Sida 1/14

www.hotpoint.eu/register

User Manual

Quick Guide

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button with indicator light

3. WASH CYCLE PROGRESS indicator lights

4. DOOR LOCKED indicator light

5. MULTI RINSE button with indicator lights

6. FUNCTION buttons with indicator lights

7. CHILDLOCK button with indicator light

8. DELAY TIMER button

9. SPIN button

10. TEMPERATURE button

11. WASH CYCLE knob

WASH CYCLE TABLE

THANK YOU FOR BUYING A HOTPOINT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.hotpoint.eu/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter

7. Adjustable feet (4)

DETERGENT DISPENSER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent

(powder or liquid)

Compartment 3: Additives (fabric softeners,

etc.)

The fabric softener must not exceed the “MAX”

level.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

For all testing institutes:

2) Long cotton cycle: set cycle 7 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 8 at a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as

the temperature and pressure of the incoming water, ambient temperature, amount of

detergent, load quantity and type, load balancing and any additional options selected.

1) Test wash cycle in compliance with regulation 1061/2010:

This cycle is designed for normally soiled cotton loads and is the most ecient in terms of

both electricity and water consumption; it should be used for garments washable at 60°C

or at 40°C. The actual washing temperature may dier from the indicated value.

Maximum load 7 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

Energy con-

sumption kWh

Total water l

Wash cycle Temperature Maximum

spin

(r.p.m.)

Maximum

load (kg)

Duration

(minutes)

Wash Fabric

softener Powder Liquid

Default Range 2 3

1 Anti Stain 100 40 °C - 40 °C 1400 7,0 205    – – – –

2 Anti Stain Quick 40 °C - 40 °C 1400 3,5 45   –– – –

3 White 60 °C - 90 °C 1400 7,0 140    – – – –

4 Bed Linen 60 °C - 60 °C 1400 7,0 120    – – – –

5 Eco Cotton (1) 60 °C 60° C 1400 7,0 275     53 0,98 52,5

40°C 1400 7,0 220     53 0,97 75

6 Mixed 40 °C - 40 °C 1000 3,5 60   –– – –

7 Cotton (2) 40 °C - 60 °C 1400 7,0 220    – 53 0,97 75

8 Synthetics (3) 40 °C - 60 °C 1400 4,0 195    – 33 0,75 72

9 Coloureds 40 °C - 40 °C 1400 7,0 100    – – – –

10 Fast 30 min 30 °C - 30 °C 800 3,0 30   –71 0,19 29

11 Wool 40 °C - 40 °C 800 1,5 75   –– – –

12 Dark 30 °C - 30 °C 800 4,0 70   –– – –

13 Ultradelicates 30 °C - 30 °C 0 1,0 80   –– – –

14 Duvet 30 °C - 30 °C 1000 2,0 110   –– – –

Rinse + Spin – – 1400 7,0 50 – – – – – –

Spin + Drain * – – 1400 7,0 10 – – – – – – –

 Required dosage Optional dosage

710

9 8

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Anti Stain 100

This cycle is suitable to heavily-soiled garments with resistant colours. It

ensures a washing class that is higher than the standard class (A class).

When running the programme, do not mix garments of dierent colours.

We recommend the use of powder detergent. Pre-treatment with special

additives is recommended if there are obstinate stains

Anti Stain Quick

This cycle is ideal for washing daily stains in 45’. It is ideal for mixed fabrics

and coloured garments.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in

the prewash and main wash section.

Bed Linen

For washing home linen in a single cycle. It optimises the use of fabric

softener and allows for saving time and electricity. We recommend the

use of powder detergent.

Eco Cotton

Suitable for washing moderately soiled cotton garments. At 40°C and

60°C it is the standard cycle for washing cotton garments, and is the most

ecient in terms of combined water and electricity consumption.

Mixed

To wash mixed and coloured items together.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Coloureds

For washing coloured cotton garments. This programme is optimised to

keep colours bright even after repeated washing.

Fast 30 min

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Wool - Woolmark Apparel Care - Green:

The Wool wash cycle of this machine has been approved by The

Woolmark Company for the washing of wool garments labelled as “hand

wash” provided that the products are washed according

to the instructions on the garment label and those issued

by the manufacturer of this washing machine (M1126).

The Woolmark logo is a Certication mark in many

countries.

Dark

For washing dark-coloured garments. The wash cycle is designed to

preserve dark colours over time.

We recommend using a liquid detergent for best results, preferably when

washing dark-coloured garments.

Ultradelicates

Suitable for washing very delicate garments. It is advisable to turn the

garments inside out before washing them. For best results, use liquid

detergent on delicate garments. For washing silk items and curtains,

select cycle and activate the option; the machine will end the cycle

with the laundry soaked and the indicator light will ash. To drain the

water so that the laundry can be removed, press the START/PAUSE

button or the button.

Duvet

Suitable for washing clothing padded with goose down, such as single

duvets (weighing under 2 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it is

advisable to use liquid detergent to be poured into the detergent drawer.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed for spinning and draining the water.

WASH CYCLE PHASE INDICATOR LIGHTS

Once the desired wash cycle has been selected and has begun, the

indicator lights switch on one-by-one to indicate which phase of the cycle

is currently in progress.

Wash

Rinse

Spin

Drain

End of Wash Cycle

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button; if the indicator light is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the

“Auto-Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Turn the washing machine on by pressing the ON/OFF button. All the

indicator lights will light up for a few seconds, then only the lights

corresponding to the settings for the selected wash cycle will remain lit;

the START/PAUSE indicator light will also ash.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Set the WASH CYCLE knob to the desired cycle.

- Modify the temperature and/or spin: pressing the

40°

60°

button allows for

gradually reducing the temperature down to the cold wash level (20°C).

The spin speed may be progressively reduced by pressing the button,

until it is completely excluded (the “ setting. If these buttons are ”

pressed again, the maximum values are restored.

- Select the desired wash cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative

indicator light will light up steady green and the door will lock ( indicator

light on).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash. If the indicator light is not lit, the door may be

opened. To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the indicator light turns on to signal that the door

cannot be opened. While a wash cycle is running, the door remains

locked. To open the door while a cycle is under way, for example, to add

or remove garments, press the START/PAUSE button to pause the

cycle; the indicator light will ash. If the indicator light is not lit, the

door may be opened. Press the START/PAUSE button again to

continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash),

then select the desired cycle and press the START/PAUSE button

again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button.

The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

Once the cycle terminates the indicator light will light up; when the

indicator light switches o, the door may be opened. Open the door,

unload the laundry and switch o the machine. If you do not press “ON/

OFF” button, the washing machine will switch o automatically after

about a half of an hour. Close the water tap, open the door and unload

the washing machine. Leave the door ajar to allow the drum to dry.
