Sida 1/20

Ph: 03 9562 3455 | E: sales@thermofilm.com.au

www.heatstrip.com.au

HEATSTRIP® Elegance With Remote & App (THE- RA)

Ele

EleEleg

ggan

anance

cece w

w wit

itith

hh R

R Rem

ememo

oot

tte

ee &

& & A

A Ap

ppp

pp C

C Con

onontr

trtrol

olol

(T(THE

HEHE-

--R

RRA)

A)A)

PPr

rro

ood

ddu

uuc

cct

MMa

aan

nnu

uua

aal

Specifications - Australia

MODEL POWER

(WATTS)

CURRENT

(AMPS)

DIMENSIONS

(mm)

WEIGHT

(Kg)

LEAD LENGTH

(mm) PLUG

THE2400RA 1306 x 170 x 42.7 6 YES 2400 10 1000

THE3200RA 1710 x 170 x 42.7 9 3200 13 1000 NO

MODEL

HEATER TYPE High intensity electric radiant overhead heater with high surface area proled

alloy

OUTPUT Refer to model code chart above

POWER 240 Volts Nominal at 50 Hertz, Single Phase

CONNECTION 3 Core Cable 2.5mm 2

APPROVALS AUSTRALIA/NZ

MOUNTING HEIGHT

MINIMUM

RECOMMENDED

MAXIMUM

2.1 m

2.3 m to 2.5 m

2.7 m in a fully enclosed outdoor area (For higher

ceiling heights, units can be lowered using oponal

bracket kits or refer to the HEATSTRIP Max range)

MOUNTING OPTIONS

Suitable for ceiling, wall, beam, xed umbrella and recess mounng. Also

available for extension mount using rigid xing poles and chains / wire

suspension.

PROTECTION RATING IP55 Protecon from water ingress from all direcons

MATERIALS OF CONSTRUCTION High temperature coated aluminium alloy

THE2400RA THE3200RA

42.7

March 2023 Revision 2

Operang cost comparison

In many instances, pao heaters powered by gas boles are used as an outdoor heang source. The below table shows

the operaonal cost comparison between HEATSTRIP® and a boled gas outdoor heater. Not only are the hourly running

costs considerably less with HEATSTRIP®, but you never have to worry about running out of gas, no relling, no unarac-

ve gas bole to waste space; and HEATSTRIP® actually improves the value of your property.

Notes:

1. Calculaons of hourly running cost for outdoor gas heater is based

on $25.00 average to ll a 9kg gas bole and average running me

of 9 hours. $25.00 / 9 hours = $2.78 per hour

2. Electricity rate of 25.0 cents/kWh

3. All calculaons are excluding GST.

1.8kW x 0.25 cents = $0.45 or 45 cents per hour

2.4kW x 0.25 cents = $0.60 or 60 cents per hour

3.2kW x 0.25 cents = $0.80 or 90 cents per hour

Calculaons of yearly running cost are based on 180 hours usage

180 hours x $2.78 = $500.40 yearly running cost for outdoor gas heater

180 hours x $0.60 = $108.00 yearly running cost for 2400W HEATSTRIP Elegance

180 hours x $0.80 cents = $144.00 yearly running cost for 3200W HEATSTRIP Elegance

RUNNING

COST

OUTDOOR GAS

HEATER

HEATSTRIP ELEGANCE ELECTRIC RADI-

ANT HEATER

THE2400R THE3200R

PER HOUR $2.78/hr $0.60/hr $0.80/hr

PER YEAR $500.40 $108.00 $162.00
