Sida 1/5

54,6 cm / 21.5“

Part. No..: HO 225 OTB

• 1920 x 1080 Resolution Full HD P1080

• 10-Point Touch P-Cap Technology

• 178°/ 178°Ultra Wide Viewing Angle

• High Brightness Panel 1000 cd/ m²

• IP65 Rating Level

• Display Protection: Thickness 3mm

• Ambient Light Sensor

• Built-in fans

• ≥7 Toughened Hard Panel SurfaceH

• Slim Profile with Narrow Edges

• VESA Mount and Multiple Mounting Options

• Edge to Edge glass without raised frame

• Orientation: Landscape, Portrait, Face-Up

Open Frame Touch Monitor

54,6 cm / 21.5 Diagonal “

LED Backlight Format 16:9–

HO OTB225

21.5 Open Frame Touch Monitor”

CONNECTIVITY, IP LEVELSIZE, RESOLUTION VIEWING ANGLE, VESA OTHER FEATURES

Technical Specifications >>>

VGA

HDMI

IP 65

Water & Dust

Protection

178 Ultra-Wide

Viewing Angle

VESA

Wall-Mountable

21.5”

16:9 Aspect Ratio

Full HD

1920 x 1080

High Brightness

Ambient Light

Sensor

PART. NO.:

HO 225 OTB

Display Size 54.61 cm / 21.5“ Diagonal

Panel Type TFT LED Backlight–

Aspect Ratio 16:9

Resolution (H x V) 1920 x 1080 Full HD

Brightness 1000 cd/m² (Panel) 850 cd/m² (Monitor)–

Contrast (Typ.) 3.000:1 (Typical)

Display Area 476 x 268 mm

Viewing Angle L/R; U/D 178°H / 178°V

Response Time 25 msec

Pixel Pitch 0,2479 (H) x 0,2479 (V) mm

Touch Type Projected Capacitive Type 10 Point Touch–

Material Glass + Glass

Display Colors 16.7M Colors

Horizontal Frequency 30 ~ 81 kHz

Vertical Frequency 56 ~ 75 Hz

Max Display Frequency 1920 x 1080 @ 60Hz

Input 1 VGA

Input 2 HDMI

Input 3 USB (Touch)

Speakers -

Power Consumption On: 16,4W; Stand-by: 0,2W; Off: 0,2W

AC Power Range External Power Supply

Input: AC 100 ~ 240 Volt; 50 ~ 60 Hz

Output: 12V –4A

Product Dimensions 526.6 x 42 x 318.2 mm (W x D x H)

Packing Dimensions 610 x 170 x 390 mm (W x D x H)

Net / Gross Weight 7 Kg / 8 Kg

VESA Mounting 100 x 100 mm

Display Protection Thickness 3±0.3 mm

Hardness / Transmittance H Toughened hard panel surface / ≥7 ≥85%

IP Rating Level IP 65 (Front), Water and Dust Protection *

Accessory Power supply; HDMI Cable (2m);

USB Cable for Touch (1.8m).

Certifications CE, RoHS, ErP Energy Label

On Screen Display 9 Languages

Color 9300, 7500, 6500, User Mode

Ambient Light Sensor Yes, external sensor board

Operating Temperature 0° ~ 50°C

Humidity Operating

Conditions 10% ~ 90% non condensing

slightly from those illustrated on this promotion material. Please refer to actual samples for final selection. The products displayed on this promotion material may not be available for

purchase in your particular country or locality. Please check with your local HANNspree authorized representatives for the av ailability of specific products in your area. All brand, product,

Service names and logos are trademarks and/or registered trademarks of their respective manufactures and Companies. * IP65: The IP Code classifies how resistant a device is to foreign objects and moisture.

IP65 means that the monitor will operate in dusty conditions, and will resist against water jets.

HO 225 OTB

21.5” Open Frame Touch Monitor
