Sida 1/24

English,1

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

Technical data

Description of the machine, 4-5

Control panel

How to run a wash cycle or a drying

cycle, 6

Wash cycles and options, 7

Table of wash cycles

Wash options

Detergents and laundry, 8

Detergent

Preparing the laundry

Washing recommendations

Load balancing system

Precautions and advice, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water and electricity supplies

Cleaning the machine

Cleaning the detergent dispenser drawer

Caring for your appliance drum

Cleaning the pump

Checking the water inlet hose

Trouble shooting, 11

Assistance, 12

WASHER-DRYER

AQUALTIS

AQM8F 49 U

Instructions for

installation and use

Español,13

Installation

 This instruction manual should be kept in a safe place

for future reference. If the washer-dryer is sold, given

away or moved, please ensure the manual is kept with

the machine, so that the new owner may benefit from

the advice contained within it.

 Read these instructions carefully: they contain vital

information relating to the safe installation and operation

of the appliance.

 Inside the pack containing this manual, you will also

find the guarantee and all the details necessary for

installation.

Unpacking and levelling

Unpacking

1. Once you have removed all the packaging from the

washer-dryer, make sure it has not been damaged

during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Remove the 4

protective screws (used

during transportation) and

the corresponding spacer,

located on the rear part of

the appliance (see figure).

3. Close off the holes using the plastic plugs supplied in

the pack.

4. Keep all the parts in a safe place; they will be needed

again if the washer-dryer is moved to another location,

to prevent the inside of the appliance being damaged.

 Packaging materials should not be used as toys for

children.

Levelling

1. Place the washer-dryer on a flat sturdy floor, without

resting it up against walls or cabinets.

2. If the floor is uneven,

the front feet of the

machine may be adjusted

until it reaches a horizontal

position (the angle of

inclination must not

exceed 2 degrees).

 If the appliance is levelled correctly, it will be more

stable and much less likely to cause vibrations and noise

while it is operating, particularly during the spin cycle.

 If it is placed on carpet or a rug, adjust the feet in such

a way as to allow a sufficient ventilation space

underneath the washer-dryer.

Connecting the electricity and water

supplies

Connecting the water inlet hose

 Before connecting the inlet hose to the water supply,

run the water until it is perfectly clear.

1. Connect the inlet hose

to the machine by

screwing it onto the cold

water inlet of the

appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

2. Connect the inlet hose

by screwing it to a cold

water tab using a 3/4 gas

threaded connection (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical data table (see next

page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand or old inlet hoses; use the

products supplied with the machine.

65 - 100 cm

Connecting the drain hose

Connect the drain hose to

drain duct piping or a wall

drain located between 65

and 100 cm above the

floor, making sure it is not

bent at all.

Alternatively, rest the drain

hose on the side of a

washbasin or bathtub,

fastening the duct

supplied to the tap (see

figure).

The free end of the hose

should not be underwater.

 We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the same

diameter as the original hose and must not exceed 150

cm in length.

Electrical connections

Before plugging the appliance into the electricity socket,

make sure that:

 the socket is earthed and complies with all applicable

laws;

 the socket is able to withstand the maximum power

load of the appliance as indicated in the Technical

data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table (see opposite);

 the socket is compatible with the plug of the

appliance. If this is not the case, have the socket or

the plug replaced.

 The machine must not be installed outdoors, even in

covered areas. It is extremely dangerous to leave the

appliance exposed to rain, storms and other weather

conditions.

 The mains socket must remain within easy reach after

the washer-dryer has been installed.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable and plug must only be

replaced by authorised technicians.

Warning! The company shall not be held responsible in

the event that these regulations are not respected.

Technical data

Model AQM8F 49 U

Dimensions

width 59,5 cm

height 85 cm

depth 64,5 cm

Capacity from 1to 8 kg for wash programme

from 1 to 6 kg for the drying programme

Electrical

connections

please refer to the technical data

plate fixed to the machine

Water connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0.05 MPa (0.5 bar)

drum capacity 62 litres

Spin speed up to 1400 rotations per minute

Energy rated

programmes

according to

regulation

EN 50229

Wash: programme ; temperature

60°C; using a load of 8 kg.

Drying:

first drying cycle performed

with a 2 kg load, by selecting the

drying level "L1";

Second drying cycle performed with a

6 kg load, selecting the maximum

drying level "L4".

This appliance conforms to the

following EC Directives:

- 89/336/EEC dated 03/05/89

(Electromagnetic Compatibility) and

subsequent modifications

- 2006/95/EC (Low Voltage)

- 2002/96/EC
