Sida 1/8
HMK1P-600D-FB
HMK1P-800D-FB
HMK1P-600D-FT420X2
HMK1P-800D-FT420X2
HMK1P-600D-FT440X2
HMK1P-800D-FT440X2
NOTE
• Read this user guide carefully before installing as it contains important instructions for the installation process.
• When installing the product, you and/or your assigned technician should always ensure safe conditions. Avoid installation
in rain, wind, or adverse weather conditions. Check a reliable weather forecast before installing.
• Never install the product alone, but preferably seek help from qualified technicians, as the weight of the product exceeds
20 kg. If you seek the help of non-techies, make sure that the person helping is an adult. During installation, make sure
that there are no people, pets, or animals nearby. Cancel the process if there is something damaging underneath.
• After installation, regularly check the screws to make sure they have not loosened. Regularly check the overall stability of
the product (especially after adverse weather conditions). If instability is suspected, a technician must be called in
immediately.
• chnician or reach out to our customer service for guidance. In instances of uncertainty, seek assistance from a qualified te
You can find our local contact details visiting this web page: https://eur.nahui-newenergy.com/services.html
Description Quantity Colour Unit
2 PIECE
1 PIECE
Mounting brackets 2 SET
AC cable 1 PIECE
DC cable 1 PAIR
Installation guide 1
Black
Silver
Silver
Black
Red+Black
/ PIECE
PACKING LIST
PV Panels
Haier microinverter
NOTE:
Nominal Power of PV Panels and Max AC Power of microinverter depends on the specific
purchased model.
Smart Balcony Solar Kit - LUMENIA
QR Code for manuals in multi-language
Scan the QR code to download the
user manual in other languages
[ EN ]
1. Accessories
V 2.2 EN
1 1×2
2 1135mm 4×2
3 545mm 2×2
4 1110mm 1×2
5 6×2M8x20
6 2×2M6x20
7 1×2M8x20
1722 x 1134 x 30 mm
Solar panel
Rail connector
Crossbar
M8 screw
M6 screw
M8 screw
(For Micro inverter)
Serial
no. Designation Image Size Quantity
Top Cover
Lower cover
Solar panel
Solar panel
Cable+Strap+Rubber mat
+Installation tools
Microinverter
Hook+Accessories
Hook+Accessories
Bracket
Pearl cotton
01
Quick Installation Guide for Smart Balcony Solar Kit
LUMENIA
2. Installation Instruction
STEP 1. Mounting Balcony Bracket
STEP
les on the solar panel.
4 times M6×20 with one gasket
2×28
10×2
10 2×2
11 Micro inverter 1
12 DC Cable 1 pair
1m
13 AC Cable 1 5m
screw
screw
Railing hook
Screws are included in the
accessories
Serial
no. Designation Image Size Quantity
14 2×2
2×2
Strap
15 Installation tools
16 Rubber mat
02
2137×25×5mm
STEP 1.2 - Mounting the triangular bracket
Use M8 screws to connect the triangular bracket.（
connector）
6 times M8×20 with one gasket
41°
38°
36°
34°
32°
30°
27°
41° 38° 36° 34° 32° 30° 27°
1135
545
1135
27-41°
03
The crossbar gives the additional stability of the substructure and is usually used to mount the
micro-inverter directly.
Pretighten the M6 screws and slider，
When doing so, observe the required cable lengths. Depending on your local requirements, you
stability).
STEP 1.3 - Mounting the crossbar
STEP 1.4 - Installation of Microinverters
Before installing the micro inverter, record the information on the label on the microinverter.
(required for subsequent distribution)
2 times M6×20
04
