PREFACE

This booklet is your guide to the basic operation and maintenance of your new

Hero MotoCorp KARIZMA. Please take time to read it carefully. As with any fine machine,

proper care and maintenance are essential for trouble-free operation and optimum

performance.

Your Authorised dealer will be glad to provide further information or Hero MotoCorp

assistance and is equipped to handle your future service needs.

We at are committed to demonstrate excellence in our environment Hero MotoCorp,

performance on a continual basis, as an intrinsic element of our corporate philosophy. To

achieve this we commit ourselves to continue product innovations to improve environment

compatibility, comply with all applicable legislation including environment legislation and

strengthen the green supply chain.

Let us make this world a safer, healthier and more environment friendly place.

Your motorcycle is conforming to latest (Bharat stage-III norms) regulation for emission,

safety & noise levels. We are also using non asbestos brake shoes/pads and engine gaskets

which are environment friendly in nature.

Thank you for selecting a Hero MotoCorp KARIZMA. We wish you many miles of continued

riding pleasure in the years ahead.

ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,

SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S

MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION

AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE

ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR

GUARANTEED. RESERVES THE RIGHT TO MAKE Hero MotoCorp Ltd

CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR

INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO

REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING

PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Ltd.

NOTE

Pg. No.Pg. No.

CONTENTS

Pg. No.

FUEL SAVING TIPS 25

MAINTENANCE 26

Importance of maintenance 62

MOTORCYCLE IDENTIFICATION 1

îAir suction valve/Seat lock/Seat removal 19

RUNNING IN PERIOD 21

îIgnition switch 12

MOTORCYCLE VIEWS 7

îInstruments & Indicators 13

îSide stand switch/Fuel valve 17

BRAKING/SAFETY PRECAUTION 23

îTripmeter/Clock/Fuel gauge display 14

PRE-RIDE INSPECTION 21

TIPS FOR HEALTHY ENVIRONMENT 6

îTool kit/First aid kit 20

PARTS FUNCTION 12

SAFE RIDING TIPS 4

îSide stand indicator 16

îLeft handlebar controls 15

îRight handlebar controls 15

îFuel tank 18

îSeat installation/Helmet hanger 20

STARTING THE ENGINE 24

ANTI-THEFT TIPS 5

îElectric starter switch/Steering lock 16

RIDING 22

ACCESSORIES & MODIFICATIONS 5

PRODUCT SPECIFICATION 2

îAir filter suction compartment 21

î5Fuse replacement 3

î39Front brake

Maintenance Safety 26

Maintenance Schedule 27

ENGINE OIL REPLACEMENT PROCESS 29

î 0Centrifugal oil filter 3

î0Spark plug 3

ENGINE OIL/ENGINE OIL TOP UP PROCESS 29

î1Air cleaner 3

î3Battery 3

î6Tyres 3

îBrake wear indicators/Suspension 41

îHeadlamp adjustment 42

îThrottle operation 43

îDrive chain slider 48

îFront wheel removal 48

CATALYTIC CONVERTER 50

ROAD SIGNS 53
