Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
MRV SII
AV08NMSETA
• Compact size, saving space and designing time.
• DC inverter compressor and fan motor
• Double pressure sensors, more reliable and higher efciency
• Total pipe length 300m, longest pipe length 175m
• Automatic refrigerant recovery
• Nighttime mode for quiet operation
FEATURES & BENEFITS
Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
Outdoor unit name:
Outdoor unit model:
Type:
Unit combination:
Rated cooling conditions:
Rated heating conditions:
Rated piping length (m):
Rated height difference(m):
Rated cooling capacity (kW):
Nom cooling capacity (kW):
Cooling input power (kW):
EER:
Rated heating capacity (kW):
Nom heating capacity (kW):
Heating input power (kW):
COP:
Power supply(V/Hz/Ph):
Power supply connections:
Min. circuit Amps MCA (A):
Max. starting current MSC(A):
Rated load Amps RLA(A):
Dimensions(H×W×D) (mm):
Net weight(kg):
Compressor type:
Capacity control range (%):
Capacity index limit:
Airow rate (H) (m3/h):
Gas pipe connection (mm):
Liquid pipe connection (mm):
High pressure gas pipe connection (mm):
Oil equalization connection (mm):
Sound pressure (H) (dBA):
Sound power level (dBA):
Max. No. of indoor units:
MRV SII
AV08NMSETA
Heat pump
/
/
0
380-400/50/60/3
L1,L2,L3,N,Ground
17.20
20.00
5
9.60
1636×1050×400
168
DC inverter rotary
10~100
22.60
22.60
5.79
3.90
25.00
25.00
5.43
4.60
50~130
10000
Φ19.05
Φ9.52
/
/
55
66
13
Indoor(°C DB/WB):27/19
Ambient(°C DB/WB):35/24
Indoor(°C DB/WB):20/14.5
Ambient(°C DB/WB):7/6
PERFORMANCE
OUTDOOR UNIT DETAILS
Max. overcurrent protection
(MOP)(A)：
Refrigerant type:
Holding refrigerant charge (kg):
Additional charge (kg):
Pre-charge piping (length) (m):
Max. pipe length (total) (m):
Max. height separation (IDU to IDU) (m):
Cooling operation range (°C DB):
Heating operation range (°C DB):
Max. height separation (IDU to ODU)(m):
Cooling adjustable range (°C DB):
Heating adjustable range (°C DB):
R410A
7.4
Piping length
caculation amount
0
300
15
-5~43
-15~21
50
16~30
16~30
SYSTEM DETAILS
Haier Commercial Air Condition
ADDRESS: NO.1 Haier Road,Hi-tech Zone, Qingdao 266101 P.R.China Haier reserves the right to make change without any notice.
Web: Http://www.haier.com
Submittal Data Sheet
DIMENSIONAL DRAWING
1050
1636
30
400
468
650200 200
31
Drainage hole
Installation hole4-Ф15
Digital tube
Pipe connecting valve
Wire hole
Pipe hole
Pipe hole
Wire holePipe hole
