Operation & Installation Manual

CASSETTE TYPE AIR CONDITIONER

Indoor Unit

No. 0150504303

Before using the air conditioner, please read this manual carefully.

Please keep this manual properly for future use.

Contents

Cautions .....................................................................................................

Introduction to Spare Parts ............................................................................

Maintenance .............................................................................................

Trouble Shooting ...................................................................................

When Trouble Happens .........................................................................

Customer Need-to-know ..............................................................................

Precaution for Installation ...........................................................................

Installation Tools..........................................................................................

Installation Procedure..............................................................................

Name of Parts ..............................................................................................

Safety Cautions .......................................................................................

Installation Procedure .............................................................................

1-5

7-10

11-12

13-14

18-29

31-32

33-42

outdoor unit

indoor unit

Cautions

Disposal of the old air conditioner

Before disposing an old air conditioner

that goes out of use, please make sure it's

inoperative and safe. Unplug the air

conditioner in order to avoid the risk of

child entrapment.

It must be noticed that air conditioner

system contains refrigerants, which require

specialized waste disposal. The valuable

materials contained in a air conditioner can

be recycled. Contact your local waste

disposal center for proper disposal of an

old air conditioner and contact your local

authority or your dealer if you have any

question. Please ensure that the pipework

of your air conditioner does not get

damaged prior to being picked up by the

relevant waste disposal center, and

contribute to environmental awareness by

insisting on an appropriate, anti-pollution

method of disposal.

Disposal of the packaging of your new

air conditioner

All the packaging materials employed in

the package of your new air conditioner

may be disposed without any danger to the

environment.

The cardboard box may be broken or cut

into smaller pieces and given to a waste

paper disposal service. The wrapping bag

made of polyethylene and the polyethylene

foam pads contain no fluorochloric

hydrocarbon.

Consult your local authorities for the name and

address of the waste materials collecting

centers and waste paper disposal services

nearest to your house.

Safety Instructions and Warnings

Before starting the air conditioner, read the

information given in the User's Guide

carefully. The User's Guide contains very

important observations relating to the

assembly, operation and maintenance of the

air conditioner.

The manufacturer does not accept

responsibility for any damages that may

arise due to non-observation of the following

instruction.

Damaged air conditioners are not to be

put into operation. In case of doubt, consult

your supplier.

Use of the air conditioner is to be carried

out in strict compliance with the relative

instructions set forth in the User's Guide.

Installation shall be done by professional

people, don't install unit by yourself.

All these valuable materials may be taken to

a waste collecting center and used again after

adequate recycling.

For the purpose of safety, the air

conditioner must be properly grounded in

accordance with specifications.

Always remember to unplug the air

conditioner before opening inlet grill. Never

unplug your air conditioner by pulling on the

power cord. Always grip plug firmly and

pull straight out from the outlet.
