Haier HWM-60-12699 Bruksanvisning

Haier tvättmaskin HWM-60-12699

Läs nedan 📖 manual på svenska för Haier HWM-60-12699 (8 sidor) i kategorin tvättmaskin. Denna guide var användbar för 7 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/8
HWM70-12688NZP
HWM60-12699NZP
HWM70-12688NZP
HWM60-12699NZP
1/12 2/18 3/24 4/29
5/33 6/37 7/41 8/46
L 500mm W 520mm H 902mm
No or slow drain the digitron ，
displays“E1”,buzzing.
No or slow water filling the digitron ，
displays“E4”,buzzing.
The digitron displays“FA”,buzzing.
The machine does
not act.
Not wash
Not spin
Water level sensor is abnormal? Please contact with after-sales service
department.
The water tap is not open.
The water inlet valve is blocked.
The water pressure is too low
and the current is too small.
Are the laundries put slantingly?
Is the machine slanting?
Open the tap.Open and close the top lid once,
then press the START/PAUSE button.
Clean the water inlet walve,Open and close the
top once.then press the START/PAUSE button.
Wait for the normal water pressure before use.
Re-order the laundries.Close the top lid and
press the button.START/PAUSE
Safety switch actuates,not spin,
(after self-correction twice),the digitron
displays“E3”,buzzing.
Is the drain hose put down?
Is the drain hose blocked by
foreign material?
Put down the drain hose.Open and close the top
lid once then press the ，START/PAUSE button
Clean the foreign material.Open and close the
top lid once,then press the START/PAUSE button
Level the machine in right position
Note: when the digital tube displays the abnormal symbol during working,it buzzs once in
succession every two minutes,then the power will be cut automatically after ten minutes.
When the power plug is inserted, computer
board indicator is switched on, and the
machine starts working.
It is the special resume function. In the case of power
failure or the power plug is loose during washing, the
machine can save the running program, and resume
the program after the power supply is recovered. You
do not need to set the program again.
Is there power failure?
Is the power plug inserted tightly?
Is the water level reached preset
position?
Is the top lid closed?
Use it when there’s power supply.
Insert the power plug tightly.
Fill water to the preset position
Close the top lid
Is the power plug inserted tightly?
Is the top lid closed reliably?
Are the laundries set flat?
Insert the power plug tightly.
Close the top lid.
Set the laundries flat.
There’s abnormal sound
inside the machine
Is the machine slanting?
Are the laundries put slantingly in
spinning?
Adjust the machine to be even.
Reorder the laundries and close the
top lid.
The water tap leaks Fasten the jointer properly.
Is the jointer of water inlet hose
loose or twisted awry?
114
Phenomena The reason How to settle
The digitron displays E2. The top lid is not closed. Close the top lid or close the top lid
and press the START/PAUSE button
Please first pull off the power plug from the receptacle before cleaning.
After using, please clean the lint and foreign materials of the lint filter and
overflow filter in time. Otherwise it may influence your using the machine.
After washing
The lint filter must be used during washing.
It must be cleaned in time after each using.
The methods of dismantle and install lint filter as follows:
1.Push down the spring piece of the top lint filter to
make the claws out of the filter cover,and then pull out
the lint filter to get it down.(figure 1)
2.Pull the back cover of the lint filter, and then you can
get down it off the front cover (figure 2)of the lint the lint
filter.
3.Sweep the rubbish in the lint filter.
4.Put the back cover of the lint filter into the front cover.
(figure 2)
5.Put the lint filter into filter cover, and make it tight.
6.Make sure the lint filter well installed,or it can influence
your use.
The filter screen of the water inlet valve is likely
to be blocked by foreign materials and influence
the water inlet.
Please clean it with brush every two months.
If the cabinet is dirty, wipe it with wet cloth
Do not flush it directly with water.
Wipe it with neutral detergent.
Do not wipe it with thinner, petrol, alcohol etc.
1.After washing, close the water faucet. ( If needed, you can dismantle the water inlet hose.)
2.Do not store water in the washing machine for a long period. Drain the water completely
after each using.
3.Be sure to pull off the power plug before maintenance.
4.Hang up the power cord and drain hose.
5.Wipe off the water drops on the surface of the machine and inside the tub. Open the top lid
for some time (about 1 hour), then close the top lid.
(If there’s breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns
sometimes. Please confirm again before sending it to repair.
If there are real breakdowns, please come to the special maintenance department or after-sale
service department of our company. Do not repair it by yourself.
2
Power
13
ProgramProgram
The machine will beep to indicate the end of the cycle then
automatically cut the power off
1.Push the button to switch on the power
2.Push the button to select suitable automatic program
After the power is switched on,“Normal” is automatically set. To select other fully-auto program,please push the "Program”
button till the corresponding indicator is light. Refer to the " Program " button on Page 12.
After switching on the power, when the normal program is selected , the washing machine will execute fuzzy program
automatically to detect the cloth .After detection, it can set the water level automatically. To select other water level, first push
the “START/PAUSE” button, then push the “Water Level” button to set the water level.
After switching on the power, the reserve time program is set to off mode automatically. If you need to set the washing
procedure to be finished at delay time, please push the “Delay” button to set the reserve washing program. Refer to delay
button in Page 12 for selection.
When the "Delay" function is activated, the indicator light of the program you have set
will be off. The "Delay Time" and "Remaining Time" indicator lights will be on.
To change the running program or cancel the relay setting, you need to switch off the power and make new selection.
During reserve procedure, push the "Delay" button to display the relay mode.
3. Push the button,select suitable water level
4. Push the button to select suitable reserve wash program
5. Push the button,close the top lid
If the top cover is opened , the washing machine will stop running and tweet during spinning,
then close the lid,you must push the START/PAUSE again to continue running.
Finish washing
Contents marked with that symbol are related to the safety
of the product and the personal safety of the users. Please
operate in strict conformity to the contents, otherwise it may
cause damage of the machine or injure the personal safety
of the user.
Contents marked with that symbol are actions forbidden to
perform. Performing of those actions may result in damage
of the machine or injure the personal safety of the user.
Warning sign
Forbidding sign
Please understand the shapes of the washing machine and accessories may be different from
the sketch figures in this manual due to product improvement,
Meaning and description of the symbols

Produktspecifikationer

Varumärke: Haier
Kategori: tvättmaskin
Modell: HWM-60-12699
