Sida 1/14
Quick Start GUIDE
COLDSTORE | CSTORE15-3U
Version 3.0. 3
Contents
3
3
4
4
4
4
5
5
6
6
7
7
8
11
13
13
13
14
14
14
A) Quick Start Guide Legends
B) Safety Instructions
C) Product Package Contents
D) Basic Requirements
E) System Overview
F) Chassis Mounting
G) System Connections
H) Disk Loading
I) Power Up Sequence
J) Front Panel Menu
K) COLDSTORE Set up and Maintenance oftware - SITESCAPES
Installing SITESCAPE
Getting nnected Co
L) System Configuration
M) Disk Management – Adding & Removing Disks
N) Troubleshooting
No wer po
No disk
Disk fail
O) System Transportation
P) Further Information & Resources 14
VERACITY COLDSTORE | CS 15-3UTORE QUICK START GUIDE | REV 3.0. | 201 | 3 3 October 8
A) Quick Start Guide Legends
The Information icon highlights particularly useful information or items which are very important to note
when using or configuring the product.
The Caution icon indicates possible actions or procedures which could prevent proper operation or
cause a system malfunction and the associated text will explain how to avoid this.
The Warning icon highlights important basic safety issues which if ignored may have a potential for
damage to the hardware, property damage, personal injury or even death.
Users are urged to read the safety information before
connecting and using the product.
References to further product information are listed at the end of this guide or may be downloaded from
the Veracity website www.veracityglobal.com. Refer to these resources for full product information,
information about terms and conditions of use, limited warranties, returns, software licence agreements,
environmental and recycling procedures and any other regulatory notices.
COLDSTORE®, LAID™, SFS™, DISKPLAY™, TRINITY® and the Veracity company logo are Trademarks
or Registered Trademarks of Veracity UK Ltd. Other trademarks referred to in this guide belong to their
respective owners.
COLDSTORE is covered by the following patents:
US Patent No. 8190837; European Patent No. 1999554B; Australian Patent No. 2007231179; Japanese Patent
No. 2009-502184.
The storage array should NOT be moved once powered
up as this is very likely to cause disk damage – this
applies to all types of disk storage arrays.
Information his guide is subject to chan without notice. in t ge
This document is copyright © 2011-201 eracity UK Ltd, all rights reserved. 8 V
B) Safety Instructions
These safety instructions are important and are provided to help prevent equipment damage and injury to
the installers and operators of the system. Please read and understand all of these instructions before
connecting and switching on the product.
Do not use a damaged power cable with the product. If the cable is cut, damaged, severely twisted, or if
the plug is loose, replace the power cable with a new one.
Do not place liquids (e.g. tea, coffee etc.) on top of the product. Specifically, do not spill any liquids onto
or into the product. If this happens, immediately switch off the power at the wall outlet and disconnect all
cables from the unit.
Do not handle the product or the power cable with wet hands. This could result in electric shock and
even death.
Do not insert any items into the air vents or openings anywhere on the unit, especially the power supply
unit. To do so may cause damage to fans and other components, may cause the system to malfunction and
may result in electric shock and even death.
The product is heavy. Ensure that proper lifting techniques are used when moving the unit to avoid
personal injury. It is highly recommended that the unit is installed in a proper 19” equipment rack before disks
are inserted. The unit is extremely heavy when fully populated with disks.
