Please read this booklet carefully before fixing and using and
save it for future reference.
HIL 2080EGC
OPERAITON THEORY OF MICROWAVE OVEN
1. Microwave is a kind of high frequency electromagnetic wave, which is commonly distributed in the
nature. But the existing form of microwave is dispersed so that it cannot be collected together for heating
purpose. The key component of magnetron of microwave oven will transform the energy of electricity to
microwave and huge energy of microwave field is established under the closed cavity. So the molecule of
food is caused to vibrate at very high speed and the friction heat produced will cook the food in a fast
way.
2. There are 3 properties of microwave:
a) Absorbability: the microwave can cause the excess vibration of molecule of various food so as to obtain
the heating purpose. But the infiltration ability is largely depend on the size, thickness and properties of
the food.
b) Penetrability: microwave can penetrate through ceramics, glass, temperature-resistant plastics. It is
required to use the containers whose material have good microwave penetrability to achieve best heating
result. See the below utensils guide.
c) Reflectivity: microwave would be reflected by the metal wall of interior cavity so as to establish an
even magnetic field, thus can prevent the overheating of partial area.
INSTALLATION OF MICROWAVE OVEN
1) To ensure sufficient ventilation, the distance of the back of microwave to the wall should be at least 10 cm,
the side to the wall should be at least 5cm, the free distance above the top surface at least 20 cm.
2) The appliance should be operated with the rear side placed against a wall.
3) Do not place any objects on the top of microwave oven.
4) The position of the oven shall be such that it is far from the TV, Radio or antenna as picture disturbance
or noise may occur.
5) The appliance must be positioned so that the plug is accessible.
6) The microwave oven is intended to be used freestanding and shall not be placed in a cabinet.
7) To keep the microwave oven at a distance from the
8) 15amp power plug to be used
wall, it is necessary to install a distance limiter
Push Distance Limiter
in this direction
1)Push Distance Limiter in the given direction;
2)Make sure Clasp A is secured to Hole A;
Secure Clasp A to Hole A
Hole A
Clasp A
Hole A
Distance Limiter
3)Insert Clasp B and Clasp C into their respective square holes .
Clasp C
Clasp B
1
2
UTENSILS GUIDELINE
It is strongly recommended to use the containers which are suitable and safe for microwave cooking.
Generally speaking, the containers which are made of heat-resistant ceramic, glass or plastic are suitable
1
for microwave cooking. Never use the metal containers for microwave cooking and combination cooking
as spark is likely to occur. You can take the reference of below table.
Material of containe setoNibmoC llirG evaworciM
Heat-resistant ceram Yes No No Never use the ceramics which are decorated with
metal rim or glazed
Yes No No Can not be used for long time microwave cooking
Heat-resistant glass oN oN seY
seY seY oN kcar llirG
Plastic film Yes No No It should not be used when cooking meat or chops
as the overtemperature may do damage to the film
FOR THE FIRST USE
As there is manufacturing residue or oil remained on the oven cavity or heat element, it usually would
smell the odor, even a slight smoke, It is normal case and would not occur after several times use, keep
the door or window open to ensure good ventilation. So it is strongly recommended to operate as follows:
For the oven incorporate grill function (for20UG08V only), set the oven to grill mode and operate dry
several times. Operating dry can only be conducted in the grill mode, it can not be conducted at
combination mode.
IMPORTANT SAFEGUARDS
The following basic precautions should always be followed when using electrical appliance:
1. Read all instructions before using.
2. Make sure the voltage in your living area corresponding to the one shown on the rating label of the
appliance. And the wall socket is properly grounded.
3. To reduce the risk of fire in the oven cavity:
a. Do not overcook the food.
b. Remove wire twist-ties from paper or plastic bags before placing bags in the oven.
c. Do not heat oil or fat for deep drying as the temperature of oil cannot be controlled.
d. After use wipe the waveguide cover with a damp cloth, followed by dry cloth to remove any food
splashes and grease. Built-up grease may overheat and begin to cause smoke or catch fire.
e. If materials inside the oven should smoke or ignite, keep oven door closed, turn oven off and disconnect
the power supply.
f. Close supervision is necessary when using disposable containers made from plastic, paper or other
combustible material.
4. To reduce the risk of explosion and sudden boiling:
a. Do not place sealed containers in the oven. Baby bottles fitted with a screw cap or teat are considered to
be sealed containers.
b. When boiling liquid in the oven, use the wide-mouthed container and stand about 20 seconds at the end
of cooking to avoid delayed eruptive boiling of liquids.
c. Potatoes, sausage and chestnut should be peeled or pierced before cooking. Eggs in their shell, whole
hard-boiled eggs should not be heated in microwave ovens since they may explode,even after microwave
heating has ended.
d. The cooked liquid should not be removed out immediately. Several moments should be waited before
removing In order to avoid possible hazards caused by delayed eruptive boiling of liquids.
e. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to
be checked before consumption, in order to avoid burns.
Heat-resistant plastic
2
