on the remote controller, unit starts.
/
Remote controller
changes as follows:
at air outlet if all vertical louvers are
right.
mode ,
controller will automatically
Note:
set swing position.
Remote controller
Air Flow Direction Adjustment
Press button again ,
vertical flap will stop over
present position,
the swing function will be cancelled
2.Press button. changes as follows: Pos.4
1.Vertical flap
Pos.1
Pos.2
Pos.3
3.Press button to choose the Pos.2 and Pos.3.
Pos.4
Pos.5
(Autoswing)
COOL/DRY/AUTO(Initial state):
HEAT(Initial state):
(no)
LOW MED HI AUTO
Display
circulated
When restart after remote turning off, the remote
return to the previous
Cautions:
When adjusting the flap by hand,turn off the unit.
When humidity is high,condensate water might occur
adjusted to left or
It is advisable not to keep horizontal flap at downward
position for a long time in COOLor DRY
otherwise, condensate water might occur.
1
3
2
DRED Operation
Haier Peaksmart enabled air-conditioners have a Demand
Response Mode display on the indoor unit.
The display could be labelled d1, d2, d3 (wording may
differ model to model).
odottahWnoitpircseDyalpsiDedoM
DRM3 d3
Your air-conditioner will continue
to cool or heat during the peak
demand event. The energy
consumed by your air-conditioner
is capped to 75%.
No action is required.
DRM2 d2
Your air-conditioner will continue
to cool or heat during the peak
demand event. The energy
consumed by your air-conditioner
is capped to 50%.
No action is required.
DRM1 d1
Your air-conditioner is still turned
on and the fan will continue to
operate. Your compressor is
turned off and cool/hot air will no
longer be generated
DRM1 mode is only activated during
emergency demand management
situations. This mode will automatically reset
the device within 2 hours .If your air-con is in
this mode for longer than 2 hours please
contact Energex on 13 12 53.
(This function is unavailable on some models.)
These modes are described in more detail below:
