NETWORK CAMERA

User Manual

PNV-A6081R

PND-A6081RV/PND-A6081RF

PNO-A6081R/PNB-A6001

Trademark

Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their

respective company.

Restriction

Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without

formal authorization.

Disclaimer

Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be

provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the

right to change the contents of this document without prior notice.

Design and specications are subject to change without prior notice.

The initial administrator ID is “admin” and the password should be set when logging in for the rst time.

Please change your password every three months to safely protect personal information and to prevent the damage of the information

theft.

Please, take note that it’s a user’s responsibility for the security and any other problems caused by mismanaging a password.

Network Camera

User Manual

English _3

●OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.

(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents

as they may deform or cause damage to the product.)

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

15. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated

from 12 Vdc, 1.42 A or PoE, 0.37 A. (PND-A6081RV/PND-A6081RF)

16. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated

from 12 Vdc 1.42 A or PoE, 0.37 A. (PNV-A6081R)

17. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated

from 12 Vdc 1.42 A or PoE, 0.37 A. (PNO-A6081R)

18. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated

from 12 Vdc, 1.17 A or PoE, 0.33 A. (PNB-A6001)

19. This product is intended to be supplied by isolation power.

20. If you use excessive force when installing the product, the camera may be damaged and malfunction.

If you forcibly install the product using non-compliant tools, the product may be damaged.

21. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As

edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or

near the kitchen table.

This may cause damage to the product.

22. When installing the product, be careful not to allow the surface of the product to be stained with chemical

substance.

Some chemical solvents such as cleaner or adhesives may cause serious damage to the product’s surface.

23. If you install/disassemble the product in a manner that has not been recommended, the production functions/

performance may not be guaranteed.

Install the product by referring to “Installation & connection” in the user manual.

24. Installing or using the product in water can cause serious damage to the product.

25. Although a rapid change in temperature could cause frost inside the dome, there will be no problem with the

video.

26. This device has been verified using STP cable. The use of appropriate GND grounding and STP cable

is recommended to effectively protect your product and property from transient voltage, thunderstroke,

communication interruption.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE

VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance

with the installation instructions.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the product.

overview

4_ overview

Class construction

An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a

protective earthing connection.

Battery

Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as

sunshine, fire or the like.

The battery cannot be replaced.

Disconnection Device

Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in

your location.

When used outside of the U.S., it may be used HAR code with fittings of an approved

agency is employed.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

ATTENTION

IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE DE

TYPE INCORRECT.

METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.

CAUTION

These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock do not perform any servicing other than that contained in

the operating instructions unless you are qualified to do so.

Please use the input power with just one camera and other devices must not be connected.

When a new product box is opened (or during the initial use of the product), moisture might

build up on the glass of the camera. The built-up moisture disappears naturally within a few

hours after powered on.

Do not arbitrarily loosen or tighten the gore valve.

The ITE is to be connected only to PoE networks without routing to the outside plant.

The wired LAN hub providing power over the Ethernet (PoE) in accordance with IEEE

802.3.at shall be a UL Listed device with the output evaluated as a Limited Power Source

as defined in UL60950-1 or PS2 as defined in UL62368-1.

Unit is intended for installation in a Network Environment 0 as defined in IEC TR 62102.

As such, associated Ethernet wiring shall be limited to inside the building.

Please read the following recommended safety precautions carefully.

yDo not place this apparatus on an uneven surface.

yDo not install on a surface where it is exposed to direct sunlight, near heating equipment or

heavy cold area.

yDo not place this apparatus near conductive material.

yDo not attempt to service this apparatus yourself.

yDo not place a glass of water on the product.

yDo not install near any magnetic sources.

yDo not block any ventilation openings.

yDo not place heavy items on the product.

yPlease wear protective gloves when installing/removing the camera.

The high temperature of the product surface may cause a burn.

User’s Manual is a guidance book for how to use the products.

The meaning of the symbols are shown below.

yReference : In case of providing information for helping of product’s usages

yNotice : If there’s any possibility to occur any damages for the goods and human caused by

not following the instruction

 Please read this manual for the safety before using of goods and keep it in the safe place.

We do not guarantee the quality of third-party products (e.g. lenses, accessories) that you

separately purchase.

In particular installation environments, there might be interference in radio communications.

When interference of electromagnetic waves occurs between the product and radio

communication device, it is recommended to keep a certain distance between the two or

change the direction of the receiving antenna.

WARNING

To Prevent damage which may caused by IR LED, don't stare at operating lamp.

For below models only.

PNV-A6081R/PND-A6081RV/PND-A6081RF/PNO-A6081R

Risk Group 1

WARNING IR emitted from this product.

Do not stare at operating lamp.

Product tested against IEC 62471

English _5

●OVERVIEW

CONTENTS

OVERVIEW

3 Important Safety Instructions

6 Recommended PC Specifications

6 Recommended Micro SD/SDHC/SDXC

Memory Card Specifications

6 NAS recommended specs

8 Optional Accessories for Installation

OUTDOOR VANDAL DOME CAMERA

9 What’s Included

9 At a Glance

10 Installation

INDOOR DOME CAMERA

17 What’s Included

17 At a Glance

18 Installation

OUTDOOR BULLET CAMERA

31 What’s Included

31 At a Glance

32 Installation

BOX CAMERA

38 What’s Included

38 At a Glance

39 Mounting the Lens

40 Inserting/Removing a Micro SD card

INSTALLATION & CONNECTION

41 Adjusting the monitoring direction for the

camera

42 Connecting with other Device

FLUSH MOUNT DOME CAMERA

24 What’s Included

24 At a Glance

25 Installation

NETWORK CONNECTION AND

SETUP

47 Connecting the Camera Directly to Local

Area Networking

47 Connecting the Camera Directly to a DHCP

Based DSL/Cable Modem

48 Using Device Manager

48 Automatically searching camera

48 Configuring IP address

49 Manually registering camera

49 Automatically configuring IP

50 Port Range Forward (Port Mapping) Setup

51 Connecting to the Camera from a Shared

Local PC

51 Connecting to the Camera from a Remote

PC via the Internet

WEB VIEWER

52 Connecting to the Camera

53 Password setting

53 Login

53 Camera Web Viewer Setup

APPENDIX

54 Troubleshooting

overview

6_ overview

RECOMMENDED PC SPECIFICATIONS

•CPU : Intel(R) Core(TM) i7 3.4 GHz or higher

•RAM : 8G or higher

•Recommended browser: Chrome

•Supported browsers: Chrome, Safari, Firefox, MS Edge(chromium based)

•Supported OS : Windows, Mac, Linux, Android, iOS, Chrome

•Verification environment

- Windows 10: Google Chrome version 80 or later, Firefox version 72 or later, MS Edge version 83 or later

- Mac 10.13/14: Safari version 11.0.1 or later

※ The video play performance of the web viewer depends on the performance of the user’s CPU and GPU.

RECOMMENDED MICRO SD/SDHC/SDXC MEMORY CARD

SPECIFICATIONS

•Recommended capacity : 16GB to 256GB (MLC type required)

•Recommended Manufacturers : SanDisk, Transcend

•Product Type : High endurance

•The compatibility varies depending on the card manufacturers and types.

NAS RECOMMENDED SPECS

•Recommended capacity : 200GB or higher is recommended.

•For this camera, you are recommended to use a NAS with the following manufacturer’s specs.

Recommended products : QNAP NAS, Synology NAS

English _7

●OVERVIEW

Outdoor Vandal Dome Camera

PNV-A6081R

Indoor Dome Camera

PND-A6081RV

Flush Mount Dome Camera

PND-A6081RF

9 17 24

Outdoor Bullet Camera

PNO-A6081R

Box Camera

PNB-A6001

31 38

overview

8_ overview

Model name Pole MountHanging Mount Housing All

PNV-A6081R SBP-187HMW SBP-300LMW (Parapet Mount)

SBP-156LMW (Parapet Mount)

SBP-300CMW (Ceiling Mount)

SBP-156CMW (Ceiling Mount)

SBP-300WMW (Wall Mount)

SBP-300WMW1 (Wall Mount)

SBP-300NBW (Installation Box)

SBP-300NBW (Wall Mount Base)

SBP-300PMW (Pole Mount)

SBP-300PMW1 (Pole Mount)

SBP-300KMW (Corner Mount)

SBP-300KMW1 (Corner Mount)

PND-A6081RV SBP-167HMW

PNO-A6081R SBP-302PM

PNB-A6001 SHB-4300HP

OPTIONAL ACCESSORIES FOR INSTALLATION

You can purchase appropriate optional accessories available.

English _9

●OUTDOOR VANDAL DOME CAMERA

outdoor vandal dome camera

WHAT’S INCLUDED

As for each sales country, accessories are not the same.

<PNV-A6081R>

AT A GLANCE

Pipe-cover

Dome-cover

Camera-module

Camera-case

Mount-plate

iReset button jZoom/Focus

Control Button

pMicro USB port

oMicro SD card slot

nTest monitor out port

fIR LED

gIllumination Sensor

kPower port

(DC 12 V)

lSeparator strap mAudio/Alarm cable

port

hNetwork

Port

Produktspecifikationer

Varumärke:	Hanwha
Kategori:	övervakningskamera
Modell:	PNV-A6081R

Behöver du hjälp?

Om du behöver hjälp med Hanwha PNV-A6081R ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

övervakningskamera Hanwha Manualer

Hanwha SHR-8160 Bruksanvisning

26 Oktober 2024

Hanwha PNM-C34404RQPZ Bruksanvisning

21 September 2024

Hanwha XNO-9083R Bruksanvisning

20 September 2024

Hanwha LNO-6012R Bruksanvisning

19 September 2024

Hanwha XNV-6081R Bruksanvisning

19 September 2024

Hanwha QNO-7022R Bruksanvisning

19 September 2024

Hanwha XNO-9082R Bruksanvisning

19 September 2024

Hanwha XNV-8081RE Bruksanvisning

19 September 2024

Hanwha HCD-6070R Bruksanvisning

19 September 2024

Hanwha QND-8020R Bruksanvisning

19 September 2024

övervakningskamera Manualer

Nyaste övervakningskamera Manualer

Hikvision DS-2CE56C0T-IRPF Bruksanvisning

5 April 2025

Hikvision DS-2CE10DF8T-FSLN Bruksanvisning

5 April 2025

Hikvision DS-2CD2141G1 Bruksanvisning

5 April 2025

Technaxx TX-192 Bruksanvisning

28 Januari 2025

Bosch AutoDome 800 Bruksanvisning

25 Januari 2025

Wisenet XNV-8080R Bruksanvisning

25 Januari 2025

Philips B120E Bruksanvisning

16 Januari 2025

Dahua Technology Pro IPC-HDPW5442G-Z Bruksanvisning

10 Januari 2025

Hikvision DS-2CE59U1T-AVPIT3ZF Bruksanvisning

8 Januari 2025

Hikvision IDS-2CD7526G0-IZHSY Bruksanvisning

8 Januari 2025
