Sida 1/1
www.hotone.com
Thank you for purchasing a Hotone product.
Scan the QR code for more related information.
10. EXP OUT:
1/4” TRS jack, for connecting to
another device with EXP control
IN jack. EXP out works in any mode.
When used as an expression pedal,
Wong Press can work without a power supply.
11. OUTPUT:
1/4"mono audio jack,
for connecting to
another gear.
12. TUNER OUT:
1/4" mono audio jack,
for connecting a tuner .
Panel
1. INPUT:
1/4"mono audio jack,
for connecting guitar.
2. MODE:
V-Volume mode, for use as volume pedal.
W-Wah mode, for use as a wah pedal.
V W-Switchable volume/wah mode,/
combining volume and wah pedals in one.
5. DC 9V:
Plug in 9V DC adapter (center negative).
3. TONE:
For selecting wah filter frequency range.
4. Q:
For adjusting wah filter frequency width.
EXP OUT OUTPUT
STATUS
TUNER OUT
8
9
10 11 12
1
2 3 4 56
7
Pot Resistance (EXP OUT): 10kΩ
Input Impedance: 1MΩ
Output Impedance: 100Ω
Wah Range Selector (TONE):
WARM 290Hz to 1.4kHz
CLASSIC 360Hz to 1.8kHz
Current Consumption: Max 30mA
Dimensions: 81mm (W) x 162mm (D) x 51mm (H)
Weight: 512g
SpecificationsBattery Installation & STATUS Setting
In the interest of product
improvement, the specifications and/or
the content of products (inclu ding but
not limited to appearances, packaging
design, manu al content, accessories,
size, parameters and display screen), are
subject to change without prior notice.
Please check with local supplier for exact
offers. Specifications and features
(including but not limited to
appearances, colors and size) may vary
by model owing to environmental
factors, and all images are illu strative.
1. Remove two screws from the battery compartment
with a phillips screwdriver.
2. Remove the battery compartment cover .
3. Install a 9V battery.
4. Use the 3-way switch to set STATUS LEDs.
There are three options available:
All Off: Switches the STATUS LEDs off.
All On: The STATUS LEDs work in all modes.
VOL Only: The STATUS LEDs work only in VOL mode.
8. Footswitch:
Switch between on/off status or active
volume/wah in V/W mode (this unit
cannot be bypassed in V/W mode).
7. Battery Compartment:
For holding a 9V battery.  
6. Power/Mode LED:
Indicates on/off and mode statuses.
See “9. STATUS” section for details.
9. STATUS:
LED strip indicates current mode and pedal
position:
You can set the LED strip on demand by the
3-way switch hidden in the battery
compartment.
V
W
V/W
Green
Blue
Green/Blue
